State-of-the-art transducer technology is supported by an alarm panel that monitors the nitrogen pressure in the cylinder every second. A fire suppression system that monitors the full integrity of the fire system every second of the day. This ensures that all fuel and ignition sources are identified and assessed for protection, resulting in more effective management of the asset and its fire risks.
Full training is a prerequisite for the design, installation and service of the MusterII fire system. All personnel from PT JSG International Distributors are trained, then tested to ensure competence to provide the correct designs, installation and service capability of the entire range. Commonly used in mining, the MusterII Fire Suppression System provides excellent asset management in the most demanding environments.
The foam forms a layer on top of the fuel surface creating a vapor barrier, denying oxygen to the fuel surface. The foam provides a cooling effect and helps prevent flare-ups. Regardless of the type of activation system you choose, the MusterII system uses fast and reliable sensor systems to best protect your assets. Provides a reliable fire suppression system by monitoring and reacting when exposed to high heat.
MusterWire activates at 180°C when the outer layers melt and cause the double cores of the cable to touch, sending a signal directly back to the alarm panel.
Loss of Pressure Detection – Intrinsically Safe
Loss of Pressure Detection (LOP)
M2APK01 Alarm panel set The alarm panel set consists of; Alarm panel (with 1.0m cable and external data port), battery pack, 10m 2-wire silicone cable, electronic and LOP activation tags, 2mm stainless steel bracket with screws, 10 connection cables, 4 heat shrink pads and installation manual.
Alarm Panel
The MusterII Diagnostic Module (M2DM01) features an easy-to-read LCD display and easy-to-follow navigation. Estimate system pressure and battery status Display detailed information on system faults Update Alarm Panel software. The Diagnostic Module is an important tool that can be used by anyone to save valuable time and will assist the monitoring and field servicing of a MusterII fire suppression system.
Valve - Electronic Assembly
The gauge has a larger range of measurement allowing for more accurate cylinder pressure within 0.1% using the latest transducer technology.
Valve - LOP Assembly
Remote Actuators
Actuation Components
Cylinders
The filling tube is a newly designed tool to ensure the highest degree of accuracy when filling the cylinders.
Foams
Standard Foam
Advanced Agent
Nozzles
Line Fittings
Strong spikes eliminate the need to crimp the pipe, assembly can be done on the machine. ¼" and ½" Stainless Steel Push Bits Straight or beveled 90° bits available. Eliminates the need to crimp the hose. All standard fittings such as sockets, adapters are made of stainless steel, ensuring durability in harsh working environments.
M2PC01 P-clamp Suitable for ¼" hose, resistance and coupling plugs M8 mounting hole stainless steel M2PC02 P-clamp Suitable for ½" hose, grommets for MusterWire. M2L09 Label 'In case of fire' red small UV-stabilized M2L10 Label alarm 'Warning' yellow small for cabin UV-stabilized M2L11 Label alarm 'Warning' yellow large for cylinder UV-stabilized. FOR INSPECTION, MAINTENANCE AND MAINTENANCE REQUIREMENTS, PLEASE REFER TO THE MUSTER II TECHNICAL MANUAL PART # M2TM01 AND THE DESIGN AND COMMISSIONING DOCUMENTATION FOR THIS MACHINE.
Replacement Labels
PT JSG International's requirement for the personnel (distributors) of our system houses is that they are qualified before designing, installing or servicing fire systems and must pass proficiency tests to verify this ability to ensure correct design, installation and servicing. MusterII's accreditation process and holistic approach to the fire extinguishing system gives the customer confidence; in contractors, asset management and security.
Design Program
As such, the MusterII approach consists of working with clients to explore the 'Big Picture' concept of fire prevention and control, and using a comprehensive risk assessment procedure, following a process that allows clients to, in real terms, reduce the risk can reduce losses. .
These preventive measures take the lead in the process to achieve the ancient philosophy; prevention is better than cure. Fire risk assessments and audits are carried out to identify any areas that need to be addressed to create a safer working environment and comply with the necessary fire legislation. It is at this point, if the risk is still considered unacceptable, that the MusterII fire system provides effective fire control to achieve the final risk reduction result.
This provides the opportunity to perform the required internal inspections of the foam cylinders required by the standard AS. Below are examples of the standard forms for annual inspection, testing and maintenance that are generated in the design program. To maintain the integrity of the fire system and comply with AS5062.2006, regular maintenance must be carried out and a maintenance log must be kept.
The shapes are supplied with the fire system and are generated by the design program. This extinguisher contains a concentrate mixed with water and is best suited for fires involving flammable materials and flammable liquids such as paper, textiles, wood, petrol, oil, paint, plastic and rubber. All Muster extinguishers; complies with Australian Standard AS/NZS 1841.6, and includes stainless steel handles, brass valves and powder coated red finish.
Features include stainless steel cylinder, red UV powder coated paint and galvanized red powder coated trolley. Muster's black powder coated heavy duty vehicle mount to fit most 4.5kg or 9.0kg DCP fire extinguishers. Fits up to 4.5kg or 9.0kg fire extinguisher on the Muster Heavy Duty Center Carrier.
Fire extinguishers installed in all commercial, public and multi-occupancy residential buildings must all be regularly inspected and tested. The inspection, testing and maintenance procedures for fire extinguishers are specified in Australian Standard AS 1851. Service technicians must identify themselves to a person responsible for the building before completing any work.
Part Number Matrix
PT JSG International presents a modern innovation in product and system design, in their MusterII Fire Suppression System range. The built-in accuracy of the MusterII Fire Suppression system is controlled using intelligent pressure sensors, ensuring discharge timing meets initial design criteria, effectively suppressing fires in punishing multi-machine environments. Full monitoring available on both of these system types allows the operator to view the overall integrity of the system at all times, knowing that it is at the correct pressure and that all sensors are active.
These innovations combine to provide one of the lowest risk fire suppression systems on the market. The new MusterII fire extinguishing system comes with stainless steel components; including the valve, cylinder and fittings, ensuring its performance in extreme temperatures and weather conditions. Whatever the request; The new PT JSG International MusterII Fire Suppression System will perform as designed and to its full potential, suppressing flames and protecting your assets and personnel.
A high level of testing gives people the confidence in Muster Operation test of manual actuators and manual. Fire suppression systems have basically not changed in concept for many decades, but Muster®II now uses modern technology to produce a 24/7 fully monitored fire suppression system.
State of the art innovation and product design - Protecting your assets
