Research Article
Biosynthesis of Ultrasonically Modified Ag-MgO Nanocomposite and Its Potential for Antimicrobial Activity
Wasiu B. Ayinde ,
1Mugera W. Gitari,
1Munkombwe Muchindu,
2and Amidou Samie
31Environmental Remediation and Water Pollution Chemistry Group (ERWPCG), Department of Ecology and Resource Management, School of Environmental Sciences, University of Venda, Private Bag X5050, Thohoyandou 0950, Limpopo, South Africa
2Mintek, Advanced Materials Division, Nanotechnology Innovation Centre, Randburg, South Africa
3Molecular Parasitology and Opportunistic Infections Program, Department of Microbiology, School of Mathematical and Natural Sciences, University of Venda, Thohoyandou, South Africa
Correspondence should be addressed to Wasiu B. Ayinde; [email protected]
Received 2 May 2018; Revised 17 July 2018; Accepted 2 August 2018; Published 29 August 2018
Academic Editor: Marco Rossi
Copyright © 2018 Wasiu B. Ayinde et al. This is an open access article distributed under the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.
This study reports a green synthesis route for a bilayered Ag-MgO nanocomposite using aqueous peel extract ofCitrus paradisi (grapefruit red) under an accelerated uniform heating technique and its antibacterial potency againstEscherichia coli. Surface modifications and composition of the nanocomposite were examined using a UV-visible spectrophotometer, transmission electron microscopy (TEM), X-ray diffraction (XRD), Fourier-transform infrared (FTIR) spectroscopy, and scanning electron microscopy (SEM) equipped with an energy dispersive X-ray (EDX) analyzer. The efficiencies of the as-synthesized Ag-MgO nanocomposite againstEscherichia coliwere examined. The synthesized Ag-MgO nanocomposite showed characteristic syn- ergetic bands at 290 nm for MgO nanoparticle and at around 440 nm for Ag nanoparticle which blue-shifted to 380 nm in the composite. A spherically dispersed nanocomposite with cubical crystal lattice network with a diameter of about 20–100 nm comprising Ag nanoparticle embedded within MgO nanoparticles was obtained. The nanocomposite produced stronger anti- bacterial activity againstEscherichia colias compared to MgO nanoparticle, indicating a higher interaction between Ag and MgO ions. The nanocomposite was successfully synthesized via an efficient modified method by bioreductive agents with an improved synergistic antibacterial property towards water purification.
1. Introduction
Waterborne epidemics associated with high faecal con- tamination by pathogenic microbes are a worldwide prob- lem. The treatment of infectious water-related diseases is becoming a threat to human existence because of the in- crease in some high resistance to the causative microbial agent. The consequence is a potential public health threat due to an epidemic outbreak of diseases often associated with microbiological contamination, resulting in an in- creasing number of deaths across the globe, mostly among children [1]. Water disinfection through the use of con- ventional methods such as chlorination and ultraviolet (UV) irradiation is rapidly becoming a major challenge due to the
formation of harmful carcinogenic disinfection byproducts (DBPs) [2, 3]. The development of inorganic nanoparticles with improved physicochemical and biological properties from the biosynthesized route is on the rise due to the growing need to develop environmentally benign technologies in material synthesis against infectious organisms. Generally, with the efforts to reduce generated hazardous waste, green synthesis and chemical processes are progressively integrating with modern developments in science and industry [4]. Re- searchers are exploiting the introduction of eco-friendly materials towards the development of novel improved anti- bacterial nanomaterials against multidrug-resistant human pathogens like Escherichia coli. E. coli is one of the deadly contaminants in drinking water. The nontoxicity and
Volume 2018, Article ID 9537454, 10 pages https://doi.org/10.1155/2018/9537454
environmental compatibility of biosynthesis agents, especially from various plant-derived extracts or components, make them reliable biosynthesis agents for metal and metal oxide nanoparticle synthesis [5–7].
