ASUS SERVER WORKSTATION POWERED BY ASUS MOTHERBOARD

(1)

ASUS SERVER & WORKSTATION

POWERED BY ASUS MOTHERBOARD

- ASUS World’s No.1 Motherboard Brand

SERVER & WORKSTATION

(2)

ASUS adalah salah satu World’s Most Admired Companies menurut Fortune Magazine, ASUS berdedikasi menciptakan produk smart-life hari ini dan esok. Portofolio komprehensif kami meliputi Zenbo, Zenfone, Zenbook, termasuk berbagai perangkat dan komponen TI, dan juga AR, VR, dan IoT.

ASUS mempekerjakan lebih dari 17.000 orang di seluruh dunia dan lebih dari 5.500 pekerja world-class R&D. Didorong oleh inovasi dan komitmen pada kualitas, perusahaan ini telah memenangkan 4.385 penghargaan dan menghasilkan pendapatan sekitar US$ 13.3 miliar pada tahun 2016. Memiliki pengalaman lebih dari 23 tahun membangun high quality performance servers dan workstations

Menerima 67 pemecahan rekor benchmark dunia untuk performa 2P server tercepat*

Peringkat No. 1 in 2014 pada daftar Green500 energy-efﬁcient supercomputers

Salah satu dari dua produsen server yang memenangkan 2017 Computex Best Choice Award

(3)

Server

• Fungsi

Melayani service jaringan, perkantoran, edukasi, dll

• GUI

Optional

• Performa

Menangani beban berat dalam periode yang lama

• Fungsi

Business, Design, Engineering, Multi-Media Production

• GUI

Terinstal

• Performa

Memiliki multimedia dan sangat baik digunakan untuk

aplikasi graphic atau video

• Fungsi

Umum (internet, perkantoran dsb)

• GUI

Terinstal

• Performa

Baik dan didesain untuk kerja 8 jam x 7,

bukan untuk menangani beban berat dalam periode lama

Merupakan komputer induk dari semua komputer yang

terhubung pada jaringan yang menangani pengolahan,

pendistribusian dan penyimpanan data secara terpusat.

PC

(Personal Computer)

Merupakan komputer yang oleh perseorangan sehari-hari

digunakan di rumah atau perkantoran

Workstation

(4)

Enterprise Solutions

o Cloud (ISP)

o Retail

o E-commerce

o IT Security

o High Performance Computing

SMB Solutions

o IT Security

o Private Cloud

Education Solutions

o E-classroom and Cloud Education

o AI and Deep Learning

Server&Workstation

(5)

Mengapa memilih ASUS Server

• Memiliki PCI Express x16

yang mendukung

GPU card

• Hotswap hard disk lengkap

dengan tray atau

bracket-nya.

• Free Remote management (ASUS-iKVM) pada dual soket processor

• Free Software ASWM Enterprise untuk monitoring status server.

• Upgrade ability komponen server (hard disk, memory)

• Garansi 3 Tahun part, labor, onsite area Jaka

rta, Semarang,Yogyakarta, Surabaya,

Bandung, Medan, Makassar, Balikpapan dan beberapa kota besar lain.

internet

Server

Kemdikbud

Server UNBK

Switch

LAN 2

LAN 1

(6)

ASWM Enterprise - In-Band Management

Management

ASWM Enterprise - System Web-based Management

• Colorful, graphical, and informative interface

Allows MIS to conveniently monitor servers remotely (using a web-browser)

ASUS Server Overview

Client Information

• Asset Management

(7)

