Sound & Vision Bible

(1)

A MIDSUMMER NIGHTS DREAM

Complied by: Ben Mills

Sound & Vision Bible

(2)

Table of Contents

Page 3 Page 4 Page 5 Page 8 Page 10 Page 11 Page 12 Page 13 Page 14 Page 15 Page 16 Page 17 Page 18 Page 21 Sound and Vision Schematic

Archive Schematic Sound and Vision Equipment List Sound and Vision Equipment Loan Request Form Sound Patch Sheet Vision Patch Sheet Network Allocation Communications Allocation Speaker Placement Plan Speaker Section Vision Placement Plan Vision Section Archive Procedure Sound & Vision Designer/QLab Operator Show Plot

SYSTEM

Page 27 Page 34 Page 35 Page 36 Sound Cue Synopsis

APRA Application APRA Duration Vision Cue Synopsis

DESIGN

(3)

Show Venue Version

Title

Drawn By Contact

A Midsummer Night’s Dream The Loft, Kelvin Grove V3 as of 14/10/2018

Sound & Vision Schematic Benjamin Mills

Director Designers Francesca Savige

Stephanie Yau

Set, Costume &Vision Designer

Nicholas Seery

Lighting Designer

Benjamin Mills

Sound & Vision Designer/

QLab Operator

KEY NOTES

RIGGED

CISCO Network Switch 10 port

1 2 3 4 5 6 7 8

Mac Pro - Vision (Qlab 4, Decklink)

Ethernet Decklink Quad OUT IP Address: 192.168.10.161 8

Mac Mini - Sound (Qlab 4)

Ethernet Thunderbolt OUT IP Address: 192.168.10.162

CAT 6 DIN21 - SDI ThunderboltSDI MOTU 16A

IN

OUT IN

[FOH L] 1 [FOH R] 2 [REAR L] 3 [REAR R] 4 [SUB L] 5 [SUB R] 6 [ATMOS L] 7 [ATMOS R] 8 109 1112 1314 1516

12 34 56 78 910 1112 1314 1516

Soundcraft SI Expression 1

OUT1 23 45 67 89 1011 1213 1415 16

TRS - XLR

JBL Control 30 REAR L

XLR Crown XLS 602

#1 IN1

2

OUT1 2

FLOOR AUDIO

JBL Control 30 REAR R JBL Control 30

FOH L

JBL Control 30 FOH R

Mackie SMR Sub L

Mackie SRM450 ATMOS L

Mackie SRM450 ATMOS R Crown XLS 602

#2 IN1

2

OUT1 2

Venue Patching

IN OUT

SP12 - MIC 2 SP14 - MIC 2 SP12 - MIC 1 SP14 - MIC 1

SP12 - AUD 2 SP14 - AUD 2 SP12 - AUD 1 SP14 - AUD 1

Wireless Mic (Primary)

Shure ULXD4D Receiver

IN OUT

RX1 1

Shure Wireless ULX SM58

RF OUT

RF SDI IN

Panasonic PT-DZ21K w/ ET-D75LE10 Ethernet

IP Address: 192.168.10.160 Monitor

Speaker (for SM)

IN

SM Stage Feed

NTG3

- Computer Monitors have not been drawn.

- Not to scale.

- Comms System hasn’t been drawn in.

- Speaker Placement refer to Speaker Placement plan.

- Keyboard & Mouse not drawn.

- Power not drawn.

Wireless Mic (Redundant)

Shure ULXD4D Receiver

IN OUT

RX2 2

Shure Wireless ULX SM58

RF OUT

SM58 God Mic

Wireless Router (Production Desk)

Sound Designer Screen Sharing

Ethernet

IP Address:

192.168.10.167

Vision Designer Screen Sharing

Ethernet

IP Address:

192.168.10.169

Mackie SMR Sub L Mackie SMR Sub R

(4)

Show Venue Version

Title

Drawn By Contact

A Midsummer Night’s Dream The Loft, Kelvin Grove V1 as of 20/09/2018 Archive Schematic Benjamin Mills

Director Designers Francesca Savige

Stephanie Yau

Set, Costume &Vision Designer

Nicholas Seery

Lighting Designer

Benjamin Mills

Sound & Vision Designer/

QLab Operator

KEY NOTES

SDI XLR

- Not to scale.

- Comms System hasn’t been drawn in.

- Camera Placement refer to Camera Placement plan.

- Power not drawn.

