B-TU003514 / 5100001408

JADWAL AANWIJZING PENGADAAN VACCUM CLEANER

Tgl. / Date

:

17.09.2014

Tanggal Penutupan / Closing Date : 24.09.2014

Jam / Time : 10:30:00

Pos/Item ; Kode Stock/Stock Code (No.SPP/Req.No.) ; Uraian/Description ; No.Part/Part.No. Satuan/ Unit Banyaknya/ Quantity Harga Satuan/ Gross Unit Price

Pot./ Disc. (%) W.serah/ L.Time (hari/day) 0000000001 Vacum Cleaner

I.A. Vacuum Unit

The frame is made of electro welded sheet stiffened to withstand the vacuum. The frame is lined with soundproof material to shot down the noise. Several opening allow the access to the internal parts:

# Three lobes Roots type blower # Three phase electric motor # Vacuum relief valve

# Valve to open the loop (vacuum is not allowed if open)

# Filter cartridge

# Star Delta starting device # Air silencers

# Temperature probe of the blower air discharge # Level gauge of integrated hopper

# Control board .

I.B. Sleeve Chamber:

The air/material mixture comes into the filter chamber in the lower part where the heaviest dust falls to the bottom.

The lighter dusts are conveyed by the air to the sleeves where they are stopped.

The inspection and maintenance operations are easy. Thes leeves can be extracted from the top of the machine. The sleeve filter type

UNT 1

(2)

Pot./ Disc. (%) W.serah/ L.Time (hari/day)

allows a great filtering surface (springs maintain the sleeves completely outstretched) and

hence a very slow air velocity.

The sleeves# cleaning is done by injection air flow.

The cleaning cycle is started each 10 minutes and is programmable. The air to lead this special cleaning device is supplied by a costumer, is not included in the equipment.

I.C. Safety Cartridges Filter

The safety cartridge has got a 10 m² surface. It is installed upward blower for avoid the incoming of particles into the lobes case damaging it.

I.D. Integrated 1,3 m3 / 2 tons hopper with discharging butterfly valve:

In electro welded steel, it is fixed and can be handled by a fork lift. It is provided of a discharging system by means of butterfly valve with manual operating.

I.E. Automatic non stop discharge valve Dia. 300 # type VSC300.001

(OPTIONAL):

# 2 butterfly valves DN 300, with steel shutter # 2 pneumatic, double effect, widely

proportioned actuators

# 2 electro-valves for pneumatic actuators operating

# 1 intermediate #buffer# body, to connect the Jumlah Pos / Total Number of items : 1

(3)

INDONESIA

Telp.Phone : (0717) 4258000 Fax. : (0717) 433075/432584

Kepada / To :

Surat Permintaan Harga (SPH) / Request For Quotation (RFQ)

:

B-TU003514 / 5100001408

Tgl. / Date

:

17.09.2014

Jam / Time : 10:30:00

Pot./ Disc. (%) W.serah/ L.Time (hari/day) two valve

# 1 compressed air regulator with condense emission, complete with pneumatic connections

I.F. Control board:

As per CE normative with mechanical protection IP 54 is provided of:

# Buttons # Pilot lights

# Safety devices: max temperature blower

discharge air, pressure switch air circuit for sleeves cleaning, maximum level gauge of integrated hopper, maximum level gauge of separator, thermal switches for electric motors

I.G. Technical Data of UNIVAC SV37TAV

Voltage 400 -660 / 50 Hz Power 37 / 50 KW/HP Type of the engine Root Blower Blower Roots no. 3 lobes Air flow rate 1,850 m³/h Maximum depression 491 m.bar / 7,000 mmH2O Primary sleeve filter surface 16 m² / 160,000 cm²

Filtering sleeve material Felt Polyester Filter sleeve cleaning Counter Current Safety cartridge surface 10 m²

Compressor for sleeve cleaning Included

Compressor for leading the sleeve cleaning 0.55 Jumlah Pos / Total Number of items : 1

(4)

Pot./ Disc. (%) W.serah/ L.Time (hari/day) KW

Minimum compressed air pressure required 5 bar Compressor tank capacity 6 Liter Dry and with no oil air consumption 50 Liter/h Volume integrated hopper 1.3 m³ Manual electric discharge valve Included Allowed suction hoses (mm) 100 - 80 Ø Sound pressure level 85 <dBA Engine Cooling Air Vacuum Relief Valve Included Level Gauge Included Dimension 1500x1500x3500 mm

Idling Weight 2,200 Kg

I.H. Accessories kit

SUPERFLEX POLYURETHANE ANTISTATIC HOSE Ø 70 mm length

Hose Cuff Ø 70 mm AA1023 4 pieces SCRAPING STEEL NOZZLE 1200 mm. LENGTH

Catatan :

1.Termasuk Bahan dan jasa pemasangan instalasi jaringan pipa vacum cleaner di Wilayah Peleburan dan PBBT Kundur 2.Franco Gudang Kundur

3.Sertifikat keaslian ( COO )

Jumlah Pos / Total Number of items : 1 RAPAT PENJELASAN ADMINISTRASI DAN TEKNIS DILAKSANAKAN PADA :
