Analysis Plan Budget Cost to Work Structure and Architecture with to do Comparison Calculation Bow

Method and Rules Minister of PUPR No. 1 of 2022

La Ode Riski Indrawan Syah, Julistyana Tistogondo

Faculty of Engineering Civil Engineering Study Program Narotama University Surabaya [email protected], [email protected]

Abstract

The Ministry has just issued PUPR Ministerial Regulation No. 1 of 2022 replacing the old regulation, namely PUPR Ministerial Regulation No. 28 of 2016. This PUPR Ministerial Regulation No. 1 of 2022 has been refined following development developments in Indonesia. This research is based on the estimated building budget plan, in Indonesia using the unit analysis of materials and wages based on the BOW method and the Minister of Public Works and Public Housing Regulation no. 1 of 2022. This study performs a comparative analysis of the calculation of the budget using the BOW analysis method and the Minister of PUPR Regulation no. 1 In 2022, in the Planning (DED) project for the Development of the Batu City Main Market. By determining the ratio of the coefficients between the BOW method and the PUPR ministerial regulation method no. 1 of 2022 and recalculating the budget plan using the BOW method and the method of the ministerial regulation of PUPR no.

1 of 2022 with the same unit price of wages and materials. The results obtained from the analysis carried out on the Batu City Main Market Development project are the differences in the final results and each work sub- analysis of the two methods. The Budget Plan (RAB) for the construction of the Batu City Main Market using the BOW method is Rp. Rp 102.944.900.000,00 while using the Minister of PUPR Regulation No. 1 of 2022 it is Rp. 101.422.600.000,00. So that the difference is Rp 1.522.300.000,00, with the BOW method, it is greater than the method of the Minister of PUPR Regulation No. 1 of 2022.

1. Introduction

1.1. Background Behind

Analysis cost construction that has been known previously covers BOW analysis , SNI and Regulation Minister of PUPR. BOW analysis ( Burgerlijke Open Bare Werken ) is rule general and set rules by Dir. BOW number 5372A on time government Dutch on February 28 , 1921. BOW analysis ( Burgerlijke Open Bare Werken ) a lot used in RAB calculation for realize development period coefficient analysis cost unit product architecture Indies Netherlands . Ministry Work General and Public Housing has Secrete regulation new , Rules Minister of PUPR No. 1 2022 for replace old rules . Principle base Method Regulation Minister of PUPR No. 1 of 2022 is list coefficient for ingredient building , wages power work , and rent equipment . Has set for analyze price or cost required for produce a building .

In choose price per unit work , some people use BOW method ( Burgerlijke Open Bare Werken ) for count budget the shopping because coefficient used for produce income more big than method regulation Minister of PUPR No. 1 2022 when count side expenditure budget . Influencing factors analysis price unit profession is amount coefficient showing needs materials , tools , and power work for amount profession certain .

In the field , often occur disparity calculation cost Among BOW method ( Burgerlijke Open Bare Werken) and regulation Minister of PUPR No. 1 2022. By because that , used plan budget development for knowing disparity coefficient and difference price nor calculation from second method , which one is budget cost most efficient expenditure . Even between both , there are variation in coefficient and calculation difference price . By because that , research this conducted for knowing in detail the difference Among BOW method (Burgerlijke Open Bare Werken) with regulation Minister of PUPR No. 1 of 2022 issued by Ministry Work General and housing area people. Study this conducted on project Market Development Planning The Parent of Stone Town which is wrong one project government that swallows cost Rp . 199,987,540,000 ,00 - Year 2021 budget .