No Nama Partner City Address Contact No

1 CV MADINAH Aceh Jl. Mata Ie No.8- Gp. Punie, Kec.Darul Imarah, Aceh besar 0852-1728-5956

2 ITSC MEDAN Medan Jl. Asia Raya Blok N No. 30A Komplek Asia Mega Mas 061-7353064

3 BAYES COMPUTER Padang Jl. Gajah Mada No.17 (Olo Nanggalo) Gunung Pangilun 0821-7117-7804

4 RUN GROUP Pekanbaru Jl. Proyek Baru No. 85/87 Tj. RHU - Pekanbaru, Riau 0823-8859-6405

5 NI COMPUTER Pangkal Pinang Jl. Linggarjati No.163, Pangkalpinang 55123 Babel 0717-432230

6 CV ALAM PRIMA Lampung Jl. Diponegoro No.120 Teluk Betung Bandar Lampung 0721- 486126

7 ITSC JAKARTA Jakarta Jl. Balikpapan Raya No. 11C-D Jakarta Pusat 10160 021-3850200

8 CV. MITRA INDEXINDO Cirebon Jl. Panjunan No.79B 0231-24556

PRATAMA

9 ITSC BANDUNG Bandung Jl. Phh. Mustofa No 39 , Ruko Surapati Core Blok M – 26 022-42690241

10 ITSC SEMARANG Semarang Jl. MT Haryono No. 824, Semarang, Jawa Tengah 50124 024-8452581

11 ITSC YOGYAKARTA Yogyakarta Jl. Gajah Mada no. 58 Yogyakarta 0274-523231

12 ITSC SURABAYA Surabaya Jl. Embong Malang No. 75A, Surabaya, Jawa Timur 031-5346045

13 ITSC DENPASAR Denpasar Jl. Kecubung No.18 Br. Pande Kel. Sumerta Kaja 0361-8948632

14 CV DUTA MULTI Kupang, NTT JL. Raya Wolter Monginsidi 3, Blok A No.21-22, Oebobo 0380-828333 COMPUTER

15 PT ERA MANDIRI Pontianak Jl. Alianyang No 10 D Pontianak (0561)768001

KOMPUTER

16 CV MITA SOLUTION Banjarmasin Jl. A. Yani Km. 1 No. 19A, Banjarmasin 70233 0511-3251672

17 ITSC BALIKPAPAN Balikpapan Mall Balikpapan Jl. Jendral Sudirman Blok J2 No. 6 0542-440970

18 WOW INFORMATIKA Manado Ruko Mega Proﬁt, JL. Raya Pierre Tendean, Blok F No.15 0853-94378899 GREAT POWER COMPUTER

19 IFAH CELL Mamuju Jl. Pabari No. 7 Depan Perum BTN Ampi Mamuju 081242080831

20 EXE COMPUTER Palu Jl. Hangtuah No 55 Palu, Sulawesi Tengah 94111 0852-4112-8000

21 ITSC MAKASSAR Makasar Jl. Toddopuli Raya No. 71B Makassar 0411-3619126

22 GALAXY JAYA Gorontalo Jl. Jendral Sudirman Komplek Gorontalo. Business Centre 0435-8707900

23 PERORANGAN Ambon Jl. Baru Passo Pantai Rt 019/04 Passo Ambon 97232 0823-99112888

24 RUDI SUBEKTI Ternate Kalumata Belakang, RT/RW. 019/06 Kel. Kalumata 0813-40253008

25 CV MANOKWARI Manokwari Jl. Trikora No.135 Wosi, Manokwari, Papua Barat 0986 - 214844

26 IP JAYAPURA Jayapura Ruko Jayapura Pasiﬁc Permai Blok D12-14, Jayapura Papua 0967-531897

ASUS Server Service Center

(8)

Using Scenario for SMB

Solution from ASUS Control Center

Type:

Trading Company

Size: 20 employees

Device: 20 Desktops

MIS: N/A

Background

Type:

Library

Size: 10 employees

Device: 40 Desktops

MIS: N/A

Background

CEO want to monitor conﬁdential

ﬁles and

keep the data safe

Have to

keep information

from being stolen

easily

Issue

Need to

assign people to turn off

PCs

before library close everyday

Key parts in PC

is easy stolen

by user

Issue

Search event log of conﬁdental ﬁles

with

Advanced Search

, monitoring

ﬁles effectively and quickly

Block USB

port on certain devices

efﬁciently

Solution from ACC

Schedule PC to turn off

at 10 PM

everyday saving manpower and

energy easily

Timely check HW

avoiding KP losing

efﬁciently

(9)

ASUS Successful Cases

Winning Point:

3~6%

performance win

by ASUS R&D

professional tuning

Winning Point:

Flexible

customization &

longevity

support

Winning Point:

Right product, customization,

local technical support

Winning Point:

Flexibility

, complete feature

with

outstanding build quality

(10)

ASUS Successful Cases

Cloud Gaming (France)

Application: HPC - Cloud gaming system Products: ESC8000 G3

Mail.Ru Group

Application: Deep learning for search engine Products: ESC4000

GSI Helmholtzzentrum für Schwerionenforschung

Application: 1st Cluster surpassed 5.27 Gigaﬂops/Watt

Theoretical physics simulations in the ﬁeld of quantum chromodynamics.