- Footage from the Stage Feed cameras will be recorded onto SD cards in the Hyperdeck Mini.

- Audio from Zoom H6 willbe ercorded

Stage Feed

NT5

NT5 ^IN¹ Zoom H6

32

Comms

SOUND

Blackmagic ATEM TV

Studio HD N70

N70

SDI OUT

N70 Hyperdeck

Mini Hyperdeck

Mini

SDI IN 1 2 3 4

SDI OUT SDI OUT SDI OUT

SDI OUT 5

6 7 8

VIDEO

_{Stage Feed}

(5)

Subject to Change Correct as of 24/10/2018 Ben Mills | Sound & Vision Designer / Qlab

Operator

Version 2 Page 1 of 3

A MIDSUMMER NIGHT’S DREAM SOUND & VISION EQUIPMENT LIST Version #2

Quanity Item Hirer Pickup Date Return Date Department

1 MacBook Pro Ben Mills 3/10/18 22/10/18 SND

1 MacBook Air Ben Mills 3/10/18 22/10/18 VIS

1 Zoom H6 Handy Recorder Nick Seery 3/10/18 22/10/18 ARCH

1 GoPro Hero 5 Black Ben Mills 3/10/18 22/10/18 ARCH

1 Panasonic DZ21K with ET-D75LE10 QUT Gardens

Theatre 3/10/18 22/10/18 VIS

1 5 meter SDI Cable QUT Gardens

Theatre 3/10/18 22/10/18 VIS

3 10 meter SDI Cable The Loft 3/10/18 22/10/18 ARCH

1 Soundcraft Expressions 1 The Loft 3/10/18 22/10/18 SND

2 Shure Wireless ULXD SM58 The Loft 3/10/18 22/10/18 SND

1 Shure ULXD4D Receiver The Loft 3/10/18 22/10/18 SND

(6)

Operator

2 Mackie SRM450 The Loft 3/10/18 22/10/18 SND

3 Mackie SRM Subwoofer The Loft 3/10/18 22/10/18 SND

1 TRS - XLR Loom The Loft 3/10/18 22/10/18 SND

4 Camera Tripods Z6 ELC 2/10/18 22/10/18 ARCH

4 Sony NX70 Z6 ELC 2/10/18 23/10/18 ARCH

2 Rode NT5 Z9 Level 1 ELC 3/10/18 22/10/18 ARCH

1 Rode NTG3 Z9 Level 1 ELC 3/10/18 22/10/18 ARCH

1 Blackmagic ATEM TV Studio HD Z9 Level 1 ELC 3/10/18 22/10/18 ARCH

4 Blackmagic Hyperdeck Mini Z9 Level 1 ELC 3/10/18 22/10/18 ARCH

1 Mac Mini w/ Motu 16a (Qlab 4

installed) Z9 Level 1 ELC 3/10/18 22/10/18 SND

2 Monitor w/ Keyboard and Mouse Z9 Level 1 ELC 3/10/18 22/10/18 SND

1 DIN21 - SDI Z9 Level 1 ELC 3/10/18 22/10/18 VIS

1 Cisco Network Switch (10 port) Z9 Level 1 ELC 3/10/18 22/10/18 VIS

1 TP-LINK Wireless Router Z9 Level 1 ELC 9/10/18 22/10/18 SND

(7)

Operator

1 Mac Pro (Qlab, Decklink Quad

Installed) Z9 Level 1 ELC 3/10/18 22/10/18 VIS

5 Ethernet Cables Ben Mills 3/10/18 22/10/18 VIS

(8)

Subject to Change Correct as of 25.10.18 Ben Mills | Sound & Vision

Designer

A MIDSUMMER NIGHT’S DREAM Sound Patch Sheet Version #2

Audio Patch Sheet – QLAB, Motu, Sound Craft SI Expression 1

Channel # Name MOTU

Outputs

Sound Craft Inputs

Sound Craft Outputs

Venue Patching - Control

Venue Patching - Floor

1 FOH LEFT 1 1 1 AMP 2/Chan 1 N/A

2 FOH RIGHT 2 2 2 AMP 2/Chan 2 N/A

3 REAR LEFT 3 3 3 AMP 1/Chan 1 N/A

4 REAR RIGHT 4 4 4 AMP 1/Chan 2 N/A

5 SUB L 5 5 5 SP12 - MIC 2 SP12 - AUD 2

SUB L (2) N/A N/A N/A N/A N/A

6 SUB R 6 6 6 SP14 - MIC 2 SP14 - AUD 2

7 ATMOS LEFT 7 7 7 SP12 - MIC 1 SP12 - AUD 1

8 ATMOS RIGHT 8 8 8 SP14 - MIC 1 SP14 - AUD 1

9 WIRELESS MIC

(PRI) N/A 9 9 RT1 N/A

10 WIRELESS MIC

(RED) N/A 10 10 RT2 N/A

11 GOD MIC N/A 11 11 N/A N/A

(9)