1.2. Formulation Problem

Based on the background, the formulation of the problem is as follows:

1. How big is the difference between the BOW Method Budget Plan (RAB) and PUPR Ministerial Regulation No. 1 of 2022?

2. How to do calculations using the BOW analysis method and PUPR ministerial regulation no 1 of 2022?

3. BOW method of budget analysis and regulation Minister of PUPR No. 1 in 2022?

(2)

95

2. Overview References

2.1. Base Theory

The project cost budgeting activity aims to determine the total cost that must be provided by the project owner to realize a building. The total cost includes the provision of materials, payment of wages for workers and the tools used in the construction process. Therefore, the project owner assigns a certain person or business entity called a quantity surveyor (QS) consultant to compile and make an overall cost budget report from the preparation stage to the finishing work. (Manullang, 2013)

According to the National Estimating Society - USA " Estimating of approximating the probable worth or cost, extent, quantity, quality, or character of something based on information available at the time", (Estimating is the art of estimating the possible price or cost, area, quantity, quality). or character of something based on the information available at the time). According to AACE International - USA, " Cost Estimating is the predictive process used quantity, cost and price the resources required by the scope of an investment option, activity or project". resources required for the scope of an investment option, activity or project).

Referring to the definition of estimation and cost estimation as presented above, it can be derived the notion of project cost estimation as an estimate of the possible costs required for project completion based on the information available at the time of making the estimate. (Pastiarsa, 2015)

Actual costing is the process of calculating the volume of work, the prices of various materials, and labor on buildings and projects based on actual data. Planning activities are the basis for making a financial system of a construction program to predict events in a building or project based on actual data. Other things that contribute to costs are:

1. Labor productivity 2. Material availability 3. Availability of tools 4. Weather

5. Contract type 6. Quality 7. Ethics

8. Implementation system 9. Management ability

Budget planning is the process of calculating the volume of work, the prices of various materials and the work involved in a construction. (Ir. Soedrajat S, Analysis (modern method) Advanced Implementation Cost Budget, Bandung, Bandung).

2.2. Analysis Budget Cost Use Book BOW analysis ( Burgerlijke Open Bare werken )

Some people still use guidelines BOW analysis volume 13 as base for determine price profession simple . Many people when this consider contained guidelines in BOW already left behind era . The BOW method is guide for make analysis cost power work traditional . Principle the guide is amount materials needed for every type profession and choice payment for To do profession it . BOW analysis only could used for activity congested creation with use tool traditional like saw and hoe . Tools traditional this still use power man for move tools that . For profession with modern / heavy equipment , BOW analysis is not available same once .

Factor analysis price rare BOW unit used because swelling cost in factor price . in between found principles in BOW method is list wages permanent and material ratio . Both of them analyze price ( cost ) required for count price unit job . Second coefficient produce materials needed and calculation salary . Composition , comparison , and composition ingredient and power work in something profession determined , then price unit ingredient multiplied with price unit local wages that .

by general principle calculation BOW method can concluded as following : Wage Cost = unit price of wages x wage coefficient (BOW) Material Cost = material unit price x material coefficient (BOW) Tool Cost = unit price of wages x tool coefficient (BOW) Price unit work = Cost Wages + Fees Material + Cost Tool

2.3. Budget Analysis of the Minister of PUPR Regulation No. 1 of 2022

New Ministry of PUPR just Secrete Regulation Minister of PUPR No. 1 of 2022, rules this official apply on 2022 .

Principle Regulation Minister of PUPR No. 1 of 2022 is count price unit power work that applies throughout Indonesian territory based on price unit material , price unit wages power work , and price unit tool according to requirements in the field employment . Specification and method work for every type profession customized with use specification standardized technical for profession that . by because that in To do calculation must based on picture technique and plan work as well as applicable requirements ( RKS).

(3)

96

Result of Budget Estimation (RAB)

Comparison of Material Coefficient Values and Wages for the BOW Method

and the Minister of PUPR 2022

Done

Conclusions and suggestions Comparison of Budget Estimates for

the BOW Method and the Regulation of the Minister of PUPR 2022

Calculation material index added tolerance 15%-20% covering amount big loss depends from type and composition material origin . Time work effective for worker counted 8 hours per day .

Principle counting price per unit profession according to system method Regulation Minister of PUPR No. 1 in 2022 practically coincide with calculation use BOW method , however different with BOW method , magnitude material coefficient and quantity the wages different .