Products: ESC4000/FDR

Russian software company

Application: Internet Security Software Application Products: RS400-E8-IFO

RS100-E8-IFO

MediaTek, Inc.

Application: EDA

(Electronic Design Automation) Products: RS720Q-E8-RS8-P RS720Q-E8-RS4

Jefferson Lab U.S

Application: Nuclear physics research

Products: ESC4000/FDR G2

King Abdulaziz City

for Science and Technology

Application: Super computer - Sanam Project

(11)

ASUS Successful Cases

Alipc - Call Centre (China)

Application: Cloud Computing / virtualization

Products: RS720-X7/RS8

Hetzner Hosting

Application: Web Hosting & Services Products: Z10-PA U8

German Bundesliga

Application: UK Football League LIVE Products: ESC4000 G3S

Winbond Electronics Corporation

Application: Big Data Analysis Application Products: RS520-E8-RS12-E V2

Education (China)

Application: Digital leaning education application Products: ESC500 G4

Albert Einstein Institute

Application: Atlas Computing Cluster - Gravitational-wave analysis Products: RS100-E8-PI2

Taiwan National

Applied Research Laboratories

(12)

ASUS Successful Cases

Realtek Semiconductor Corp

Application: EDA (Electronic Design Automation) Products: RS700-E8-RS4-C

Korea LCD manufacturing company

Application: LCD Display PCB analysis and production Products: RS200-E9-PS2

National Centre for Nuclear Research

(Philippine)

Application: Nuclear and Physics research and simulation

Products: ESC4000

SYSTEX Corporation

Application: Stock Exchange Application Products: RS100-E9-P12

Korea DMZ Surveillance

Application: Surveillance back-end server Products: RS300-E8-PS4

RS720-X7-RS8

Education (Philippine)

Application: CBT (Computer Based Test Application) Products: TS110-E8-PI4

(13)

Purley Platform Intel DP (PCH: C621)

Z11PA-D8, PCH: C621

(Embedded ASMB9-iKVM) (Giftbox)

Intel® Xeon® server motherboard

with 8 DIMM slots

∙ Powerful performance with Intel® Xeon® Scalable processor and ECC memory

∙ Increased performance or data redundancy with dual M.2 SSDs in RAID mode

∙ High-speed storage interface support with dual OCuLink for NVMe

∙ Connect up to 16 SATA 6Gb/s storage devices

∙ Comprehensive IT infrastructure management solution with ASMB9-iKVM and ASUS Control Center (ACC)

∙ More ﬂexible storage capability with SD card support

∙ Quick initialization guidance for faster BIOS tracking enhancement

MOTHERBOARDS

Server

Workstation

Granley Platform Intel DP (PCH: C612)

Z10PA-D8, PCH: C612

(Giftbox)

Most Compact Dual LGA2011-3

Serverboard

∙ ATX case compatible

∙ The Powerful PCI-E Expandability in 12”x10” Form Factor and MIO-892 audio card support

∙ Mass storage capacity and additional OS storage ∙ Optional PIKE II 3x08 series SAS 12Gb/s solution ∙ Premium components for premium efﬁciency ∙ Quick Initialization Guidance

(14)

Intel UP Entry Mehlow (C242)

P11C-X/AUDIO

(Giftbox)

Intel® Xeon® E ATX server motherboard

with dual M.2 and audio support

∙ Powered by the Intel® Xeon® E platform

∙ 95W CPU and up to 64GB memory support (4 DIMMs)

∙ Rack-optimized design maximizes cooling for excellent thermal efﬁciency ∙ Flexible expandability with 6 native SATA, two PCIe Gen3 slots and two PCI legacy slots

∙ Dual Intel® Gigabit Ethernet with teaming support ∙ Dual M.2 for independent OS drives with RAID 0/1 ∙ Onboard audio for workstation applications

∙ Supports the latest 10Gb/s USB 3.1 onboard for high transfer speed ∙ TPM-M 2.0 support for enhanced platform integrity

∙ Complete server management with ASUS Control Center

MOTHERBOARDS

Server

Workstation

Intel UP Entry (C23X)

P10S-X

Exclusive Combat Model

∙ Cost-effective C232 ServerBoard ∙ Platinum-Grade Power Efﬁciency

∙ Multiple PCI slots reserve the usage ability of legacy PCI devices ∙ Dual Intel® I210AT Gigabit Ethernet