Designer

A MIDSUMMER NIGHT’S DREAM Vision Patch Sheet Version #2

Vision Patch Sheet – Decklink Quad 2, QLAB, Panasonic PT-DZ21K

SOURCE IN OUT SURFACE

Panasonic DZ21K SDI IN DECKLINK QUAD 2 #8 Surface #1 Back Wall

(10)

Designer

SHOW NAME DOCUMENT TITLE

Version # A MIDSUMMER NIGHT’S DREAM

NETWORK ALLOCATION Version #2

Machine IP Address

Vision Mac Pro 192.168.10.161

Sound Mac Mini 192.168.10.162

Panasonic DZ21K Projector 192.168.10.160

Sound Designer 192.168.10.167

Vision Designer 192.168.10.169

(11)

Ben Mills | Sound & Vision Designer

Subject to Change Correct as of 2.10.18

SHOW NAME DOCUMENT TITLE Version # A MIDSUMMER NIGHT’S DREAM

Communication Allocation Version #2

If there are any issues or concerns with the current comms allocations, please see Ben Mills (Sound & Vision Designer/ QLab Operator).

Personnel Comm's Pack Number Plot Tech/Dress Show Production Stage

Manager 1 x x x

Assistant Stage

Manager 2 x x x

Head LX/ Lighting

Designer 3 x x x

Lighting Operator 4 x x x

Sound & Vision Designer / QLab

Operator

5 x x x

Set, Costume &

Vision Designer 6 x x x

Head of Set 7 x x x

Lecturer 8 x x x

Duty Tech 9 x x x

(12)

Control Room PS Rail OP Rail

11800

2498 2498

(13)

Notes Key

- Mackie SRM450's to face the Upstage wall.

D

- Mackie SRM Sub to face downstage.

JBL Control 30 D Mackie SRM Subwoofer [ Mackie SRM450

TITLE: Speaker Section Sound Designer: Ben Mills

Version: V3 as of 12/10/2018 Venue: The Loft, Kelvin Grove Drawn by: Ben Mills Mobile:

Scale: 1 :50

^@

A3

(14)

Control Room

PS Rail OP Rail

Rear Rail

(15)

Notes

- Aspect Ratio: 16:1 0 - Surface Dimensions: 1920 x 1040.

- Lens: ET-O75LE10 1.3 - 1.7:1 - Surface dimensions: 11800mm x 7400mm ...

^e

Title: Vision Section ^Drawn by: Ben Mills

v-r-s_ia_n:_v_3_a_s_ot_1_21_1_01_20_1_a ...

- Projector: Panasonic PT-DZ21 K - Projector will sit on a black wooden box - Distance from liens to surface: 18.25 m in the centre of the bio box.

- Projector surface is the upstage wall. - Projector not drawn, only beam.

Venue: The Loft, Kelvin Grove Emai

Vision Designers: Stephanie Yau & Ben Mills

(16)

Designer

SHOW NAME

DOCUMENT TITLE

Version #

A MIDSUMMER NIGHT’S DREAM Archival Procedure Version #2

Time-lapse

You MUST Format the SD Card before each Recording

STARTING THE TIME-LAPSE

Step One: Format SD Card

1. Turn on Go Pro by holding the button on the side down.

2. Swipe down from the top of the screen to reveal the menu.

3. Click on “Preferences” and scroll down to “FORMAT SD CARD”

4. Select this, and press “OK”

Step Two: Selecting Time-Lapse Mode

1. As default, once the Go Pro is turned on I have configured it to be ready to start Time Lapsing (photo) at 30 seconds.

2. Press the Mode (side button) button until the Time-Lapse screen appears.

3. Select “Time-Lapse Photo”, ensure settings are set to “30 Seconds” and

“12mp”

4. Press the mode button to escape once settings have been set.

Step Three: Plug in Go Pro to GPO

1. Plug the Go Pro charging cable (USB-A to USB Type C) into the Go Pro with the USB C termination going into the camera.