This formulated as following :

Wage Cost = unit price of wages x wage coefficient (Permen PUPR) Material Cost = material unit price x material coefficient (Permen PUPR) Tool Cost = unit price of wages x tool coefficient (Permen PUPR) Price unit work = Cost Wages + Fees Material + Cost Tool

3. Methodology Study

3.1. Chart flow Study

As for chart flow research , made like on the following Flowchart this :

BOW method (Burgerlijke Openbare Werken)

Method of Regulation of the Minister of PUPR No. 1 of 2022

Figure 1. Research Stages 3.2. Method Data Collection

Data collection methods are crucial to support the perfection of research results. In this study, the data collection needed to determine the budget plan for the Batu City Main Market development project, namely:

1. Data volume profession structural ( Bill of quantity ).

2. Price unit wages and ingredients which used on project Batu City Main Market.

3. Analysis BOW ( Burgerlijke Open Bare Werken ).

4. Analysis Minister of Public Works and Public Housing Regulation No. 1 of 2022.

3.3. Data Analysis

On activity analysis data conducted a number of Thing which related withprocessing data Among other:

1. Evaluation BOQ data ( Bill of Quantity ) .

Data Collection Unit Price Analysis

Literature review

(4)

97 2. Understanding terms RKS project .

3. Summarize BOW analysis ( Burgerlijke Open Bare Werken ) who required in accordance list work items which there is .

4. Summarize index coefficient based on regulation minister PUPR number 1 year 2022 for system method calculation price unit job .

5. Collection list price material , wages , and tool based on with price which worn party contractor for development Market Main Stone Town .

3.4. Stages Study

3.4.1. Stage of Calculation of the amount of the difference in the Budget Cost between the BOW method and the Minister of PUPR Regulation no. 1 of 2022

1. Knowing results calculation between BOW and Regulation Minister of PUPR No. 1 2022 2. Sum up all work items in BOW budget and regulation Minister of PUPR No. 1 2022

3. Of the total budget cost BOW and method Regulation Minister of PUPR No. 1 of 2022, knows Difference budget BOW and method Regulation Minister of PUPR No. 1 2022

With formula :

Formula = Budget Cost Method BOW – Budget Cost Method regulation Minister of PUPR number 1 2022 .

3.4.2. The Calculation Stage of the Minister of PUPR Regulation No. 1 of 2022 1. Define price unit ingredient and wages worker

Moment count budget cost , where need price unit ingredient and wages workers . The cost depends location development project .

2. Calculate the total price ingredient and wages

From how to calculate the amount of material prices can be obtained the formula as following : Coefficient Total = Coefficient x Price Unit Ingredient

Amount Price = Coefficient Total x Volume

3.4.3. The Stage of Determining the Most Economical Value Between the BOW Method and Regulation Minister of PUPR No. 1 year 2022

1. Knowing the results of the comparison between the budget using the BOW method and the Minister of PUPR Regulation No. 1 of 2022.

2. The comparison results show which budget from the BOW method and PUPR ministerial regulation No. 1 of 2022 is the most economical and efficient.

4. Results and Discussion

4.1. General Project Data

The project that is used as a case study in this research is the construction project of the Batu City Main Market. This market development project is carried out by contractor PT. Sasmito. With this market project, it is a means of buying and selling activities as well as a shopping center.

From the project data obtained, it is obtained the budget plan (RAB) which will be analyzed in this study, namely analyzing the budget plan using the BOW (Burgerlijke Openbare Werken) method and the PUPR ministerial regulation.

The following is general data from the Batu City Main Market Development project:

The project name : Development of Batu City Main Market

Location : Dewi Sartika Street

Name of Executing Contractor : PT. Sasmito

Contract value : IDR 199,987,540,000.00-

4.2. Unit Price Analysis BOW Method (Burgerlijke Openbare Werken)

The BOW method is a guide for making traditional labor cost analysis. The guiding principle is the amount of material needed for each type of work and the choice of pay for doing the work. BOW analysis can only be used for labor-intensive activities using traditional tools such as saws and hoes.

The following is the calculation of the unit price analysis using the BOW method on structural and architectural work.