∙ Next-Gen Storage – NVMe Support ∙ Serviceability – Quick Boot

(15)

SMALL & MEDIUM BUSINESS

Add on graphics card

Expansion slots PCI-E / PCI

Drive bays & ODD

Drive Bays Optical drive

Chassis

Form factor

Power Supply

Intel® Xeon® Processor E3-1245 v6 3.7GHz Turbo 4.1Ghz 8MB Cache

4 DIMM slots up to 64GB UDIMM 8 GB UDIMM ECC DDR4

1 M.2 connector , 7 ports SATA3 6Gb/s 1TB SATA 7.2Krpm

Intel® C236 Chipset 2 ports Intel® I210AT GbE Intel® HD Graphics 630

Quadro P600 384 CUDA 2GB GDDR5

1 PCI-E Gen3 x16 (x16 link) 1 PCI-E Gen3 x8 (x4 link) 1 PCI-E Gen3 x1

2x 3.5" internal HDD bays DVD-RW

Small Form Factor (410mm x 96mm x 330mm)

ESC510 G4 SFF

Small Form Factor workstation with the latest

processor, graphics, and storage technology in

ASUS bezel

∙ New ID design on front bezel with ASUS branding

∙ Accelerate to 32Gbit/s data-transfer speeds with M.2 native NVMe supported

∙ Drive three independent displays simultaneously with HDMI, DisplayPort, DVI-D ports

ISV certiﬁed

∙ Best virtual reality experience with NVIDIA® Quadro and AMD® Radeon Pro professional graphic processor (Option)

∙ Powered by Intel® Xeon® E3-1200 v6 and Intel® 7th generation Core™ i7/i5/i3 processor platforms

∙ Built-in dual Intel® I210 Server-Class Gigabit LAN

∙ Improve productivity with ASUS Control Center (ACC) integrated platform

TOWER

Combat Workstation

1

CPU

4

Number

(16)

ESC300 G4

Performance You Can Rely On High

Performance Design with Entry-level Pricing

∙ Affordable workstation based on the Intel® Xeon Greenlow platform with C232 chipset

∙ 5X Protection II — Advanced hardware safeguards for all around protection

∙ Complete server management with ASUS Control Center (ACC) ∙ Ultrafast transfer speeds with M.2 slot

∙ Convenient I/O design

∙ Multiplegraphics card support ∙ PCI slots for legacy device support

∙ Robust security: TPM, BIOS password and chassis lock ∙ User friendly, tool-less case design for hassle-free maintenance ∙ ISV Certiﬁcated

Processor

Add on graphics card

Expansion slots PCI-E / PCI

Drive bays & ODD

Drive Bays

Intel® Xeon® Processor E3-1245 v6, 8 GB DDR4 ECC

4 DIMM slots up to 64GB UDIMM EECC 8 GB UDIMM ECC DDR4

1 x M.2 connector +6 x SATA3 supporting RAID 0,1,10,5 with Intel RSTe 1TB SATA 7.2Krpm

Intel® C232 Chipset 1 Realtek® RTL8111H GbE

Quadro P600

1 PCI-E Gen3 x16 (x16 link) 1 PCI-E Gen3 x16 (x4 link) 2 PCI-E Gen3 x1

3x 3.5" internal HDD bays , 1x internal 2.5" SSD bay DVD-RW

Tower (423mm x 190mm x 435mm)

500 Watt 80 PLUS single Power Supply

TOWER

Mainstream Workstation

(17)

TS100-E9-PI4

High-Performance, entry-level business

server

∙ Socket LGA1151 for Intel® Xeon® E3-1200 v6 processors

∙ High energy-efﬁciency and stability

∙ Complete server management with ASUS Control Center (ACC)

∙ Flexible and convenient connectivity

∙ Built-in dual Intel® I210 server-class Gigabit LAN

∙ USB 3.0 for high-speed external

∙ Easily serviceable design

Processor

Drive bays & ODD

Drive Bays

Intel®Xeon® E3-1220 v6, 3.0GHz 8MB L3 Cache

4x DIMMs slot up to 64 GB 8 GB UDIMM ECC DDR4

6 port SATA 6Gbps supporting RAID 0,1,10, 5, with Intel RSTe 1 TB SATA

Intel® C232 Chipset

2 ports Intel® i210-AT Gigabit Ethernet + 1 Management LAN Aspeed AST2400 with 32MB VRAM