Among the metallic and metal oxide nanoparticles, silver (Ag) and magnesium oxide (MgO) nanoparticles have been extensively reported to possess broad-spectrum antibacterial activities [8–11]. Silver nanoparticles are undoubtedly the most widely used inorganic nanoparticles with tremendous applications in the field of highly sensitive biomolecular detection and antibacterial activities [12–14].
MgO nanoparticles, on the other hand, have recently re- ceived greater attention because of their vast applications in biomedical materials, catalysis, and as absorbents [15–17].
However, based on the antibacterial properties of MgO nanoparticles having less potent bactericidal effect in comparison to silver-based antibacterial agents, efforts are now being channeled into the development of composite materials to exert strong synergistic antibacterial activity against infectious pathogens through chemical methods [9, 18, 19]. However, the use of such chemicals in nano- synthesized biomedical materials has been a major concern due to their high cost, toxic nature, and production of non- eco-friendly byproducts and nonbiodegradable stabilizing agents posing a danger to the environment and human beings [20–22].
To address this shortcoming, successive biosynthetic approaches using plants extracts have been explored and reported [23, 24]. The plant-based approaches have many advantages over chemical methods. According to previous investigations, the polyol components and the water-soluble heterocyclic components in these plants play a significant role in the reduction of metallic ions. They have proven to be effective capping and stabilizing agents for the nanoparticles with widespread technological and medicinal applications [25–27]. Silver and magnesium oxide nanoparticles have been synthesized using various plant extracts. The use of the extract of different biodiversity plants has been extensively reported and reviewed for silver nanoparticles [8]. Fur- thermore, MgO nanoparticles have been successfully syn- thesized through different plant species extract including Swertia chirayitaleaf extract [16],Clitoria ternatea[28], and Emblica officinalisfruit extracts [29].
The peel of some fruits contains considerable amounts of minerals and vitamins, especially in citrus fruits. Previous studies have shown the presence of higher contents of phenolic, flavonoids, as well as other valuable secondary plant metabolites and essential oils in fruit peels than in other segments of citrus [30–32]. These metabolites are reported to account for various bioactivities including an- tibacterial and antioxidant properties [33, 34]. In addition to the eco-friendly application of these components in syn- thesizing nanoparticles, efforts are now focusing on iden- tifying different novel energy transfer-assisted methods, such as microwave [35] and ultrasound [36], capable of providing efficient, uniform heating distribution in the formation of a stable and sustainable biomedical nano- composite materials with improved physicochemical properties.
In this present study,Citrus paradisi(grapefruit red) peel extracts were used via an efficient heating medium towards its bioreducing, stabilizing, and capping ability in the for- mation of Ag-MgO nanocomposites. A detailed formation, characterization, and E. coli inactivation of the Ag-MgO nanocomposites were evaluated and reported. The novelty of this work is based on the fact that, to the best our knowledge, the use of aqueous C. paradisi peel extracts in bio- synthesizing Ag-MgO and testing of its antibacterial activity have not been reported.
2. Materials and Methods
All chemicals were of analytical reagent grade. Mg (NO3)2·6H2O, AgNO3, NaOH, and other chemicals used were purchased from Rochelle chemicals, South Africa, and used directly without further purification. Deionized water from Millipore (18.2 MΩ/cm) was used for the preparation and dilution of standards throughout the experiment.
2.1. Preparation of Citrus paradisi Peel Extracts. The fruit peels of Citrus paradisi (grapefruit red) were removed, cleaned thoroughly using ultrapure water (18.2 MΩ/cm) to remove any dust particles adhering to the surface, and cut into small pieces. 30 g of the peel was added to 100 mL of ultrapure water and boiled for 20 minutes at 70°C. The extract was cooled and filtered through Whatman no. 1 filter paper and stored at 4°C for further use.
