Electrochemical sensing of oxalic acid using silver nanoparticles loaded nitrogen-doped graphene oxide

Muhammad Adeel Zafar

¹

, Yang Liu

²

, Scarlett Allende

¹

, Mohan V Jacob

¹^,^∗

1Electronics Materials Lab, College of Science and Engineering, James Cook University, Townsville, QLD, 4811, Australia

2College of Science and Engineering, James Cook University, Townsville, QLD, 4811, Australia

a rt i c l e i n f o

Article history:

Received 28 March 2022 Revised 14 June 2022 Accepted 27 June 2022

Keywords:

Atmospheric pressure microwave plasma nitrogen-doped graphene oxide oxalic acid

electrochemical sensor

a b s t r a c t

Theadverseeffects ofoxalicacid(OA)onhumanhealth linkedwithitsexcessiveconsumptionneces- sitatesan improvedsensor. Here, wedemonstratean electrochemical sensor foroxalic acid detection basedonsilvernanoparticles (Ag-Nps)and nitrogen-dopedgraphene oxide(N-GO)nanocomposite. N- GO,whichwassynthesizedusingatmosphericpressuremicrowaveplasmahasbeenﬁrsttimeemployed forelectrochemicalapplication.Thenanocompositeformationwasconﬁrmedthroughscanningelectron microscopyand EDSelemental analysis.Thenanocomposite-basedsensor showedahighercurrentre- sponse,good selectivity and stability whichcan beattributed tothe synergistic-effect of Ag-Npsand N-GO.AmperometricresponseswereproportionaltotheconcentrationofOAbetween10and300μ^M, andthedetectionlimitwas2μ^M.

ThisisanopenaccessarticleundertheCCBY-NC-NDlicense (http://creativecommons.org/licenses/by-nc-nd/4.0/)

1. Introduction

Oxalic acid (OA) isfound naturally ina wide rangeof plants, animals, andmicroorganisms. Theexcessiveness ofOAin thehu- manbody isconsidered risky forhumanhealth.Forinstance,OA can react with magnesium, potassium, and iron to form insolu- ble oxalate salts,and can remove calcium fromthe blood which leads to kidney stones or can interfere with the heart or ner- voussystem[1,2]. Consideringaboveharmful effects,theUSde- partmentofagriculture(USDA)recommendsacertainlimitofOA daily intake for humans. For example,in 1 g serving ofspinach, the OAamountshould not beabove 9.7mg[3].Thus, thedetec- tion ofOA infoodsandurine garnered thesigniﬁcant interest of scientists.

The electrochemical methodforthe determination ofOA, sur- passes conventionally used techniques, such as spectroscopy [4], chromatography[5],andenzymaticmethods[6]becauseofitslow cost,fastprocedure,goodselectivity,andhighsensitivity[7,8].Al- thoughmanyelectrochemicalsensorshavebeendevelopedforOA detection[9],asensingplatformwithinexpensivepreparationand

∗Corresponding author:

E-mail address: [email protected] (M.V. Jacob) .

high analytical performance including high sensitivity and good stabilityisstillhighlydesirable.

Graphene-based composite materials, such as Pt-Pd nanoparticles/chitosan/nitrogen-doped graphene [10], silver nanorods/graphene nanocomposite [11], Pd/rGO composite [12], gold nanoparticle/polypyrrole reduced graphene oxide [8], grapheneaerogel[13],graphene(GR)-modiﬁedcarbonionicliquid electrode[14],platinumnanoparticle loadedgraphenenanosheets [15],andPd/AuAlloyNps onionicliquidfunctionalizedgraphene ﬁlmhavebeeninvestigatedforOAdetection[16].Althoughthese materials exhibitedhighcatalytic activities towardsOA oxidation, the usage of expensive metal Nps, such as Au, Pd andPt raised thecostofthesensor.Silvernanoparticles(Ag-Nps)arepromising alternatives inthisrespect,asthey are lessexpensivethan those precious metals and can achieve comparable electroanalytical performance for the detection of OA. For OA detection, Ag-Nps hasbeen used incomposite withgraphite [17] or graphene[11]. However, lengthy chemical synthesis procedures were utilized to makethecomposites[18].