1 PCI-E Gen 3.0 x16 (x16 link) 1 PCI-E Gen 3.0 x8 (x4 link) 4 PCI-32bit/33Mhz

3x 3.5 inch internal HDD bays + 1 internal SSD bay DVD-RW

Tower (380mm x 430mm x 44mm)

TOWER

Mainstream-TOP-selling Server

TS100-E9-PI4

1

4

CPU

Number MemoryNumber

(18)

TOWER

Entry- Level Server

TS300-E9-PS4

Supreme Computing and Expandability for

SMB

∙ ASUS PIKE II & 12G SAS support

∙ High scalability

∙ High networking connection

∙ Best-in-class power efﬁciency and stability

∙ Comprehensive remote management

Processor

Drive bays & ODD

Drive Bays

4 DIMMs slot up to 64 GB 8 GB UDIMM ECC DDR4

2 x M.2 connector (2280/2260/2242) +8 x SATA 6Gb/s ports 1TB SATA3 Enterprise 7.2Krpm

4 ports Intel® i210-AT GbE + 1 Mgmt LAN Aspeed AST2400 with 32MB VRAM

PCI-E x16 (Gen3 x16 link)

1 PCI-E x8 (Gen3 x4 link), and 1 MIO slot 1 PCI 32bit / 33MHz

4x 3.5"/2.5" hotswap bays DVD-RW

Tower (455mm x 217.5mm x 545mm)

TS300-E9-PS4

SMALL BUSINESS

1

CPU

4

(19)

TS500-E8-PS4

Robust Performance with Flexibility to Expand

TS500-E8-PS4 is the mainstream Tower server perfectly built for both workstation and server dual use. It features the latest Intel® Xeon® processor E5-2600 v4 product families, 8 DIMMs, six expansion slots, three 5.25” media bays and single 500W 80 PLUS Bronze power supply. Additionally, as other E8 series server, TS500-E8-PS4 equips the premium components offering up to 94% VR efﬁciency as well as the complete remote management solution. With the extreme computing power and ﬂexible expandability, TS500-E8-PS4 is perfect for growing business applications and individual workstation users.

Processor

Drive bays & ODD

Drive Bays

Intel®Xeon® E5-2620 v4 2.10GHz 20MB Cache Up to 2CPUs

8 DIMMs slot up to 512GB RDIMM/LRDIMM 8 GB RDIMM ECC DDR4

6 ports SATA 6Gbps supporting RAID 0,1,10, 5, with Intel RSTe 1 TB SATA 7.2Krpm Enterprise Storage Hotplug HDD

Intel® C612

3 PCI-E Gen3 x8 1 PCI-E x8 (Gen2 x4 link) 2 PCI-E x16

3x 3.5 inch internal HDD bays + 1 internal SSD bay DVD-RW

TOWER

Medium-Supreme Server

TS500-E8-PS4

MEDIUM & ENTERPRISE BUSINESS

2

CPU

8

(20)

TS700-E8-RS8

Built with Super Speed, Ready for Hyper Scale

TS700-E8-RS8 is designed for dual use server and workstation supporting extreme graphics power, optimized audio performance, BIOS flashback and Q-code logger, an easy-maintenance button. It features the latest Intel® Xeon® processor E5-2600 v4 product families, 16 DIMMs, six expansion slots, three 5.25” media bays and 1+1 Redundant 800W 80PLUS Gold Power Supply. Additionally, as other E8 series server, TS700-E8-RS8 equips the premium components offering up to 94% VR efficiency as well as the complete remote management solution. With the extreme computing power and flexible expandability, TS700-E8-RS8 is perfect for growing business applications and individual workstation users.

Drive bays & ODD

Drive Bays

Intel®Xeon® E5-2630 v4 2.2GHz 25MB L3 Cache, Up to 2 CPUs

9 x SATA3 6Gb/s ports + 1 x M.2 connector, supporting RAID 0,1,10, 5, with Intel RSTe

1TB SATA Enterprise 7.2Krpm

Intel® C612 PCH

4 PCI-E x16 (Gen3 x16 link) 2 PCI-E x16 (Gen3 x8 link)

8x 3.5" / 2.5" hotswap bays DVD-RW

800 Watt 80 PLUS Gold Redundant (1+1) Power Supply

TOWER

Medium-Flagship Server

TS700-E8-RS8

ENTERPRISE BUSINESS

2

CPU

16

(21)

