TRAILER CONNECTORS TRAILER CONNECTORS BRACKETS EURO & SUZI COILS ELECTRICAL SUZI COILS

(1)

TRAILER CONNECTORS

BRACKETS

(2)

TRAILER CONNECT

ORS

TRAILER CONNECT

ORS

TRAILER CONNECTORS

Part No./ Description

553114

7 Pin Heavy-Duty Round Metal

Trailer Socket with Rubber Boot

Die cast housing is self grounded

Amp rating per pole 40A at 6-28V continuous.

Part No./ Description

553113

7 Pin Heavy-Duty Round Nylon

Trailer Socket with Rubber Boot

Corrosion resistant nylon housing

Amp rating per pole 40A at 6-28V continuous.

553113/ 20 as above Bulk Pack of 20

Part No./ Description

553112BL

Blister Pack

12 Pin Flat Trailer Socket with Reed Switch

for use with Normally Open Circuits

For use on vehicles with reversing sensors. The reed switch

deactivates the reverse sensor while the trailer is connected.

Suits all vehicles with normally open circuits secifically Ford

and Nissan.

7 pole amp rating per pole 15A at 12V

5 pole amp rating per pole 35A at 12V

553112/ 20 as above Bulk Pack of 20

Part No./ Description

553111

Blister Pack

7 Pin Large Round Plastic Trailer

Coupling Socket

Amp rating per pole 30A at 12V

553111/ 25 as above Bulk Pack of 25

Part No./ Description

553110

Blister Pack

7 Pin Flat Trailer Socket Kit

Pre-wired with 1.5m harness and supplied with wire-tap

connectors. Amp rating per pole 15A at 12V

(3)

TRAILER CONNECT

ORS

TRAILER CONNECT

ORS

BRACKETS

Part No./ Description

553119BL

Blister Pack

Angled Bracket for Large Round Plastic

and Metal Sockets

553119/ 20 as above Bulk Pack of 20

Part No./ Description

553118BL

Blister Pack

Angled Bracket for Small Round

Metal Sockets

553118/ 20 as above Bulk Pack of 20

Part No./ Description

553117BL

Blister Pack

Flat Bracket for Small Round

Metal Sockets

553117/ 20 as above Bulk Pack of 20

Part No./ Description

553116BL

Blister Pack

Angled Bracket for Small Round

Plastic Sockets

553116/ 20 as above Bulk Pack of 20

Part No./ Description

553115BL

Blister Pack

Flat Bracket for Small Round

Plastic Sockets

(4)

TRAILER CONNECT

ORS

TRAILER CONNECT

ORS

EURO & SUZI COILS

Part No./ Description

553224

7 Core 4mm ‘Euro Coil’ , 3.6 Meters

with Two Short Tail Fitted with P/No. 553142

Metal Plugs

The ‘Euro Coil’ is wound with less tension than the standard

Suzi coil and extends to 3.6 m yet still retains excellent coil

memory. The reduced tension places less stress on the plugs

and is ideal for use with PO-GO sticks, a common European

style of use. Two Short tails, 250 mm long manufactured from

polymide 11 & 12 they recoil to a very short length for easy

storage when not in use.

Part No./ Description

553210

7 Core 4mm ‘Euro Coil’ , 3.6 Meters

with One Short and One Long Tail Fitted with

P/No. 553142 Metal Plugs

The ‘Euro Coil’ is wound with less tension than the standard

Suzi coil and extends to 3.6 m yet still retains excellent coil

memory. The reduced tension places less stress on the plugs

and is ideal for use with PO-GO sticks, a common European

style of use. Two Short tails, 250 mm long manufactured from

polymide 11 & 12 they recoil to a very short length for easy

storage when not in use.