Inthiswork,weusedAg-Nps/N-GOmodifiedGCEsensorforOA detection. N-GO which wassynthesized using atmospheric pres- suremicrowaveplasmahasbeenfirsttimeutilizedinelectrochem- icalsensorapplication. Tomakea nanocompositeofAg-Npswith N-GO,afastandefficienttechnique,i.e.electrodepositionwasem- ployed. Attributed to the synergistic-effect of Ag-Nps and N-GO https://doi.org/10.1016/j.cartre.2022.100188

(2)

wasusedthroughouttheinvestigation.

2.2. Instrumentation

Confocal laser Raman spectroscopy (Witec,532nm laser) and scanningelectronmicroscopy(SEM)(HitachiSU500)wereusedto characterize the samples. Electrochemical experiments were performed ona PalmSens4(Palm InstrumentsBV,The Netherlands) potentiostatequippedwithathree-electrode systemconsistingof aglassy carbonworkingelectrode(GCE),aplatinumcounterelec- trode,andanAg/AgClreferenceelectrode.Toinvestigatetheelec- trochemical performance of the bare and modiﬁed GCE, electrochemical impedance spectroscopy (EIS), cyclic voltammetry(CV), andamperometrictechniqueswere employed.CVofOAwascon- ductedin0.1Mphosphatebuffersolution(PBS)(pH7.0).EISwas recorded inafrequencyrangeof 0.1Hzto100 kHzina solution containing0.1MKCland5mMK₃[Fe(CN)₆].

2.3. Synthesisofnitrogen-dopedgrapheneoxide

The synthesis of Nitrogen-doped graphene oxide (N-GO) was carriedoutinatmosphericpressuremicrowaveplasmaasreported earlier[19].Aniline precursor withoutanymodiﬁcationwasused tosynthesize nitrogen-dopedgrapheneoxideinasingle-step.The microwave plasma systemmainly consisted ofa microwave gen- erator (2.45GHz),matchingnetworkandaquartz tubeasshown schematically in Fig.1. Aniline wassuppliedfromthe top ofthe tube using a homemade aerosolsystem. Argon gas wasused as a carrierfor anilinevapours. As soon as the anilinevapours en- teredintotheplasmaglow,thebreakdownstartedoccurringwhich resultantly formed N-GO on the walls of the reaction chamber.

Thesynthesiswasconductedatoptimizedconditionsofmicrowave power, aniline ﬂow rate and fabrication time, i.e. 80 W, 3 litre per min and3minrespectively. The N-GOwaswashedfromthe walls of the chamber using ethanol and was collected in a vial for thesensor application. A well-homogenisedsolution of N-GO in ethanolcan be observed inFig. 1.Toinvestigate thestructure andmorphology ofN-GO, samples were collecteddirectly onthe siliconsubstratefromthereactionchamber.Additional characteri- zationsofN-GOisreportedinourpreviouswork[19].

2.4. Preparationofthemodiﬁedelectrode

1 mg/mLsolution ofN-GO waspreparedin ethanolfor drop- casting on GCE. Before modiﬁcation, GCE (3 mm diameter) was polished with0.3

μ

^m ^and^0.05

μ

^m^alumina ^slurryconsecutively, followedbyultrasoniccleaninginethanolandwater.Analiquotof 4

μ

^L^N-GO^solution^wasdrop-castedonGCEanddriedunderroom

Fig. 1. Schematic illustration of N-GO synthesis in atmospheric pressure microwave plasma.

conditions.Electrodepositionwasconductedina1mMKNO₃solu- tioncontaining0.1mMAgNO₃andat-0.2V(vs.Ag/AgCl)potential for350sec.TheprocedureschemeisshowninFig.2.

