CAM BIEN
SO sanh cac cong nghe
cam bien thay the i khong tiep xuc
V
di bat ki iing dung do thay ddi ludn ed sa can nhac g\da Idi ich va gidi ban ma mdi cdng nghe do dem lai. Chinh vi vay, bai viet nay so sanh bdn logi edng nghe do ladng thay the khdng tiep xuc, daa ra t a van viec chpn li/a cdng nghe do sao cho phii hdp nhat.Viec sir dung cdng nghe thay the khdng tiep xuc trong do ladng chinh xae dang phat trien mot each nhanh chdng.
Ngadi sir dung can do chinh xae hdn, dp phan giai nhd hdn micro hoac nano met, va chdng lai khd khan b'e mat hoac vat lieu khdng the dapc cham trong luc do bao gom silicon, thiiy tinh, chiit deo, thanh phan dien va y te thu nhd, gidng nha di/a tren be mat thac pha'm.
Sa phat trien dd da thiic day trien khai cdng nghe mdi, bao gom sd dieu chinh cdng nghe hien tai cho phii hdp nhu'ng yeu cau do ladng mdi, cai thien dp chinh xae
va dp phan giai cho viec do. Cam bien thay dd'i khdng tiep xuc tien tdi md rpng tinh da dang eiia hinh dang, kich thadc va nguyen ly do. Trong thac te, cung nha ddng xoay va cam bien tam giae lazer, dien dung va cam bien dong tieu la pho bien ngay nay.
Nguyen ly dong dien xoay
Nguyen ly do ddng dien xoay la each do cam iing. Mot cudn day dapc ciip bdi ddng dien xoay chieu va sinh ra tir tradng xung quanh cudn day. Neu mot vat dan dien dadc dat trong tir tradng, ddng dien xoay dadc cam u'ng, tao thanh mot tradng dien theo Luat cam iing Faraday Bp dieu khien tinh toan thay ddi trong nang lapng chuyen dd'i t i i cudn day cam bien tdi vat dich va chuyen dd'i nang ladng dd thanh do ladng sa thay doi .
Phadng phap nay ed the dadc sir dung cho tiit ea vat dan dien, sat tir va khdng mang sat tir, la Idi the ciia phadng
phap nay. Kich thadc cam bien thac sti nhd dadc so sanh vdi eac cdng nghe khac, cdng nghe cd dp chinh xae cao va ngan dadc bui, ban, dp am, dau, ap suiit cao va chiit dien mdi trong do khoang each.
Tuy nhien, tin hieu ra va tuyen tinti phu thupc vao dac diem dien va tir ciia doi tapng. Bdi vay, moi sa dieu chinh va tuyen tinh hda dadc yeu cau. chieu dai Idn nhiit cap la 15m va dadng kinh ciia cam bien tang khi tang pham vi do.
Nguyen ly dien dung
vdi nguyen ly dien dung, cam bien va ddi tadng tac ddng gidng y tadng hai ban CI/C song song ciia tu dien. Hai dien ci/c dadc hinh thanh bdi cam bien va ddi mat ddi tadng. Neu ddng xoay chieu vdi tan so khdng dd'i qua tu cam bien, dp Idn ciia dien ap xoay chieu tren cam bien ty le vdi khoang each giu'a hai cdc cua tu. Dien ap bii ed the dieu chinh ciing mot liic dadc phat ra t i i bd khuyech dai dien. Sau do giai dieu bien ciia ea dien ap xoay, sai lech dadc khuyech dai va dau ra nha mot tin hieu tadng ta.
Bdi vi cam bien dadc cau tao giong nha mot vdng bao ve tu, hiiu nha nhOtig y tadng tuyen tinh va dp phan can eii cac ddi tadng kim loai da dat dadc. Cdng nghe cung daa ra dp on djnh nhiet dp cao, khi thay doi tinh d i n dien ciia ddi tadng khdng cd hieu iing trong do ladng. Cam bien dien dung cung ed the do chiit each dien.
Cdng nghe nay nhay cam vdi thay doi trong khe dien mdi dien trd va vi cd tac dung hieu qua Idn nhiit trong viec lam sach, iing dung khd. Chieu dai cap cung thac sa ngan do hieu irng ciia dien dung cap trong sa dieu chinh mach dao ddng.
Nguyen ly tam giac laser
Trong nguyen ly nay, mot diode laser phdng ra mot diem anh sang nhin thiiy len tren be mat cua vat the dang dadc do.
Anh sang bj phan tan trd lai dadc phan xa tir die'm dd la hadng len tren mot mang CCD bdi he thdng thau kinh quang hoc chat ladng cao. Neu doi tadng thay doi vj (Xem tiep trang 55)