553211 as above, no plugs

Part No./ Description

553142BL

Blister Pack

7 Pin Large Round Metal Trailer Plug

Amp rating per pole 30A at 12V

Accepts 6mm Cable (5.22mm2)

553142 as above Bulk Pack of 25

553121

7 Pin Heavy-Duty Round Metal Trailer Plug with

Internal Weatherbeater Seal and Cable Guard

Amp rating per pole 40A at 6-28V continuous

(5)

TRAILER CONNECT

ORS

TRAILER CONNECT

ORS

EURO & SUZI COILS

Part No./ Description

553216

7 Core 4mm Suzi Coil, 4.6 Meters

with 6 x 4 mm (2 mm²) 1 x 5 mm (3 mm²)

Cores and Two Short Tail Fitted with

P/No. 553142 and One P/No. 553121 Plug

with Cable Guard

Required to adapt trucks or trailers with the new heavy-duty

sockets to the current large round sockets and vice versa.

Extends to 4.6 m (15ft) with 6 cores of 2 mm² cable, one 3

mm² earth/ ground cable and two 250 mm short tails fitted

with standard metal plug and the SAE plug with cable guard.

Part No./ Description

553218

7 Core 4mm Suzi Coil, 4.6 Meters

with 6 x 4 mm (2 mm²) 1 x 5 mm (3 mm²)

Cores and One Short and One Long Tail

Fitted with P/No. 553142 Metal Plugs

Extends to 4.6 meters (15ft) with 6 cores of 2 mm² cable,

on 3 mm² earth/ ground cable, one 250 mm short tail and

a 1 meter long tail. Fitted with standard metal plugs

(P/No. 553142)

553223 as above, with long tail on the Heavy-Duty plug end

Part No./ Description

553215

7 Core 4mm Suzi Coil, 4.6 Meters

with 6 x 4 mm (2 mm²) 1 x 5 mm (3 mm²) cores

and Two Short Tail Fitted with P/No. 553142

Metal Plugs

The ‘Euro Coil’ is wound with less tension than the standard

Suzi coil and extends to 3.6 m yet still retains excellent coil

memory. The reduced tension places less stress on the plugs

and is ideal for use with PO-GO sticks, a common European

style of use. Two Short tails, 250 mm long manufactured from

polymide 11 & 12 they recoil to a very short length for easy

storage when not in use.

(6)

TRAILER CONNECT

ORS

TRAILER CONNECT

ORS

ELECTRICAL SUZI COILS

Part No./ Description

553221

Extra Heavy-Duty 7 Core Suzi Coil 4.6 Meters

with 4 x 5 mm (3 mm²), 2 x 6 mm (5 mm²),

1 x 8AWG (8 mm²) Cores and Short Tails Fitted

with P/No. 553121 Heavy-Duty Plugs.

A Heavy-Duty green jacket is impervious to most chemicals

and abrasion. It has extra ordinary coil memory and extends

to 4.6 meters (15ft) with 4 cores of 3 mm², 2 of 5 mm² and

one earth/ ground core of 8 mm².

Two 250 mm short tails are fitted (Internally crimped) with

Heavy-Duty plugs and cable guards.

Part No./ Description

553222

Extra Heavy-Duty 7 Core Suzi Coil 4.6 Meters

with 4 x 5 mm (3 mm²), 2 x 6 mm (5 mm²),

1 x 8AWG (8 mm²) One Short Tail and One

Long Tail Fitted with P/No. 553121

Heavy-Duty plugs.

A Heavy-Duty green jacket is impervious to most chemicals

and abrasion. It has extra ordinary coil memory and extends

to 4.6 meters (15ft) with 4 cores of 3 mm², 2 of 5 mm² and

one earth/ ground core of 8 mm². One 250 mm short tails

and a 1 meter long tail (Internally crimped) with Heavy-Duty

plugs and cable guards.

553220

Heavy-Duty 7 Core Suzi Coil, 4.6 Meters

with 6 x 5 mm (3 mm²), 1 x 6 mm (5 mm²)

Cores and One Short and One Long Tail

Features :

A Heavy-Duty silver sheath and generous cross sectoinal

core area extends to 4.6 meters (15ft) with 6 cores

of 3 mm² cable and one earth/ ground core of 5 mm².

One 250 mm short tail and a 1 meters long tail have

soldered ends and can be used with either standard plugs

or heavy-duty plugs.

553223 as above, with long tail on the Heavy-Duty plug end