2. Plug the charger into a GPO located on the Bio Box desk near the projector.

Step Four: Positioning of Go Pro

1. Place the Go Pro in the position, closest to the silver lip on the edge of the bio box desk.

2. Ensure the power cable is still in place once the Go Pro has been positioned, make sure the Go Pro will not move during the time-lapse.

END OF TIME-LAPSE

1. Press the recording button (top button) on the Go Pro to stop its recording.

2. Power off the Go Pro, hold down the side button.

3. Take Go Pro out of its housing, import footage via the USB-C cable.

4. Import all footage onto LaCie HD (Ben Mills) in the Archive folder, and then into corresponding subfolders (bump in, focus, plot etc.)

(17)

Designer

SHOW NAME

DOCUMENT TITLE

Version #

A MIDSUMMER NIGHT’S DREAM Archival Procedure Version #2

Show Recording

Pre-show

1. See show plot for power up sequence.

2. For All three of the Blackmagic Hyperdeck minis ensure that all are set to record as H624 Medium.

3. Format the SD cards in both the Hyperdecks minis and in the Zoom H6 Recorder.

Beginners

1. Start recording on all three Blackmagic Hyperdeck minis by pressing the record button, each Hyperdeck will record on of the following OP Stage Camera, C Stage Fee Camera and PS Stage Camera.

2. Start recording on the Zoom H6 which will record the stage feed audio (left and right) and comms recording.

Post Show

1.

Stop recording on all devices. Hyperdecks, this is done by using the STOP button on each device. Zoom H6 Recorder, this is done by pressing the stop button.

Post Show

After FOH Clearance

1. Stop the Zoom H6 recording for the stage feed and comms recording. Bring SD Card down to the green room to import content into the LaCie HD (Ben Mills).

2. Stop all recording on cameras #1-3, on the Hyperdecks, this is done by using the STOP button on each device.

3. Import all footage onto the Archive HD into the appropriate folders, (Show, Camera, Comms Recording etc).

4. Once confirmed that all footage has been backed up to the Archive

HD format all the SD Cards.

(18)

Designer

SHOW NAME

DOCUMENT TITLE

Version #

A MIDSUMMER NIGHT’S DREAM Archival Procedure Version #2

Comms Recording Announcement

Ladies and Gentlemen of the A Midsummer Night’s Dream Company. Please be advised that comms and archival recording will commence shortly, comms and archival recording will commence shortly.

Thank you

Ladies and Gentlemen of the A Midsummer Night’s Dream Company, this is comms recording for A Midsummer Night’s Dream, Show Number #, 15/16/17/18/19/20th October, 2018. Please be advised that comms are now recording. Please be advised that comms are now recording.

(19)

Subject to Change Correct as of 20-Oct-18 Ben Mills | Sound & Vision

Designer

Page 1 of 6 Version 2

SOUND & VISION DESIGNER / QLAB OPERATOR SHOW PLOT Version #2

Two Hour Call:

Power On:

- Vision:

o Turn on the vision control power board which is connected to a technical earth GPO. This power board has plugged in into it the Mac Pro, Monitor, Network Switch, Blackmagic Decklink Quad 2.

o Power on the Projector that is used in the show, which is the Panasonic PT- DZ21K. The mains power button should be already in the ON position, press the POWER ON button on the side of the projector for 3 seconds. Wait until the projector starts to power up and continue with the power up sequence.

o Power on the Mac Pro by pressing the silver power button on the front of its housing for 3 seconds until the mac start up sound can be heard.

o Turn on the monitor by pressing the touch sensor power icon on the front of the display.

o Once the projector has powered up, check that the signal that the projector is being inputted is 1080/60i. A pop-up window will appear on the left-hand side of the surface.

o Open Blackmagic Desktop Video Setup on the Mac Pro.

o Click through until Decklink Quad (8) appears on the screen. From this click into it to check its settings.

(20)

Designer

o Check that the Output Format is set to 1080i60.

o Check that the Connector is set to SDI 8.

o Once this is all correct. Save and QUIT Blackmagic Desktop Video Setup. Make sure this is completely quit before opening the QLAB Show file.

§ If the projector isn’t recognising the input, check the following:

• Make sure that the DIN21-SDI cable located at the back of the Mac Pro in the Decklink Quad 2 is connected properly and isn’t

damaged.