3. Resultsanddiscussion 3.1. N-GOcharacterization

The structural quality of N-GO nanosheets deposited on sili- consubstratewasanalysedusingRamanspectroscopy.TheRaman spectrumshowninFig.3arepresentsthree vibrationalmodesi.e.

defectmodearound∼1334cm⁻¹(Dpeak),verticalvibrationmode around ∼1576 cm⁻¹ (G peak), and two-phonon vibration mode centred at ∼2677 cm⁻¹ (2D peak) [20]. The D peak forms due to the scattering of phonons at the boundary of the disordered hexagonal Brillouinzone; theG peak arisesfromthe in-plane C- CstretchingvibrationundertheE2gmode[21–23].

The intensityratioofD andG peaksi.e.I_D/I_G isgenerally as- cribedtothedefectsingraphene.However, dopingmaterials also contributetowardshigherratiosofI_D/I_G [24,25].Similarly,inthe presentwork,theN-GOindicatedarelativelylargervalueofI_D/I_G, i.e.0.91[26].Accordingtotheprevious reports,thiscouldbedue to thenon-hexagonal rings, functionalities, orheteroatomdoping [27].Thus, itcould be interpreted thatthe functionalgroupsand N-doping were responsible for a higher value of I_D/I_G. Li et al.

[28] also observed that theN-doped graphene produced a larger I_D/I_G ratioincomparisonto pristine graphene. Theyascribedthis totheformationofsp³-CinpyrrolicN-dopedgrapheneconsisting ofﬁve-atomheterocyclicring.

The2Dpeak isusually identiﬁedasthesignatureofgraphene.

The intensity ratio between 2D and G peaks i.e., I_2D/I_G and full widthathalf-maximum(FWHM)are usuallyrelatedtothequan- tityoflayersingraphene[29].TheFWHMof∼50cm⁻¹andI_2D/I_G values between 1 to 1.5are commonly associated with the two layers of graphene[30, 31]. In the currentwork, the N-GOsam- ple demonstrated FWHMand I2D/IG valuesof 68 cm⁻¹ and0.81 respectively, suggestive of multiple layers N-GO.Notably, the ex- istenceofNdopantsin graphenecan inﬂuenceboth peaks,i.e.D and2D.N-dopingenlargestheDpeakontheonehand,andonthe otherhand,itincreasestheelectronscatteringrate,whichlessens theintensityofthe2Dpeak.[31].N-GORamanspectrawascom- paredwith that of GO and rGO [32] given in the literature. The

(3)

Fig. 2. Ag-Nps/N-GO/GCE modiﬁed electrode preparation scheme.

Fig. 3. (a) Raman spectrum and (b) SEM image of N-GO sample.

higherDpeakinGOincomparisonwithrGOruledoutanyreduc- tionoccurringontheGO.

TheSEMimage oftheN-GOsampledepositedstraightawayon asiliconsubstrateisdisplayedinFig.3b.Thehorizontalﬁlmswere not found in theimage;however, thesample showed3D islands similartowrinkled-paperlikestructuresspreadacrossthesurface of thesubstrate [22]. Theseislands consistedmainly of multilay- eredN-GOstructures.

3.2. Electrodecharacterization

ThesurfacemorphologyoftheAg-Nps/N-GO/GCEelectrodewas analysed usingSEM, displayedin Fig. 4a. Successfulelectrodepo- sition of Ag on N-GO can be observed in the images. The SEM image showsthe uniformity inthe distribution of Ag nanoparti- clesontotheN-GO/GCEelectrode.Themagniﬁedimageinthein- set showsan aggregationofAg-Nps, whichis ingoodagreement with the previous reports [33, 34]. Furthermore, the presence of Ag as well as other elements, including carbon (C), oxygen (O), and nitrogen(N) whichcame from anilinewas revealedthrough energy-dispersiveX-rayspectroscopy(EDS).TheEDSspectrumand elementspercentagesaredelineatedinFig.4b.