(5)

98 4.2.1. BOW Method Structural Job Analysis

Table 1. Excavation Works of 1m3 ordinary soil

No Description Unit Koef Unit price Total price

(IDR) (IDR)

A Power

Worker Oh 0.750 Idr 85,000.00 Idr 63,750.00

Foreman Oh 0.025 Idr 150,000.00 Idr 3,750,00

Total Manpower Idr 67,500,000

B Ingredient

Total Price Of Materials Idr -

C Equipment

Total Price Of Tools Idr -

D Amount (A+B+C) Idr 67,500,000

4.2.2. Architectural Work Analysis Method BOW

Table 2. Works 1.00 M2 red brick wall size (5 x 11 x 22) cm thick 1/2 brick camp. Specs 1 Pc : 4 Ps

(IDR) (IDR)

A Power

Worker Oh 0.450 Idr 85,000.00 Idr 38.250.00

Bricklayer Oh 0.150 Idr 100,000.00 Idr 15.000,00

Foreman Oh 0.023 Idr 150,000.00 Idr 3,375.00

Total Manpower Idr 58,425.00

B Ingredient

Red Brick Bra 72.00 Idr 700.00 Idr 50,400,000

Cement (Pc) Kg 12.66 Idr 1,325,00 Idr 16,781.39 Tide Sand M3 0.041 Idr 142,300.00 Idr 5,777.38

Total Price Of Materials Idr 72,958,77

C Equipment

D Amount (A+B+C) Idr 131,383.77

4.3. Unit Price Analysis Method Regulation of the Minister of PUPR No 1 of 2022

The principle of PUPR Ministerial Regulation No. 1 of 2022 is to calculate the unit price of labor applicable throughout Indonesia based on the unit price of materials, unit price of labor wages, and unit price of equipment according to the requirements in the field of manpower.

The following is an analysis of the calculation of the unit price of work using the analysis method of the Minister of PUPR Regulation No. 1 of 2022 on structural and architectural work.

(6)

99

4.3.1. Work Analysis Structure Minister of PUPR Regulation no 1 of 2022

Table 3. Excavation Works of 1m3 ordinary soil

No Description Sat Koef Unit price Total price

(IDR) (IDR)

A Power

Worker Oh 0.750 Idr 85,000.00 Idr 63,750.00

Total Manpower Idr 67,500,000

B Ingredient

Total Price Of Materials Idr -

C Equipment

D Amount (A+B+C) Idr 67,500,000

4.3.2. Architectural Work Analysis Regulation of the Minister of PUPR No. 1 of 2022

Table 4. Works 1.00 M2 red brick wall size (5 x 11 x 22) cm thick 1/2 camp brick. Specs 1 Pc : 4 Ps

(Rp) (Rp)

A Power

Worker Oh 0.300 Idr 85,000.00 Idr 25,500.00

Bricklayer Oh 0.100 Idr 100,000.00 Idr 10.000.00

Total Manpower Idr 38,950.00

B Ingredient

Red Brick Bra 70.00 Idr 700.00 Idr 49.000.00

Cement (Pc) Kg 11.50 Idr.1,325,00 Idr 15,237.50 Tide Sand M3 0.043 Idr 142,300,00 Idr 6,118.90

Total Price Of Materials Idr 70,356.40

C Equipment

D Amount (A+B+C) Idr 109,306.40

4.4. Recapitulation of Budget Estimates for the BOW Method and Minister of Public Works and Public Housing Regulation no 1 of 2022

The recapitulation of the budget plan for the construction of the Batu City Main Market is carried out on structural and architectural works. The results of the recapitulation estimation can be seen in Table 4.5.