• Make sure the connection from DIN21 – SDI to the SDI cable to the projector is securely in place. As well as the SDI connection into the projector itself.

• Make sure the projector is set to INPUT SDI 1 this can be checked by going into MENU, scrolling down and selecting signal list, and checking that the input the projector is receiving is SDI 1, at 1080i60.

• If the projector is still not receiving any signal, quit Decklink and restart the computer and power down the projector. Once all has been powered down, wait at least 1 minute to give it some time, then power up the projector then the Mac Pro. This should resolve the issue.

(21)

Designer

SOUND & VISION DESIGNER / QLAB OPERATOR SHOW PLOT Version #2 o On the desktop open the Folder named “Show Files”

o Open the file named “2018_QUTActing_MND_VisionShowFile_Bundle_V2

o Once this is opened, click on the setting icon and go into the VIDEO Tab.

o Click EDIT, on the Back Wall Surface which should be the only surface available.

o Open the surface setting and put up the grid. This is done by clicking the GRID button.

(22)

Designer

o Make sure that the projector is focused correctly to the edges of the wall and make sure that the focus is correct.

o Once the grid is up and the focus is correct, unclick the GRID button and return back to the main cue list.

o Check that QLAB has control of the shutter over the network. This is done by going on the Shutter Close Cue and Shutter Open Cue that is located in the Preshow Checks Cue List.

§ If this doesn’t work check that the ethernet cable that is in the projector hasn’t come lose or unplugged.

§ Double check that the Network switch is powered on and the ethernet cables connected are plugged in correctly.

§ Check the IP Address of the projector and make sure it is 192.168.10.160.

If this has changed, set it back to 192.168.10.160. To check this, on the projector, using the button on the side, click MENU, then use the arrow down button (with will be the top arrow because the projector has been positioned upside down due to restrictions on placement) until NETWORK is selected, click the ENTER button, scroll down until IP Address is

selected and click ENTER and use the arrows to change the IP address.

SOUND:

- Turn on all GPO’s that are on the desk of the bio box.

- Power on the Mac Mini by pressing the power button.

o Open the folder Show file, and open the file

“2018_QUTActing_MND_SoundShowFile_V3”

- Turn on the monitor by pressing the power on touch sensor on the front of the monitor.

- Power on the MOTU 16A audio interface, by switching on the power switch (located on the front right of the mac mini housing)

- The sound console that is being used of MND is the Soundcraft SI Expression 1. Power on the sound console by pressing the power button in and holding for 2 seconds. The console will take a while to power on but whilst this is happening, turn on the FOH and REAR speaker AMPS. This is done by pressing the power buttons locating in the venue patching rack at the bottom and turning the two amps labelled “REAR” and “FOH” ON.

(23)

Designer

SOUND & VISION DESIGNER / QLAB OPERATOR SHOW PLOT Version #2 - Power on all Stage Audio, which consists of the three Subs and the two atmos

speakers, they are located in the upstage wall traps in the wall both OP and PS.

- Power on the ULXD4D rack which is located below the base station for Comms.

- Turn on the base station (HME DX200) by pressing the power button.

- Turn on the Show Relay which is located above the base station, by pressing the power switch onto the ON position. Please note that the LED lights are broken and do not work but if the switch is in the ON position, the show relay is on.

- Wireless Microphones:

o The Wireless microphones that are used in the show are the ULXD SM58. There are two of these used, on the desk Chan 9 is the Primary and Chan 10 is the Secondary. On the physical microphone the primary has been labelled for ease of locating it for the actors.

o Before each show the batteries MUST be changed with new fresh AA batteries.

These batteries can be located in the Audio Cupboard.

o Each microphone requires two AA batteries.

- Sound Check:

o Play the Preshow Check group in the show file. Mute channels 1 through 11 at the desk and bring up each speaker and turn it on and check that sound is coming out, then move onto the next speaker.

o Once this is done, press the RECALL button located above the master fader and recall “MND18”.

- Hour Call:

o Mic Check with Cast:

§ Once Ms Grima, is ready with the cast after fight call get Ms Tucker, Ms Price and Mr Carseldine to get ready for a Mic Check. Make sure the Primary and Secondary microphones are switched on and are receiving signal at the desk.

§ Turn on Chan. 9 on the desk and bring up the fader to -10db.