2.2. Microwave-Assisted Synthesis of Silver Nanoparticles Using Citrus paradisi Peel Extract. Biosynthesized Silver nanoparticles (AgNps) were first obtained via the microwave-assisted sol-gel method. In a typical experiment, 40 mL of the filtrate of the citrus peel was added to 60 mL of 1 mM silver nitrate (AgNO3) in 250 mL Erlenmeyer flasks at the ratio of 2 : 3 v/v for the reduction of Ag+to Ag0. The mixture was then placed on a turntable domestic microwave oven (Russell Hobbs 20L (RHEM 21L)) operating at a power of 700 W and frequency of 2450 MHz at different time in- tervals of 30, 60, 90, 120, and 150 seconds for complete bioreduction. The formation of silver nanoparticles (AgNps) was monitored using UV-Vis Spectrophotometer over the wavelength range of 220–600 nm. Time-resolved absorption spectra of the UV-Vis spectroscopy were used in monitoring the periodic bioprocess growth kinetics of AgNps through color variation. The synthesized nanoparticle was used in subsequent experiments.
2.3. Synthesis of Ag-MgO Nanocomposite. Ag-MgO nano- particles were synthesized by seed growth via the bio- reduction route by the precipitation method at room temperature using a natural mild reducing agent (aqueous Citrus paradisipeel extracts) in the presence of the metallic precursors. 0.1 M·Mg(NO3)2·6H2O and 1×10−3M AgNO3
were used as the precursors of MgO and Ag, respectively.
In a typical experimental procedure, the Ag-MgO composite was obtained from an already optimized
microwave-assisted aqueous mixture of C. paradisi peel extracts (1 mM·AgNO3 (2 : 3 v/v%)). 80 ml of this solution was mixed with 20 mL 0.1 M·Mg(NO3)2·6H2O under con- tinuous stirring (2 h) at room temperature with 2 mL of 0.1 M·NaOH solution added dropwise until a complete precipitation was achieved. The composite solution was thereafter subjected to ultrasonic irradiation controlled at 100% amplitude (0.5 cycles) for 30 min. The product ob- tained was centrifuged (4500 rpm) for 30 min, filtered, and freeze-dried.
2.4. Physicochemical and Mineralogical Characterization of Synthesized Nanocomposite. The synthesized Ag and Ag- MgO nanomaterials absorption range was monitored using UV-visible spectrophotometer (SPECTROstar Nano/BMG LABTECH). Surface morphology of the nanoparticles was characterized using SEM (FEI Nova NanoSEM 230) with the field-emission gun equipped with an Oxford X-Max SDD detector operating at an accelerating voltage of 20 Kv for the EDS detector (Oxford X-Max with INCA software). The ALPHA FT-IR spectrophotometer from Bruker was used to obtain the FTIR spectra (4000–400 cm−1). The crystalline phases present in the materials were identified by X-ray diffraction (X’Pert Pro; Cu-K radiation; wavelength 1.54443 ˚A). The transmission electron microscopy (TEM) image was taken using an FEI Tecnai 20 equipped with a LaB6 emitter, operating at 200 KV and fitted with a Gatan Tridiem GIF with a 2K×2K CCD camera. Images were collected using the digital micrograph suite of programs in relation to size and shape.
2.5. Antibacterial Evaluation of the Crude Extract and Nanomaterials. The bacterial resistance of the bio- synthesized Ag-MgO nanocomposite, Ag, and MgO was determined from the observed zone of inhibition (mm) using the standard agar well disc diffusion methods (Kirby–Bauer disk diffusion test) and microdilution assay.
The indicator strain used isEscherichia coli(ATCC 35218).
Bacterial suspensions were prepared with the turbidity of 0.5 McFarland. 50μL (1 mg/mL) of Ag, MgO, and Ag-MgO solution was impregnated on a cellulose nitrate sterile filter paper (pore size 0.45μm) and allowed to dry at room temperature for 3 h and placed on MacConkey nutrient agar plates already inoculated with the bacterial cell suspension.
The plates were incubated at 37°C for 24 h, and the diameter of the zone of growth inhibition around the sample was measured in millimeters (mm) and compared. The measured zones of inhibition were used to determine the antibacterial activities of the nanocomposite. Minimum inhibitory con- centration (MIC) of biosynthesized Ag, MgO, and Ag-MgO was also determined using the microtiter broth-dilution method as described by Samie et al. [37].