The work items in the Batu City Main Market development project are:

1. Preparatory work 2. Structure Work 3. Earthwork

4. pack. sand, rebate and foundation 5. Concrete works

6. Architectural work 7. Wall and plaster work 8. Kuzen and window work 9. Ceiling work

10. Floor and wall ceramic work 11. Sanitation work

12. Finishing work

(7)

100

Table 5. Total Budget Plan

No Work BOW PUPR Candy 2022

1 Main IDR 98,014,850,062.21 IDR 96,150,577,414.13

2 Other IDR 6,208,585,699.32 IDR 6,585,988,828.55

Amount IDR 104,223,435,761.53 IDR 102,736,566,242.68 rounded up IDR 104,223,400,000.00 IDR 102,736,600,000.00

4.5. Calculation of the Difference in Budget Estimates for the BOW Method and the Minister of PUPR Regulation No. 1 of 2022

From the results of calculations using the BOW method and the Minister of Public Works and Public Housing Regulation No. 1 of 2022, the construction work of the Batu City Main Market can be obtained as follows:

1. Estimated cost budget using the BOW method is IDR 102.944.900.000,00

2. The estimated cost budget using the PUPR Ministerial Regulation No. 1 of 2022 is IDR 101.422.600.000,00 From the data above there is a difference in the estimated cost budget between the BOW method and the PUPR Ministerial Regulation No. 1 of 2022 amounting to:

IDR 102.944.900.000,00 - IDR 101.422.600.000,00 = IDR 1.522.300.000,00

The percentage difference between the BOW method and the PUPR Ministerial Regulation No. 1 of 2022 is:

The reason the budget value for the PUPR Ministerial Regulation No. 1 of 2022 is cheaper than the BOW is because the BOW (Burgeslijke Openbare Werken) analysis needs to be revised or improved. The guideline is felt to be no longer relevant because the BOW analysis can only be used if the work is a labor-intensive job using conventional equipment and an unprofessional workforce. While the method of the Minister of Public Works and Public Housing Regulation No. 1 of 2022 has used modern equipment and a professional workforce, so that the cost planning analysis is cheaper and more efficient.

4.6. Graph of Cost Estimate Results Between the Bow Method and the 2022 PUPR Ministerial Regulation

The results of the estimated cost budget using the BOW method and the PUPR Ministerial Regulation No. 1 of 2022 can be made in a graph. The graph can be seen in Figure 4.1. In making a graph based on Table 4.6 which shows the results of the estimated cost budget between the BOW method and the PUPR Ministerial Regulation No. 1 of 2022.

Table 6. Results of Budget Estimates

No Method Cost Estimate Results

1 Bow Idr 102.944.900.000,00

2 Pupr 2022 Idr 101.422.600.000,00

Figure 2. Graph of Cost Estimate Results Between the BOW Method and PUPR Ministerial Regulation No. 1 of 2022

103,000,000,000.00 102,500,000,000.00 102,000,000,000.00

BO W 101,500,000,000.00

BOW Peren PUPR

2022 Permen PUPR

2022 101,000,000,000.00

100,500,000,000.00

(8)

101

5. Conclusions And Recommendations

5.1. Conclusion

From the calculation results in the discussion of the Final Project on Comparative Analysis of the Budget Plan for the Development of the Batu City Main Market Using the BOW Method and the PUPR Ministerial Regulation No. 1 of 2022, the following conclusions are obtained:

1. The final result of the research shows that the calculation of the cost of building the Batu City Main Market using the BOW method is IDR 102.944.900.000,00, while the results of the cost estimation using the PUPR Ministerial Regulation No. 1 of 2022 are IDR 101.422.600.000,00.

2. From the calculation results, the difference in the estimated cost budget between the BOW method and the PUPR Ministerial Regulation No. 1 of 2022, namely the BOW method is more expensive by IDR 1.522.300.000,00 from the PUPR Ministerial Regulation No. 1 of 2022.

3. Fromthe results of the calculation of the budget plan for the Batu City Main Market development project with both methods, the cost estimation results using the PUPR Ministerial Regulation No. 1 of 2022 are the most economical. Because the index coefficient of the unit price of wages and materials is smaller than the BOW method.

5.2. Suggestion

1. In calculating the unit price of work, more careful calculations should be carried out, especially the selection of the right calculation method so that an economical and accountable budget is obtained.

2. It is recommended that the contractor in preparing the RAB can consider the amount of the difference in bidding costs not much different from the actual costs in the field, because if the bidding costs are reasonable, the competitiveness for the tender will be higher.