§ Get cast to say a couple of their lines when they use the microphone and make sure there is no feedback.

o Once Mic Check is complete, get Ms Grima to turn off both microphones and place them in there pre-set positions.

- Archival

o Turn on the Blackmagic Video Switcher at the front of its housing which is located underneath the projector.

o Put the SD card into SD 1 into each of the Hyperdeck Minis and Click MENU, then click SET, then use the wheel to scroll down to Format, click set, then select SD1, then SET, then OX Extended, then set, then confirm that you are wanting to format the SD card. Do this for all three SD cards.

o Power on the Cameras by opening the screens on the physical device in the seating bank.

o Make sure the ZOOM H6 Recorder (located on top of the switcher) has power.

o Plug in the SD card and format it.

- 10 Minutes to Beginners:

o Do the Archival Warning over comms.

(24)

Designer

§ Ladies and Gentlemen of the A Midsummer Night’s Dream Company.

Please be advised that comms and archival recording will commence shortly, comms and archival recording will commence shortly. Thank you Beginners:

o Start recording on the three hyperdecks and the Zoom.

o Do the Comms recording announcement over comms:

§ Ladies and Gentlemen of the A Midsummer Night’s Dream Company, this is comms recording for A Midsummer Night’s Dream, Show Number #, 15/16/17/18/19/20th October, 2018. Please be advised that comms are now recording. Please be advised that comms are now recording.

During the Show:

- When instructed by SM go into SND Q 0.5 (Preshow).

- Shutter the projector when instructed by Head LX for Blackout check.

- Respond to standby’s with Sound when SM puts up standbys.

- When a MIC Q is called, press Chan. 9 ON and ride the fader up.

- Write down any notes of nothing that went wrong during the show.

Power Down:

- Once Front of House Clearance has been given, save the show file on both the Sound Mac Mini and the Vision Mac Pro

- Stop recording on the Hyperdecks and the Zoom.

o Take out all SD cards and start downloading content off them onto Archive Lacie Hardrive.

- Power down the projector by pressing the Standby button and then selecting the OK button.

- Power down the Mac Pro.

- Power off all stage audio speakers and the FOH & REAR Amps.

- Power down the audio sound console by press and holding the power button and pressing it again. This will power down the console.

- Turn off the wireless microphones and the ULXD40 Receiver.

- Turn off the Comms base station.

- Power off the vision power board.

- All systems will have been powered down.

(25)

Subject to Change Correct as of 15/10/18 11:30 am Ben Mills | Sound & Vision Designer / Qlab

Operator

A MIDSUMMER NIGHT’S DREAM SOUND CUE SYNOPSIS Version #3

LEGEND:

BOLD = Cue Point

CUE Unit Page Cue Name Source Line/Blocking Notes

SND Q 0.5

Preshow

- Pre-show TBC SM's Discretion W/ SHUT Close

SND Q 0.7 - FOH Clearance TBC FOH Clearance

SND Q 1 1

Fade & Stop Pre-

show -

Front of House

Clearance. After song has finished

W/ VISQ Q 1 & SHUT Open

Dream Sequence - SpookyWind_V3.

- RA by Slumberjack - AthensWorld_Atmos

2 1 Fade Up Atmos - AthensWorld_Atmos After Hippolyta wakes up.

SND Q 3 6 5 Door Open - DoorOpen_CreakyV1 VISQ: HELENA opens the fourth wall door.

SND Q 3.5 6 5 Door Slam Close -DoorSlamClose_V2 VISQ: as HELENA steps onto stage from stairs.

MIC Q 1 7 6 MIC ON - Wireless SM58 W/ SND Q 3.5 Through FOH L & R

SND Q 4 7 7 Forest Fairy Theme - ForestFairyTheme_V3 - ForestWorld_AtmosV1

BOTTOM: Hold or cut

bow strings! W/ VIS Q 2.5

MIC Q 2 8 7 MIC OFF - Wireless SM58 W/ SND Q 4

SND Q 4.5 8 7 Fade Out and scratch -ComedicScratch_V1 PUCK Entrance SNAP OUT SND Q 5 8 8 Oberon Entrance -OberonEntrance_V2 PUCK: wanderer of the

night. Rear R, Atmos R, Sub

(26)

Operator

A MIDSUMMER NIGHT’S DREAM SOUND CUE SYNOPSIS Version #3 SND Q 5.5 8 8 TITANIA Entrance

Sound -ForestFairyTheme_V2 PUCK: here comes Oberon

SND Q 6 12 12 Fade Low Fairy Lullaby

-ForestFairTheme_V3

OBERON: "I know a bank."

