Processes for Low- Level Asbestos
Contamination in
Occupied Workplace Buildings
T H I S W O R K B Y E S R C I S L I C E N S E D U N D E R A C R E A T I V E C O M M O N S A T T R I B U T I O N -N O N C O M M E R C I A L-N O D E R I V A T I V E S 4 . 0 I N T E R N A T I O N A L L I C E N S E .
- : , & -
C o A u th o rs F re d Pa u D a n B la n c h o n Te rri A n n B e rry
U n ite c In stitu te o f T e ch n o lo g y
Shannon Wallis
, &
ESRC Unitec Institute of Technology University of
Canberra
A s b e s to s
Serpentinite with asbestos crystals, asbestos mine tailings, Upper
Takaka River, Kahurangi National Park (Dr Peter de Lange)
? W h a t is it
• Fibrous silicate-based mineral composed of long and thin fibrous crystals.
• Found throughout the world.
• Mined for its physical and chemical properties.
• Serpentine
• White (Chrysotile)
Rare Asbestos Types
• Actinolite, Anthophylite, Tremolite
• Brown/grey (Amosite) • Blue (Crocidolite)
• Amphibole s
• “Asbestos” is a commercial / regulatory term
• Refers to the six
natural minerals
? W h y is it u s e d
• Physical and chemical properties:
• High mechanical strength (7x stronger than steel)
• Heat and fire resistance – thermal insulator
• Resistant to most chemicals
• Cheap
• High tensile strength
• High acoustic insulation
Scanning electron photomicrographs (SEM) of two members of amphibole and serpentine asbestos family, respectively (a) the
crocidolite or blue asbestos, (from Koegas, South Africa), and (b) the
Canadian B chrysotile
? W h y is it to x ic
• Issue – breathing in of the fibres
• Fibre hazards linked to size, and chemical and physical presence in the lung tissue.
• Fibre size = >5 µm long & <3 µm wide
• Current standards for asbestos assume fibres <5 µm pose no danger.
• Fibres of this size travel down through the
air passages into the alveoli, fibres lodge in
the tissue, the body reacts to dislodge the
foreign material, which causes scarring.
A s b e s to s R e la te d D ise a s e s
• Three fatal and four non-fatal diseases
• Non-fatal:
• Pleural plaques – calcium deposits build up in the rib cavity
• Pleural thickening – diffuse fibrosis in pleura
• Pleural effusions – fluid build up in membrane cavity
• Asbestos warts and corns – fibres embedded below skin surface
• Fatal:
• Asbestosis – fibrosis/hardening of the lung tissue.
• Considerable exposure is needed over time
• Lung Cancer – malignant tumour growth – uncontrolled cell growth in the lung tissues.
• Asbestos exposure and a smoker? 53x higher incidence of lung cancer
• Mesothelioma – Cancer tumour of the pleura membrane of the lung.
• Small exposure can cause it
• Disease development has a latency period – 15-60 years
M e s o th e lio m a N u m b e rs
• Of those affected:
• 40% - plumbers, fitters, electricians, laggers
• 23% - carpenters, builders, asbestos cement workers
1970 0 1980 1990 2000 2010 2020 2030
20 40 60 80 100 120 140 160 180
New Zealand Registered Mesothelioma Cases
Year
N um be r of m es ot he lio m a
A s b e s to s C o n ta in in g M a te ria ls
• Over 3,000 products
• Loose insulation
• Spray coatings
• Thermal insulation (pipe lagging)
• Millboard
• Asbestos insulation board (AIB)
• Paper, felt & cardboard
• Textiles
• Textured coating (Artex)
• Gaskets
• Brake pads & clutch plates
• Cement products
• Floor tiles
• Plastic and composite products
Loose insulation Sprayed limpet
Thermal insulation - Pipe lagging
Millboard
Images from UK HSE Perforated AIB – ceiling tiles
AIB – soffit
Asbestos roofing Asbestos fire blanket
Textured coating
G lo b a l U s e
• >200 million tonnes mined (since 1900)
• 1975 production – 4.2 million tonnes
• 2003 production – 2.15 million tonnes
• 2013 Production – 2 million tonnes
• Most countries are reducing production, there are some exceptions. (Virta R.L., 2006)
The Wizard of Oz – Pure asbestos as “snow”
Unconventional products:
W a v e s o f A sb e sto s E x p o su re
(Data based on Landrigan, 1991)
International Ban Asbestos Secretariat
67 (out of 196) have banned all forms of asbestos (Kazan-Allen, 2019)
(EWG Action Fund, n.d.)
Legislation & Guidelines
C o n ta m in a tio n M a n a g e m e n t
• Governed by:
• Approved Code of Practice (WorkSafe 2016) - Management and Removal of Asbestos
• Health and Safety at Work (Asbestos) Regulations (2016)
• Three types of surveys
• Management Survey
• Refurbishment Survey
• Demolition Survey
required AMP No AMP
required AMP should
be required Rental
Home Office
REGULATED UNREGULATED
*AMP – Asbestos
Management Plan
C o n ta m in a tio n M o n ito rin g
• How do we test?
• Swab sampling
• Air testing
• Static
• Disturbed
R e s u lts In te rp re ta tio n
• What is safe?
• Permitted levels
• Trace level < 0.01 f/ml
• Workplace Contamination Standard (8-hour time weighted average) = 0.1 f/ml
• With PPE/RPE – 2-4 f/ml
• Microscopy
• PLM and PCM
• Not every fibre = asbestos
• TEM
• Background asbestos levels
• It is everywhere! (Hill Laboratories)
Conclusion
• Comprehensive understanding of
theoretical management and routine asbestos removal.
• Unmonitored compliance around asbestos management.
• What needs to change?
• Policy changes – surveillance testing and
asbestos management