EDUCATION & SMB

RS100-E9-PI2

Zen-quiet Appliance, Magic Capacity

∙ Super quiet green design with lowest as 30 dB

∙ Compact size with 15” depth increasing the density per rack ∙ Complete remote management saving time and efforts ∙ Advanced storage support with dual M.2

Processor Drive bays & ODD

Drive Bays

Intel®Xeon® E3-1220v6 3.5GHz Turbo 3.9Ghz 8MB Cache

4 DIMMs slot up to 64 GB 8 GB UDIMM ECC DDR4

2 x M.2 connector + 4 ports SATA3 supporting RAID 0, 1 1TB SATA Enterprise 7.2Krpm

1 PCI-E Gen3 x16

2x 3.5 inch internal HDD bays Slim DVD-RW

Rackmount 1U (380mm x 430mm x 44mm)

RACKMOUNT

Mainstream Server

(22)

SMALL BUSINESS

RS300-E9-PS4

Flagship Model with Versatile Expandability

∙ Platinum power efﬁciency with up to 94.4% ∙ Optimized thermal design for heat sink and heat pipe ∙ Advanced storage support with dual M.2

∙ Quad Intel I210 Server Class GbE delivering high networking bandwidth

Drive bays & ODD

Drive Bays

4 DIMM slots up to 64GB UDIMM EECC 8 GB UDIMM ECC DDR4

2 x M.2 connector +6 x SATA3 supporting RAID 0,1,10,5 with Intel RSTe 1TB SATA3 Enterprise 7.2Krpm

4 ports Intel® i210-AT GbE + 1 Mgmt LAN Aspeed AST2400 with 32MB VRAM

1 PCI-E x16 1 PCI-E x8

4x 3.5"/2.5" hotswap bays , 2x internal 2.5" HDD/SSD bays Slim DVD-RW

Rackmount 1U 615mm x 444mm x 44mm

400 Watt 80 PLUS Gold single Power Supply

RACKMOUNT

Entry-level Server

(23)

MEDIUM BUSINESS

RS500-E8-PS4

High Efficiency, Future Proof Your Data Center

RS500-E8-PS4 is a 1U rack server that delivers extreme computing power, high memory and storage capacity, as well as highly-ﬂexible expandability. Engineered with premium components throughout, RS500-E8-PS4 provides high dependability and exceptional efﬁciency levels, making it ideal for datacenter deployment, and both small and medium business applications.

RACKMOUNT

Medium-level Server

Processor

Drive bays & ODD

Drive Bays

Intel®Xeon® E5-2620 v4, 2.1GHz 20MB L3 Cache, Up to 2 CPUs

16 DIMMs slot up to 1024GB 8 GB RDIMM ECC DDR4

9 x SATA3 connector supporting RAID 0,1,10,5 winth Intel RSTe, 1 x M.2 connector

1TB SATA3 Enterprise 7.2Krpm

Intel® C612

4x ports Intel® i210-AT GbE + 1 Mgmt LAN Aspeed AST2400 with 32MB VRAM

1 PCI-E x16 (Gen3 x8 Link), 1 PCI-E x16 (Gen3 x8 Link) 1 OCP Mezzanine (Gen3 x8 link)

4x 3.5"/2.5" hotswap bays Slim DVD-RW

(24)

MEDIUM & ENTERPRISE BUSINESS

RS520-E8-RS8

Entry-level Storage Server

RS520-E8-RS8 is a 2U rack server that offers diverse RAID storage, exceptionally-high storage density, an optimized user experience. Engineered premium components for premium efﬁciency, RS520-E8-RS8 is an ideal choice for datacenters and other high-performance enterprise applications.

RACKMOUNT

Supreme Server

Processor

Drive bays & ODD

Drive Bays

1x M.2 connector + 9 x SATA3 6Gb/s ports supporting RAID 0,1,10, 5, with Intel RSTe 1TB SATA Enterprise 7.2Krpm

Intel® C612 PCH

1 PCI-E x16 (Gen3 x8 link), 1PCI-E x8 (Gen3 x8 link) 1 PCI-E x8 (Gen3 x8 link) OCP Mezzanine

8x 3.5" / 2.5" hotswap bays Slim DVD-RW

770 Watt 80 PLUS Platinum Redundant (1+1) Power Supply

(25)