SND Q 6.1 12 12 Fade Up Fairy Lullaby TITANIA Enters

SND Q 6.2 12 12 Fade Up Fairy Lullaby OBERON: Dances and

delight.

SND Q 6.5 12 12 Fade Down Fairy

Lullaby COBWEB: Now all is well

SND Q 6.7 12 12 Cigarette Sound

(breathing something) - CigaretteEnhale_V1

VISQ: Flute put the cigarette in his mouth the right way.

SND Q 7 12 12 TITANIA Orgasm -TitaniaOrgasm_V4 OBERON: Wake when

some vile thing is near W/ VIS Q 3.5 SND Q 8 13 12 Siri Response -SiriResponse_V2

LYSANDER: …you faint with wandering in the wood

SND Q 9 14 13 Lysander Orgasm - LysanderOrgasm_V2 PUCK: Sleep his seat on

thy eyelid w/ VISQ 4.5

SND Q 10 15 14 Glass Smash -GlassSmashWall_V1 VISQ: Lysander punches fourth wall on DSPS SND Q 10.5 15 Bottom Transition into

Donkey

-

BottomTransitionDonkey_V1

VISQ: When Bottom puts his foot up on rostra.

MIC Q 3 17 15 MIC ON - Wireless SM58 QUINCE Entrance

(27)

Operator

MIC Q 4 17 16 MIC OFF - Wireless SM58 BOTTOM: Odours

savours sweet

MIC Q 5 17 17 MIC ON - Wireless SM58 PUCK: I'll follow you, I'll lead you about a round…

MIC Q 6 17 17 MIC OFF - Wireless SM58 PUCK: …at every turn.

SND Q 11 18 18 Bottom Dancing - Let's Get It On_V1 VISQ: PUCK presses remote button

MIC Q 7 18 18 MIC ON - Wireless SM58 W/ SND Q 11 Will on Mic.

SND Q 11.5 18 18 Fade Down Bottom Dancing

- Let's Get It On_V1

TITANIA: What an

angle... Fade Down

SND Q 11.7 18 18 Fade Up Bottom Dancing

TITANIA: …from my

flowery bed? Fade Up

SND Q

11.75 18 18 Fade Out Bottom Dancing

VISQ: Bottom falls over

DSOP Long Fade

SND Q 12 18 18 Flying Moth -FlyingMoth_V1 TITANIA: Cobweb! Moth!

SND Q 12.5 18 18 Button Running into

Fourth Wall -ButtomRunningIntoDoor_V1 VISQ: Button runs DS into Fourth wall.

SND Q 13 19 19 Fade Up Rave Music

-RaveMusic_V1

PUCK: HOW NOW MAD SPIRIT

SND Q 13.2 19 19 Fade Out Rave Music VISQ: Oberon presses

REMOTE

(28)

Operator

SND Q 13.5 19 19 Fade Up Rave Music VISQ: Oberon presses

REMOTE

SND Q 13.7 19 19 Fade Out Rave Music VISQ: Oberon presses

REMOTE

SND Q 14 19 20 Demetrius Orgasm -DemetriusOrgasm_V1 OBERON: remedy. W/ VIS Q 5 SND Q 15 22 25 Puck Boxing Ring -PuckBoxingRingV1 VISQ: PUCK getting

angry.

MIC Q 7 22 25 MIC ON -

VISQ: Puck picking up microphone, walking into rostra

SND Q 15.5 22 25 SLOWMO Boxing -PuckBoxingRingSlowmoV0 VISQ: Puck climbs into the Upstage Box.

SND Q 15.6 22 23 Fade Out PUCK

Boxing Ring -PuckBoxingRingSlowmoV1

SND Q 15.7 22 26 Flower on Titania -FairyForestMusic_V1 PUCK: Gentle lover, remedy

MIC Q 8 22 26 MIC OFF - PUCK: and all things

shall be well.

SND Q 16 23 26 Titania' Lap Dance

- Pony

PUCK: shall be well (beat)

SND Q 16.2 23 26 Fade Down Titania

Lap Dance TITANIA: Come sit thee

SND Q 16.3 23 26 Fade Down and Stop

Titania Lap Dance TITANIA: By gentle joy

SND Q 16.9 24 27 BIRD CALL -BirdCall_V1 PUCK: I do hear the

morning lark.

