Honeycomb pattern on thin wall object with grain based 3d printing

AMM Nazmul Ahsan, and Bashir Khoda, PhD*

Industrial and Manufacturing Engineering Department, North Dakota State University, Fargo 58102, USA

* Corresponding author. Tel.:+0-701-231-8071; fax: +0- 701-231-7195.

E-mail address: [email protected]

Abstract

Thin wall free form shaped objects frequently encounter printing difficulties including significantly higher build time, increased support structure, and trapped support material. Limited envelop volume of the existing 3D Printers narrows down the printability of larger objects. In this paper, we propose a novel grain based segmentation approach suitable for curved free-form shaped thin wall objects. Surface points from mesh are clustered into homogeneous groups based on the attributes including facet normal, neighboring facet, locations, and spatial variation of functional response. The boundary defined by clustered facets is called grain here which is constructed with modified K-mean facet clustering algorithm. The grain geometry is optimized for maximum uniformity in their surface curvature to reduce their fabrication complexity, support volume and fabrication time. Once the grains are generated, they are optimally oriented on the base plane to reduce the deviation caused by the surface curvature. The grain is then tessellated with variational hexagonal honeycomb cells to capture functional variation. The thin wall lattice grains are manufactured with the optimal orientations and assembled together with glue. The proposed methodology is implemented on two freeform shaped custom objects– helmet and hand cast, and tested on commercially available printers for fabrication. Comparative results indicate a significant reduction in total build time and support volume for both objects.

Keywords: Thin wall object, Object segmentation, Honeycomb pattern, Object grain orientation.

1.Introduction

Additive manufacturing, also known as 3D printing, enables direct fabrication of a 3D physical object from its digital model by successively printing

and stacking the layers of material one upon another.

The layer geometries are generated through slicing the digital model of the object. Materials are then deposited or cured inside these layers and stacked as it goes along the build direction. The succeeding layers Available online at www.sciencedirect.com

ScienceDirect

46th SME North American Manufacturing Research Conference, NAMRC 46, Texas, USA

Honeycomb pattern on thin wall object with grain based 3d printing

AMM Nazmul Ahsan, and Bashir Khoda, PhD*

Abstract

1. Introduction

The layer geometries are generated through slicing the digital model of the object. Materials are then deposited or cured inside these layers and stacked as it goes along the build direction. The succeeding layers

2 AMM Nazmul Ahsan and Bashir Khoda/ Procedia Manufacturing 00 (2018) 000–000 are supported by the previous layers during the whole

fabrication process. Depending upon the object geometry and the process plan, the object may require additional sacrificial support material to fabricate the overhangs.

To enhance the functionality and characteristics of 3D printed parts, research on novel structure design methods and techniques has received significant attention over the last few years. For instance, one common approach to reduce the deposition volume and material usage in this bi-modal layers pattern is hollowing the object and creating a scaled-down version inside it [1]. Another hollowing approach to reduce material wastage along with structural stability enhancement is a skin-frame structure design [2]

where frame structure is placed underneath the skin.

With the same objectives, Lu et al. [3] demonstrated another hollowing technique where the object interior was filled with voronoi honeycomb structure.

However, the hollowing techniques will introduce uncured trapped material inside the object for processes like powder bed fusion, vat polymerization, binder jetting etc. Removing the uncured material from the internal space can be tedious and time consuming and may often time require minor design modification to avoid trapped volume.

Hollowing the curved free form shaped thin wall objects can be done by placing repetitive patterns on the object surface and removing the interior of the patterns. These repetitive cutout patterns on thin wall objects are used for decorative purpose, easy uncured material removal, light weighting, or other functionality such as ventilation/air pass. The by- example pattern synthesis algorithm demonstrated by Dumas et al. [4] generates patterns as surface texture based on a given example pattern considering both appearance and structural properties of the object.

Zehnder et al. [5] proposed a decorative surface patterning technique formulated as energy minimization which creates ornamental curve networks on the object surface based on user-defined spline curves as the design primitives. Schumacher et al. [6] also presented an example pattern based cutout pattern/stencil generation technique taking aesthetics, stability, and material efﬁciency into account. The distribution and scaling of the patterns on object shell were determined solving an energy minimization problem. A stochastic search and a boosting algorithm proposed by Chen et al. [7] were used to cover an object surface with thin patterns termed as filigree.

This filigree synthesis was posed as a packing problem

with a focus on appearance. Besides providing some advantages, the thin wall objects with cutout patterns, however, suffers from fabrication complexity. For example, the overhang sections of the hollow cutout patterns frequently require increased amount of support structure from both outside and inside of the object. Again, support removal becomes another challenge because of the thin hollow sections of the object wall.

The print volume of the existing 3D printing machines is another important factor affecting the printability of larger objects that do not fit into the printing envelop of a given printer. The build time for larger objects with higher build height significantly increases due to the increased number of layers. Layer geometries also play a prominent role in the manufacturability of an object. Contour plurality and non-uniform layer geometries [8, 9] resulting from curved free form shaped objects dramatically increase fabrication complexity in additive manufacturing processes. The curved free-form shaped objects sometimes demand sacrificial support material as well depending on the object geometry. All these factors demand more resources in 3D printing processes [8].

Splitting thin wall objects into discrete segments can solve the problem of limited print area. Also, a careful discretization of curved free-form shaped object into segments may result in uniform layer geometries of the object segments. For larger objects, Luo et al. [10] proposed an object partitioning approach where objects larger than the working volume of a 3D printer were partitioned into smaller parts so that each of the pars fit into the printing volume. Several partitioning criteria such as assemblability, joining interface, areas of high mechanical stress, object symmetry etc. were taken into account in the segmentation process. Vanek et al. [11] developed a mesh segmentation and packing approach where the 3D objects were first converted into shells and then segmented into smaller parts. It was shown that the overall support material and build time were reduced due to partitioning and packing the segments in the print envelop. Recently Cheng et al. [12] has demonstrated a skeleton based partitioning technique for large objects considering the integrity of meaningful parts. However, the object geometry and fabrication complexity have not been considered while partitioning the object model. Therefore, object segments obtained using these techniques may have inhomogeneous surface characteristics due to sharp change in curvature. The dissimilarity in the grain

(2)