2.6. Release of Silver and Magnesium Ions. To determine the release of silver and magnesium ions in solution, 1 mg/ml of the biosynthesized Ag-MgO was left to stand at room temperature for 3 h. At different time intervals, the
suspension was collected and filtered through a membrane filter (pore size 0.45μm (47 mm)). The concentrations of Ag- Mg ions in the filtrate (20μL) were measured on PinAAcle 900T Atomic Absorption Spectrometer (AAS, PerkinElmer, Inc.).
3. Results and Discussion
3.1. Physicochemical and Mineralogical Characterization of Ag-MgO Nanocomposite
3.1.1. UV-Visible Analysis. Figures 1 and 2 show UV-visible absorbance spectra for the Ag nanoparticle and Ag-MgO nanocomposite. The successful bioreduction formation of AgNps by aqueous extract of C. paradisi peel extracts at a mixing ratio of 2 : 3 by volume at different time intervals ranging between 0–150 s under microwave irradiation is indicated by a change in the color of the reaction solution from light yellow to dark brown (Figure 1). AgNps were observed at intervals of 0–150 s with a characteristic surface plasmon vibration band ranging between 410 and 440 nm appearing at approximately 30 s of the reaction nucleation and onset of growth. The absorption peak intensity gradually increases with the increase of irradiation time with some overlapping plasmon bands with the formation of more AgNps evidently the same sizes which may be due to the stabilizing effect of theC. paradisipeel extract biomolecule.
The intensity of the peaks indicated that C. paradisi peel extracts enhanced the bioreduction process of Ag+with the continual formation of AgNps up to 150 s with little vari- ation in the absorption maxima. In general, the morphology of the nanoparticles is greatly influenced by the surface plasmon resonance, due to the mutual vibration of electrons of metal nanoparticles in resonance with light wave serving as the basis for measuring adsorption of the material onto the surface of metal nanoparticles [38, 39]. Furthermore, the use of microwaves is vital in the development of this nanoparticle because it is eco-friendly in nature and pro- vides rapid and even heating of the reaction medium, thus offering uniform nucleation and growth conditions for nanoparticles within the short reaction time unlike the traditional external heating methods [40].
Figure 2 depicts an absorption spectrum of the syn- thesized biogenic Ag-MgO nanocomposite. As shown in the spectrum, two different distinct peaks were observed. A prominent intense band is observed in the low-UV region at 290 nm typical of MgO together with a broad band at 378 nm associated with AgNPs. It is observed that the incorporation of MgO onto the Ag layer resulted in a blue shift in the peak of AgNps from 440 nm to 378 nm. This shifting is attributed to its particle size, which depends on nucleation and growth mechanism based on the excitation of plasmon resonance or interband transition, particularly on the size effect [13]. This clearly indicates the reduction in the particle size resulting from the optical property of biomolecular capped Ag-MgO nanocomposite. Furthermore, the sizes of the composites were affected upon ultrasound exposure due to the cavita- tional collapse phenomenon resulting in an interparticle collision, thus affecting the physicochemical properties of
the composite in relation to the incident frequency of the sonicator [41, 42]. It can be established that the availability and impacts of the phytochemicals in C. paradisipeel ex- tracts were responsible for the rate of bioreduction leading to the formation of the composites.
