DUST COLLECTOR SYSTEM UNTUK PPBT UNMET

Tgl. / Date

:

10.10.2014

Tanggal Penutupan / Closing Date : 20.10.2014

Jam / Time : 12:00:00

Pos/Item ; Kode Stock/Stock Code (No.SPP/Req.No.) ; Uraian/Description ; No.Part/Part.No. Satuan/ Unit Banyaknya/ Quantity Harga Satuan/ Gross Unit Price

Pot./ Disc. (%) W.serah/ L.Time (hari/day) 0000000001

Dust Colector Rotary Dryer

To supply one unit of packed columnfume scrubber system integratewith venturi scrubber

aspre-separator and quencher as perdescription below:

-Design capacity of scrubber : 85m3/min (3,000ft3/min)

-Type of scrubber recommended : Packed Column Scrubber

-Type of fumes : Acidic fumes with sand dust an fly ash

-Dimension :Ø 900mm x 4,650mm Ht.

-Pressure drop across scrubber: Approx. 75mmm H2O -Packing element : 3.5" Lanpac (P.P)

-Packing height : 2,000mm

-Type of mist eliminator : no. 1 Type R Tellerette (P.P) or eqivalent

-Material of construction ;Fully fiberglass (Vinyl Ester)

-Reagent recommended ; NaOH solution

-Accessories : 570Liter sump tank for reciculation water

Specification of Venturi Scrubber -Design capacity of scrubber : 85m3/min (3,000ft3/min)

-Type of scrubber recommended : Venturi Scrubber -Type of particle/fume : Acidic fumes with sand dust

and fly ash

UNT 1

(2)

Pot./ Disc. (%) W.serah/ L.Time (hari/day) -Dimension :Ø 350mmm x 2,200 mm Ht

-Material of construction : Fully Fiberglass (Vinyl Ester)

-Pressure drop across scrubber : Approx. 125mm H2O -Collection efficiency:99% @ 3microns

1.2 To supply one lot of PVC SCH 80 standard piping

and fittings for spray nozzle

1.3 To supply one unit of chemical resistance centrifugal fan c/w

Type : Belt Driven Air Capacity : 85m3/min Static Pressure : 275mmAq

Construction material : Casing and Impeller - FRP Motor power : 15HP; 415V/3ph/50Hz

Motor Degree of protection :IP 55

Impeller Balance : ISO1940 -Standar_G2.5mm /s_Rank Mechanical Vibration : ISO2372-Standar_4.5m/s_Rank Sound Level : lebih kecil 85dB at 1.0M

1.4 To supply two units (one run;One standby) of chemical resistance pump c/w PVC Sch.80 piping

and fittings as specificattion below for above said

scrubber system :

Type : Vertical Sealess Dhemical Resistance Pump Capacity : 180 Liter/min

Head : 10m

Material : FRPP (Wetted part) Motor : 3HP;415V/3ph/50Hz

1.5 To supply one lot of Ø 400mm FRP inter-connecting

ducting from

(3)

INDONESIA

PELELANGAN TERBUKA

Surat Permintaan Harga (SPH) / Request For Quotation (RFQ)

:

B-TU003545 / 5100001455

Tgl. / Date

:

10.10.2014

Jam / Time : 12:00:00

Pot./ Disc. (%) W.serah/ L.Time (hari/day)

1.6 To supply one lot of Ø 400mm FRP chimney which 8meter

1.7 To supply l one lot of control instrument for above

system as

Differential Pressure Gauge Type : Magnehelic

Range : 0"-6"W.G. Quantity : 3pcs

Recirculation Water Pressure Gauge Type : Analog Local Display

Range : 0-6 bar Quantity : 1 pc

Recirculation Water Rotameter Type : Analog Local Display Range : 80-400 LPM

Quantity : 1 pc Air Steam Temperatur Gauge Type : Analog Local Display

Range : 0 - 100oC Quantity : 1pc

1.8 To supply and install one set of pH control system

consist

1.9 To supply six units of suction hood as shown /

specified in drawing

1.10 To upply one lot of labors and tools to carry out

the following

a. To Supply labors and tools to carry out on site Jumlah Pos / Total Number of items : 1

(4)

Pot./ Disc. (%) W.serah/ L.Time (hari/day) commissioning

b. 2 stes of miantenance and operation manual for the system

1.11 To supply one lot of weatherproof type control

panel for

Exclusion :

-Rountine maintenance of above system -Electrical wiring from factory DB to system control

panel

-Civil and mechanical work not specified in the proposal

-Incoming city water and drainage piping for the above said system

-Any offer/item not specified in the proposal

Catatan :

-Franco Gudang Mentok

-Memberikan garansi pemakaian -Biaya pemasangan dan commisioning

-Penyerahan barang dilengkapi certificate of origin

of manufacture

-Menyerahkan design Dust Collector detail
