Thermogravimetric Analyzer TGA 4000 Applications

(1)

King Abdulaziz University

Faculty of Engineering, Rabigh

Dep. of Chemical & Mat. Engineering

Thermogravimetric Analyzer TGA 4000

TGA is a quantitative technique:

The weight of a sample is continuosly monitored while exposed to a change of Temperature in a controlled

atmosphere. It is also possible to measure decrease or increase of weight in isothermal mode or changing the atmosphere

around sample.

Auto Stepwise TGA can give very good separation for overlapping decompositions.

Thermogram is showing Auto Stepwise applied.

TGA can quantitatively measure the solvent trapped inside crystals.

Stepwise TGA: Analysis of Automotive Components

The sample list of the tare weights of crucibles :

Applications

Sample volatility Moisture content

Oxidation Stability Decomposition

Temperature Performance of Stabilizer Ash Content

(2)

Inductively Coupled Plasma Mass Spectrometry (ICP-MS)

Inductively coupled plasma mass spectrometry (ICP-MS) is a type of mass spectrometry which is capable of detecting metals and several non-metals at concentrations as low as one part in 10¹⁵ (part per quadrillion, ppq) on non-interfered low-background isotopes. This is achieved by ionizing the sample with inductively coupled plasma and then using a mass spectrometer to separate and quantify those ions.

As (Arsen) Fe (Iron) Sr (Strontium)

Be (Breyllium) Li (Lithium) Ti (Titanium) Ca (Calcium) Mg (Magnesium) Tl (Thallium)

Cd (Cadmium) Mn (Manganese) V (Vanadium)

Co (Cobalt) Mo (Molybdenum Zn (Zinc)

Cr (Chromium) Ni (Nickel) Sb (Antimony)

Cu (Copper) Pb (Lead) Se (Selenium)

Detection of the following elements:

(3)

The 2400 Series II system is comprised of four major zones:

• Combustion Zone

• Gas Control Zone

• Separation Zone

• Detection Zone

CHNS/O Elemental Analyzer

The PerkinElmer® 2400 Series II CHNS/O Elemental Analyzer (2400 Series II)

^{is a}

proven instrument for the rapid determination of the Carbon, Hydrogen, Nitrogen, Sulfur or Oxygen content in organic and other types of materials.

Applications

Polymers Chemicals Pharmaceutical Environmental

(4)

World's Smallest Laboratory FT-IR Spectrometer

The new ALPHA is in a class of its own; with its small footprint, affordable price, exchangeable sampling accessories and easy to-use software; the new ALPHA will find a place in every

laboratory.

The small footprint of the ALPHA makes it ideal for quality control. The ALPHA in

combination with Bruker Optics powerful OPUS/Mentor software and extensive infrared

libraries provide easy-to-use turn key solutions. Unknown substances are identified in seconds.

Sampling modules allow the analysis of almost any kind of sample (e.g. solids, liquids or gases).

Transmission, diffuse and external reflection and attenuated total reflection (ATR) FT-IR sampling accessories are available with the Quick Snap™ interface.

Alpha FTIR Analyzer

Applications

Identification of compounds in chemistry Study impurities in semiconductors

(5)

Gas Chromatography / Mass Spectrometry (GC/MSD)

Gas chromatography–mass spectrometry (GC-MS) is an analytical method that combines the features of gas-chromatography and mass spectrometry to identify different substances within a test sample.

Plumbing diagram for the 7890B/5977A GC/MSD’s concurrent, mid-point backflush option.

Capillary Flow Technologies enhance performance, productivity, and reliability Advantages include:• Improved retention time stability for heavy-matrix samples

• More stable chromatographic baselines • Shorter analysis times

• Less source cleaning • Longer column life

The heart of performance:

The combination of the Extractor EI source, heated monolithic gold-plated quartz quadrupole, and Triple- Axis Detector delivers the most sensitive, reliable

results.

Agilent’s Inert Flow Path Split/Splitless inlet option ensures the inertness of flow path surfaces, allowing analytes to safely pass from injector to detector

GC/MSD high-sensitivity analysis for the full range of biofuel analytes. The system is easily set up for simultaneous SIM/SCAN data acquisition to maximize sensitivity and selectivity, while providing full spectra for qualitative analysis.

Applications

Pharmaceutical metabolomics

Chemicals Food Environmental Forensic/

toxicology

(6)

High-Performance Liquid Chromatography (HPLC)

High-performance liquid chromatography (HPLC)

is a technique in analytical chemistry used to separate, identify, and quantify each component in a mixture. It relies on pumps to pass a pressurized liquid solvent containing the sample mixture through a column filled with a solid adsorbent material. Each component in the sample interacts slightly differently with the adsorbent material, causing different flow rates for the different components and leading to the separation of the components as they flow out the column.

Schematic representation of an HPLC unit.

Applications

Pharmaceutical Analysis

separation of similar molecules

food industry for quality control

(7)

Total Organic Carbon Analyzer (TOC)

Total Organic Carbon Analyzer (TOC Analyzers):

A TOC measures the amount of total organic carbon present in a liquid or water sample. TOC detection is important because of the effects that TOCs may have on health, not to mention the environmental effects and implications for the pharmaceutical manufacturing processes. a TOC analyzer always requires some accounting for the inorganic carbon (IC) that is always present.

Non-Dispersive Infra-Red (NDIR) Detector Non-Dispersive Infra-Red (NDIR) TOC fusion

Schematic representation of an TOC

Applications

Environmental :

Ground Water Surface Water

Waste Water:

Contamination

Drinking Water Quality

High Purity

Water Sea Water