3.1.2. FTIR Analysis. The functional groups of the various metabolites present in the C. paradisi peel extract re- sponsible for the bioreduction, capping, and stabilizing of the Ag-MgO nanocomposite were identified between 4000 and 500 cm−1 of the FTIR region. Figure 3 shows the comparative FTIR spectra of as-synthesized Ag(CPAgNp) and Ag-MgO(CPAgMgO) from the aqueousC. paradisipeel extract. In the CPAgNp spectrum, a strong band centred at around 3282 cm−1resulting from the stretching vibrations of
the hydroxyl (–OH), N–H stretch of various metabolites present in the peel extract in the form of alcohol and N–H stretch of 1°and 2°amines or amides, carboxylic acid, ester, and ether [39]. These peaks shifted to a higher and broader frequency range of 3440–3200 cm−1in intensity on binding with MgO in CPAgMgO nanocomposite. The sharp peaks observed at 2915 cm−1 and 2849 cm−1 in CPAgNps which disappeared in the CPAgMgO spectrum could be assigned to the symmetric and asymmetric C–H stretching vibrations of methyl, methylene, and methoxy groups [43, 44]. The presence of CO is found in both spectrums at 1734 cm−1 and 1625 cm−1for CPAgNps which shifted to 1626 cm−1in the composite. This may be attributed to the presence of carboxylate ion and an amide group. In both spectra, dif- ferent characteristic sharp peaks were also observed between 1538 and 1377 cm−1which may be assigned to the –CC in the aromatic rings, asymmetric stretching (C–N) mode in addition to the bending vibrations of the methyl and methylene groups of fatty acids. The C–O–C, C–C, and carboxylic group (C–O) stretching vibrations were identified 0sec
30sec 60sec
90sec 120sec 150sec
b c d e f
a
0.8 1.8 2.8 3.8 4.8
Absorbance
420 460 500 540 580 620
380
Wavelength (nm)
Figure1: UV-visible spectra and photographic representation of silver nanoparticles biosynthesized by using aqueousC. paradisipeel extract at the mixing ratio of 2 : 3 at different time intervals.
Ag-MgO AgNp
438 378 Blue shifts between Ag nanoparticles and
Ag-MgO composite
280 300 320 340 360 380 400 420 440 260
Wavelength (nm)
0 0.5 1 1.5 2 2.5 3 3.5
0.05 0.15 0.25 0.35
Absorbance
390 440 490 540 590
290 340 290 nm
Figure 2: UV-visible spectra of biomolecular capped Ag-MgO nanocomposite.
CPAgMgO CPAgNP
–0.1 0 0.1 0.2 0.3 0.4 0
0.2 0.4 0.6 0.8 1
Absorbance
1000 1500 2000 2500 3000 3500 4000
500 Wavenumber (cm)
Figure 3: Comparative FTIR spectra of biosynthesized Ag and Ag-MgO nanomaterial.
at 1238, 1156, and 1032 cm−1 bands, respectively. The ab- sorption peaks in the region between 487–677 cm−1 are attributed to Mg–O–Mg compounds [45, 46], and from the spectrum of CPAgMgO, it shows Mg–O–Mg deformation of the Mg–O absorption band at 540 cm−1[47]. The presence and interaction of the above bands in C. paradisi peel ex- tracts indicate that the bioactive compounds were presumed to act as reducing, capping, and stabilizing agents for the biosynthesized Ag-MgO nanocomposite.
3.1.3. Surface Morphology. The resulting morphological characteristic images (SEM and TEM) with associated EDAX spectra for the biosynthesized Ag and Ag-MgO nanomaterials using the peel extract of C. paradisi are shown in Figures 4 and 5. The SEM micrograph of AgNps (Figure 4(a)) shows well spherically and uniformly dis- persed nanoparticles, whereas the Ag-MgO composite nanoparticles image (Figure 4(b)) displayed an agglom- eration of layered clustered particles. It is polydispersed and crystalline in nature. The corresponding elemental compositions suggesting the formation of the AgNps and Ag-MgO nanocomposite are depicted in Figures 4(b) and 4(d), respectively. The observed agglomeration in the composite may be due to higher amounts of organic moieties acting as the capping and stabilizing agent in the
biomass of the C. paradisi peel extracts. In addition, the polarity and electrostatic attraction of the attached MgO nanoparticles in the composite may also result in the ag- gregation [48].