3.3. Electrochemicalanalysisofelectrode

Theelectrochemicalperformanceofthemodifiedelectrodewas investigatedusingEIS.Fig.5exhibitstheNyquistplotsofbare,N- GOandAg-Nps/N-GOmodifiedGCE.ThefittedRandlesequivalent circuitis showninthe Fig.5inset. Thelinear regionsof plotsat lowfrequencies implicate thediffusionprocess, whereas,semicir- clesathigherfrequenciesareassociatedwiththeelectron-transfer reaction [35, 36]. The charge-transfer resistance (Rct) of the bare GCE and the N-GO modified GCE was found to be 206 ând 1.2k^, respectively,indicating theslowelectron-transfer kinetics atthe N-GOfilmsurface. However, afterelectrodeposition ofAg- NpsonN-GOfilm,theRctofN-GOdecreasedsignificantlyto∼653 ^,^which^can^be âttributed^to ^the^highelectrocatalyticactivityof the Ag-Npsdeposited atthe surface of the electrode. High elec- trocatalyticactivityofAg-Npsisduetothelargesurfacearea,and outstandingelectronicconductivity.Inaddition,theaggregatedAg- NpspossessporousnetworkoftheAg-Npsfacilitatethediffusion process[37].

CVwasperformedtoinvestigatetheelectrochemicalbehaviour ofthe bare GCE,N-GO/GCE andAg-Nps/NGO/GCE towards oxida- tionof0.1mMOA(Fig.6). Therewasan inadequateresponsefor

(4)

Fig. 4. (a) SEM image (high resolution in inset) and (b) EDS of Ag-Nps/N-GO/GCE modiﬁed electrode.

Fig. 5. EIS spectra for (a) bare GCE (b) N-GO/GCE (c) Ag-Nps/N-GO/GCE in a solution of 0.1 M KCl and 5 mM K 3[Fe(CN) 6] with the frequencies swept from 0.1 Hz to 100 kHz.

OAoxidationfrombareGCE,whileN-GO/GCEexhibitedacompar- ativelyimprovedresponse.Noticeably,Ag-Nps/N-GO/GCErevealed aremarkableoxidationprocess,suggestingthatAg-Nps/N-GO/GCE considerably catalyses the OA oxidation response. It can be attributed tothe synergistic effectof bothAg-Nps andN-GO.They possess excellent conductivity andenormous surfacearea, which canacceleratetheelectron-transferkineticsandaccommodatethe OAmoleculesatthesurfaceoftheelectrode[38].

Theelectrochemicalreactionmechanismreliesonthenatureof the modiﬁedmaterials [9]. An acceleratedoxidation reaction has been observed when OA molecules have strong interaction with the electrode surface. OA has limited absorptive ability withthe GCE, which slowed down the oxidation process at the surface.

However, metalscatalysestheoxidationprocess.Withmetals,the

reaction mechanism involve electro-oxidation of OA, which pro- ducescarbondioxideandhydrogenions.Ithasbeenreportedthat theoxidationofOAisbasedontwoelectrons,twoprotonmecha- nismtoformcarbondioxide[7,17].Theproposedreactionisgiven below.

H2C2O4→2CO2+2H⁺+2e⁻

3.4. AmperometricdetectionofOA

Fig. 7a exhibits the amperometric response of the Ag-Nps/N- GO/GCE on the successive addition of 2 μM to 300 μM OA into 0.1 M PBS (pH 7) stirredsolution. An optimal potential of1.2 V wasusedforthe detectionofOA owingto the highestsignal-to-

(5)

Fig. 6. CVs of bare GCE, N-GO/GCE, and Ag-Nps/N-GO/GCE in 0.1 M PBS (pH 7) containing 0.1 mM OA, scan rate 50 mV/s.

noiseratio.Itcanbeobservedthatafastandstableresponsecould be obtainedafter each injectionofOA. Acalibration curve ofOA concentration versus currentresponseisdisplayedinFig.7b.The plot shows that the Ag-Nps/N-GO/GCE can detect OA in the lin- earrangeof10– 300μM;wherethelinearregressionequationis y= 0.0552x+ 3.7385 (R²=0.9989).Thesensor showedan excel- lentlimitofdetectionof2μM.Thecommendableelectroanalytical performance ofthe sensor can be ascribed to thecombined cat- alyticactivityofAg-NpsandN-GO[39].Table1showsthecompa- rableresultsofthelinearrangeandlimitofdetectionwiththose ofdifferentOAsensorsreportedearlier.