ENTERPRISE BUSINESS

RS720Q-E8-RS8-P

High Efficiency, Future Proof Your Data Center

RS720Q-E8-RS8-P has four nodes, eight CPUs and up to 64 DIMMs, offering up to 112 cores and 4 Teraﬂops Max Theoretical Peak Performance*. This exceptional high-density computing power makes RS720Q-E8-RS8-P the premium choice for situations that demand the highest IO throughput and number-crunching power. * Max Theoretical Peak Performance (DP FLOPS) = 2 sockets x (#cores) x (freq) x (16 DP FLOPS)

RACKMOUNT

Flagship Server

Processor per Node

Processor Number

System memory per Node

Memory Slots Installed

Storage per Node

HDD installed

Expansion slot per Node

PCI-E Gen 3.0 x16 PCI-E Gen 3.0 x6

Onboard devices per Node

Chipset

480 SATA 3 SSD Enterprise

1 PCI-E Gen 3.0 x16 (Gen3 x16 Link) 1 PCI-E x8 (Gen3 x8 link), proprietary

Intel® C612 PCH

8x 2.5" hotswap bays (2 bays per node) Up to 4 Nodes

2000 Watt 80 PLUS Titanium redundant (1+1) Power Supply

(26)

Comprehensive and Effortless IT Management

A

SUS

C

ontrol

C

enter

Hardware to Software,

Physical to Virtual

Easy Search and Control

of Your Devices

Enhance Information Security

Easily and Quickly

Power Master —

Effective Energy Control

for Data Centers

Let the System Do the

Tiring Tasks

(27)

ACC

Control Panel View

ACC

Optimized Mobile Experience

Taking Control Anytime, Anywhere

(28)

Intel® Xeon®

Scalable Platform Servers

Intel® Xeon® Scalable Processors

Exclusive Smart Thermal Rader design Port-to-port NVMe SSD Technology

1.65X faster system performance, support up to 28 cores

Dynamically adjust fan speed for cooling efﬁciency

ASUS Control Center Software

Server remote management to safeguard all of your devices

3X faster transit speed and dramatically reduce latency

RS520-E9

ESC8000 G4

ESC4000 G4

(29)

Fully Optimized Certiﬁed

Workstation for Professional

Content Creators

ESC500 G4 E700 G4 ESC300 G4 ESC500 G4 ESC510 G4

(30)

Sangfor HCI Solution

Why Choose Sangfor as Your HCI Solution Provider

5-Tier Architecture Consolidated into 1

1 Single User Interface Managing All IT Resources

Sangfor Hyper-Converged Infrastructure consolidates traditional

hardware-appliance-based security, IP network, storage network, server and

storage into one tier of commodity hardware (aSV), Storage Virtualization

(aSAN) and Network Virtualization (aNET), on top of that we have NFV

(Network Function Virtualization) integration including all our network

application such as NGAF/IAM/WANO

Asus RS500-E8/PS4 Sangfor HCI

SANGFOR HYPER-CONVERGED INFRASTRUCTURE

aSV Server

Virtualization aSAN StorageVirtualization aNET NetworkVirtualization NFV NetworkVirtualization

Node A Node B

10GbE 10GbE

10GbE 10GbE 10GbE 10GbE

A A

B _C C B

1GbE 1GbE

1GbE

D D

A : aSV Virtual Server - Client communication

B : aSAN communication (shared storage)

C : Overlay network communication

(31)

Asus RS520 Series for Sangfor HCI

Featuring:

2x RS500 series with 3 Years Sangfor HCI License

1x Network Switch 24x 1Gbps + 4x 10Gbps SFP+

3x 10Gb SFP+ Transceiver Cable

2 Socket CPU Up To 2x 22 Cores E5-26XX v4

3x8Cores E5-2620v4, 12x16GB DDR4 Registered , 3x 480GB SATA Enterprise SSD, 6x 4TB SATA 7.2Krpm Enterprise HDD, 6x 1Gb Ports,3x 10Gb Ports With SFP+ Transceiver Cable, 24x 1Gb+ 4x 10Gb Network Switch

S001114D0BCBZ0510Z0D

PN Specification

S001114D0A1AEB511Z0D

(32)

Upcoming Model Support

for AMD EPYC Platform

Right-Size Systems to Workloads

Without Compromise

High-Performance

Balanced Architecture

32

24, 16, 8

cores per socket

128

PCIe Gen 3 lanes in a single CPU

8

Memory channels

per CPU

2 TB

RAM per socket