Figure 5 shows the morphology, shape, and particle size distribution of the biosynthesized AgNPs and Ag-MgO nanomaterial through the TEM micrograph. The TEM images (Figures 5(a)–5(c)) of C. paradisi peel extract- mediated synthesized AgNps and Ag-MgO composite clearly show that the particles are uniformly dispersed and mostly spherical in shape with a particle size of 14.84 nm and 11.92 nm, respectively. Figures 5(b) and 5(c) revealed the stabilization and distribution of the embedded-layered core- shell interaction between the Ag and MgO in the bio- synthesized composite. The spherical shaped appearance and the sizes are well in line with the shape of the UV-visible plasmon resonance band established during the cavitation process at high intensities of exposure resulting in the conversion of larger particle sizes to smaller sizes. The images from the different scale bars (Figures 5(b) and (c)) clearly show the embedment of the bilateral core-shell interaction.
3.1.4. XRD Pattern. The X-ray diffraction patterns of Ag- MgO nanocomposite, MgO, and Ag nanoparticles
Ag Ag C
0 1 2 3 4
Full Scale 587 cts Cursor: 0.000
(a) (b)
C
Cl Cl
Mg AgCl
Ag O
0 1 2 3 4 5
Full Scale 349 cts Cursor: 10.095 (2 cts)
(c) (d)
Figure4: SEM images of biosynthesized (a) AgNps; (b) EDAX spectra of AgNps; (c) Ag-MgO nanocomposite; (d) EDAX spectra of Ag-MgO nanocomposite.
synthesized using aqueousC. paradisipeel extracts over a range of 20–80°using Cu-K radiation with their corresponding peak lists are shown in Figure 6. The nanocomposite material showed major predominant consistent reflection peaks at 2θ values between the range (20–80°) differently indexed to {111}, {200}, {202}, {311}, and {222} assigned to cubical crystal planes of Ag (reference code: 96-901-2962), together with an extended
reflection labelled pattern {420} associated with the cubical system phase of MgO (reference code: 96-901-3264) which shifted to a higher prominent 2θvalue deposited on Ag-MgO plane lattice interaction. Silver-magnesium (0.8/0.2) planer lattice (reference code: 96-150-9046) was also detected, thus providing confirmation of the composite nature of the material with a cubical crystal lattice network.
(a) (b) (c)
Figure5: TEM micrograph. (a) AgNps; (b) scale bar Ag-MgO nanocomposite image at 20 nm; (c) Ag-MgO at 100 nm.
10.00 100
200 300 400 500 600 700 800 900
15.00 20.00 25.00 30.00 35.00 40.00 45.00 50.00 55.00 60.00 65.00 70.00 75.00 80.00 2θ Cu-Kα (1.790300A)
a
c b Irel
Figure6: XRD diffractogram of biosynthesized (a) Ag-MgO nanocomposite, (b) MgO, and (c) Ag.
3.1.5. Antibacterial Activity. The agar well diffusion and minimum inhibitory concentration experiments were con- ducted on MgO nanoparticle and Ag-MgO nanocomposite to perform a qualitative antimicrobial screening. Clear in- hibition zones of varying diameters appeared against the Gram-negative bacteria Escherichia coli from both nano- particles with Ag-MgO showing a wider antibacterial activity on the bacterial strain as shown in Figure 7. Ag-MgO composite exhibited a higher level of antibacterial poten- tial onE. coliwith 22 mm zone of inhibition in comparison with the Ag and MgO nanoparticle (Table 1). In addition to visual readings from the agar well, the viability ofE. coliwas subjected to different concentrations of the nanocomposite.
As shown in Table 1, minimum inhibitory concentration (MIC) values of 80, 40, and 20μg/mL was recorded for MgO, Ag, and Ag-MgO, respectively. The lowest concentration at which the composite showed growth inhibition was recor- ded as the minimum inhibitory concentration. Studies have shown that the toxicity effects at different MIC values de- pend on the type of bacterial strains, precursor concentra- tion, methods of preparation, and capping agents [49–51].
Although the inactivation mechanism of action of nanoparticles against microbes has been a major debate, studies have shown that bacterial inactivation appears to be driven by the toxicity of release of metal ions as well as the generation of intracellular reactive oxygen species (ROS) upon exposure of the bacterial cells to such nanomaterials amongst other factors [52–55]. Consequently, antimicrobial potency of any material will depend on the ability to disrupt the microbial cell membrane damaging its membrane properties, permeability, and the collapsing of its respiratory functions resulting in the cell death [29].