3.5. Reproducibility,repeatabilityandstabilityoftheelectrode

To fabricate commercialdevices it is importantthat theelec- trode has signal responses which are reproducible and repeat- able. Moreover, the electrode should be stable for longer period

Fig. 8. Amperometric response of Ag-Nps/N-GO/GCE towards OA (50 μM), ascorbic acid (100 μM), glucose (50 μM) and uric acid (100 μM) in 0.1 M PBS at 1.2 V.

oftime.WeinvestigatedAg-Nps/N-GO/GCEsforitsreproducibility.

Fourelectrodeswereemployedforthispurposeandcyclicvoltam- mograms were obtained in a 0.1 mM OA solution. The relative standard deviation (RSD) was calculated to be 5.8%, which indi- catedreasonablereproducibilityofthesensor.

The repeatability measurements were performed with one of the Ag-Nps/N-GO/GCE electrodes. Four successive measurements wereperformedin0.1mMOAsolution.Thecyclicvoltammogrms are shown in Fig. S1. The RSD calculated from these voltammo- gramsis3.4% whichshowedgoodrepeatabilitybehaviour ofthe proposedOAsensor.Weattributethistotheexcellentanti-fouling propertiesofgraphene-basedmaterials.Similarly,N-GObasemate- rialplayedcriticalroleonenhancingthestabilityoftheAg-Nps/N- GO/GCE.A1weekand2weeksstabilitytestswerecarriedoutin 0.1mMOAsolutionwhichyielded97%and95%oftheinitialcur- rentvalues,respectively.Thesevaluesshow theexcellentstability oftheelectrode.

Fig. 7. (a) Amperometric response of the Ag-Nps/N-GO/GCE in stirred 0.1 M PBS with sequential injections of OA at 1.2 V potential (b) Calibration curve showing OA current response against its concentration.

(6)

3.6. Interferencestudy

TheamperometricresponseoftheAg-Nps/N-GO/GCEelectrode atan appliedpotential of1.2Vwasmeasuredfor50μMOA,fol- lowed by separate additions of 100 μM of ascorbic acid, 50 μM of glucose, and 50 μM uric acid into a stirred 0.1 M PBS solution. Theseinterfering compounds were chosen because they are likelytocoexistwithOAinurinesamples[1].AsshowninFig.8,a strongandfastcurrentsignalwasobservedatAg/N-GO/GCEelec- trode aftertheinjectionofOA,however,therewasoncurrentre- sponsetoascorbicacid,glucose,anduricacid,whichdemonstrates thegoodselectivityoftheproposedsensor.Additionally,againthe prominentandimmediatecurrentresponsewasdetecteduponthe addition of 50 μM OA which can be seen at the ﬁnal stage of theplot.Thisamperometrytestdemonstratesasatisfactorysensor- interferencebehaviouroftheAg-Nps/N-GO/GCEelectrode.

4. Conclusion

In a nutshell, the combination of Ag-Nps and N-GO for OA detection is a superior alternative to the particularly expensive metals modiﬁed electrodes. The ﬁrst time usage ofN-GO in this work, which was prepared through a single-step and rapid syn- thesisroute,notonlymadetheoverallelectrodepreparationfacile andquickbutalsoenhancedtheelectrodesensingproperties.Ow- ing to the synergistic-effect ofAg-Nps andN-GO, the Ag-Nps/N- GO/GCEsensor showedacomparablelinear rangei.e.10-300μM and an excellent detectionlimit of2 μMin an amperometric investigation.Theadmirableselectivityagainstascorbicacid,glucose, and uric acid proves the superiorityof the sensor. Attributed to thegrapheneinherentcharacteristics,remarkablerepeatabilityand stabilityofthedesignedsensorhavealsobeenobserved.

Declarationofinterests

Theauthorsdeclarethattheyhavenoknowncompetingﬁnan- cialinterestsorpersonalrelationshipsthatcouldhaveappearedto inﬂuencetheworkreportedinthispaper.

Acknowledgement

M.A.Z. gratefully acknowledges ﬁnancial support through the Australian Government International Research Training Program Scholarship.

Supplementarymaterials

Supplementary material associated with this article can be found,intheonlineversion,atdoi:10.1016/j.cartre.2022.100188.