As illustrated in Figure 8, the time-dependent releases of metal ions fromC. paradisipeel extracts biosynthesized Ag- MgO nanocomposite were examined. Both Ag and Mg ions release were affected by time and rate of dissolution; metal ions release increases as the time progresses (Figure 8).
Although the release of Mg ions is in higher concentration than the Ag ion throughout the process, both concentrations at the highest time interval (Ag ion (2.7 ppb) and Mg ions
(1027 ppb)) are lower than the observed minimum inhibitory concentration (MIC) (Table 1). These results suggested that the MIC value does not correlate with the mode of action of the antimicrobial activity of the Ag-MgO composite and the release of these metal ions against Escherichia coli. Conse- quently, there is a possibility that the bacterial susceptibility of this Ag-MgO nanocomposite does not only rely on the in- teraction of metal ions with the cell wall structures of Gram- negative bacteria genome but are also dependent on the solution pH, cellular enzymes, and biochemical events in producing intracellular reactive oxygen species (ROS) from the composite surface [15, 56, 57]. Furthermore, other factors that may be associated with microbial cell death by this nanocomposite could be attributed to its size, structure, and surface properties of the composite since smaller particles with larger surface area possess the affinity for interaction, giving more bactericidal effect than the larger particles [15, 58]. Moreover, the Ag-MgO nanocomposite antibacterial activity may also depend on the reducing and capping agents used in the synthesis route [59]. Therefore, theC. paradisipeel extracts used in the synthesis of Ag-MgO may have con- tributed to the antimicrobial activity due to the different functional phytochemical species in the peel segment, which account for the bioactivity [32, 60].
4. Conclusion
This study integrates biomediated microwave and ultrasonic simple and rapid synthetic methods using an aqueous peel MgO
Ag-MgO
Ag-MgO
Ag
Figure7: Antibacterial activity of biosynthesized Ag, MgO, and Ag-MgO againstE. coli.
Table1: Antibacterial activity.
Methods MgO Ag Ag-MgO
Well diffusion assay (mm) 9 14 22
MIC (μg/mL) 80 40 20
1 2 3
Ag ion 1.0313 2.5229 2.7252
Mg ion 581.5 824.3 1024
200 400 600 800 1000
0.5 1 1.5 2 2.5 3
Mg ion conc. (ppb)
Time (hours)
Ag ion conc. (ppb)
Figure8: Time-dependent metal ions release from biosynthesized Ag-MgO nanocomposite.
extract of theCitrus paradisifruit as the reducing, capping, and stabilizing agent for synthesis of Ag-MgO nano- composite. The presence of the phytochemicals in the extract was responsible for the rate of bioreduction leading to the formation of the composites, thus serving as an alternative to the chemical and physical synthesis route. Surface plasmon resonance nucleation growth of AgNps was observed at 410 and 440 nm upon microwave exposure, which shifted to 378 nm band upon integrating with MgO shell, which displayed an absorption band at 290 nm, confirming the presence of a bilayered Ag-MgO core-shell synergy. Surface modifications and composition of the nanocomposite showed a spherical and uniformly distributed nano- composite with an average crystalline size of 11.92 nm. The biosynthesized Ag-MgO nanocomposite exhibited an en- hanced antibacterial activity than MgO nanoparticles, proving to be a potential material against common patho- gens in water treatment.
Data Availability
The data used to support the findings of this study have not been made available because of the collaboration agreements covering the research.
Conflicts of Interest
The authors declare no conflicts of interest.
Acknowledgments
The authors would like to acknowledge the financial support from USAID-PEER Cycle 6 (Award no: AID-OAA-A-11- 00012); National Research Foundation (Grant no: 114726);
University of Venda, South Africa (RPC Grant no:
SES/17/ERM/03); and Mintek, South Africa.