(29)

Operator

A MIDSUMMER NIGHT’S DREAM SOUND CUE SYNOPSIS Version #3 SND Q 17 28 30 Flute' Sad Leaf

Blower

- Only Time_V1

VISQ: As Flute enters

from USPS W/ VIS Q 6.5

SND Q 17.5 28 30 Stop Flute' Sad Leaf Blower

VISQ: Quince takes out

Flutes earphones. Snap Out SND Q 18 29 31 Grand Entrance

Music -GrandEntranceMusic_V1 VISQ: QUINCE presses

remote. W/ VIS Q 7.5

MIC Q 8 30 32 MIC ON - Wireless SM58 QUINCE: If we offend... W/ SND Q 18.

SND Q 18.5 30 32 STOP Grand

Entrance Music -GrandEntranceMusic_V1 VISQ: QUINCE presses remote.

SND Q 19

30 32

Entrance Music

-GrandEntranceMusic_V1

QUINCE: The actors are at hand

SND Q 19.5 Fade down Entrance

Music

VISQ: QUINCE presses remote.

SND Q 20

31 32

Entrance Music -GrandEntranceMusic_V1 W/ MIC Q 9

SND Q 20.5

WALL Theme

-WallTheme_V1 VISQ: Wall stomps her right foot onto rostra DS.

Fade and stop Entrance music SND Q 21

31 32

PYRAMUS Entrance

Theme -

PyramusEntranceTheme_V2

SND Q 21.5 Stop Pyramus Theme VISQ: QUINCE presses

remote.

SND Q 22

31 33

Thisbe Entrance Theme

- ThisbeEntranceTheme_V2

SND Q 22.5 Stop Thisbe Entrance

Theme

(30)

Operator

A MIDSUMMER NIGHT’S DREAM SOUND CUE SYNOPSIS Version #3 SND Q 23

31 34

Lion Theme

-LionTheme_Roar_V1

SND Q 23.5 Stop Lion Theme VISQ: QUINCE presses

remote.

SND Q 24

31 34

Moon Theme

-MoonTheme_V1

SND Q 24.5 Stop Moon Theme VISQ: QUINCE presses

remote.

SND Q 26

31 34 Thisbe Theme

SND Q 26.5

Stop Thisbe Teme

SND Q 27

31 35

Pyramus Theme

-

PyramusEntranceTheme_V2

SND Q 27.5 Stop Pyramus Theme VISQ: QUINCE presses

remote.

SND Q 28 Thisbe Theme

SND Q 28.5 Stop Thisbe theme VISQ: QUINCE presses

remote.

SND Q 29 Glass Wall Smash - GlassSmashing_V1 VISQ: BOTTOM runs into the fourth wall DSPS.

SND Q 30 Thisbe Theme

SND Q 30.5 Stop Thisbe theme VISQ: QUINCE presses

remote.

(31)

Operator

SND Q 31

36

Grandfather Clock Chime

-GrandfatherClockChime_V1

THESEUS: Very notable discharged.

SND Q 31.5

Fade and stop

Grandfather Clock PUCK: Tis only fairy

time"

Fade low Fairy

Lullaby -FairyForestMusic_V1 SND Q 32 32 37 Techno Rave

-RaveMusic_V1

PUCK: Now are frolic.

SND Q 32.5 32 37 Slow-mo Techno Rave

TITANIA: Now, until the break of day.

SND Q 33 32 37 Build up Techno Rave TITANIA: Trip away

SND Q 34 32 37

Fade Out Techno Rave. W/ mic drop voom sound.

TBC TITANIA: break of day

MIC Q 16 32 37 MIC OFF - Wireless SM58 W/ SND Q 34

VISQ 8.5 32 37 VISQ 8.5 - Particles

Dissolve VIS CONTROL MAC PRO PUCK: Shall restore

amends." W/ SHUT Q (Close) SND Q 35 Post

show 37 Post show - Run the World Girls

VISQ: After bows

TITIANIA presses remote button.

Post show Music TBC

(32)

Operator

A MIDSUMMER NIGHT’S DREAM APRA APPLICATION Version #1

APRA SONG ID (GW CODE)

SONG (Musical

Work)

COMPOSER(s) (Arranger – if applicable)

PERFORMER(s) DURATION (to be used)

00:00

PUBLISHER (office use

only)

GW24012401

ONLY TIME BRENNAN E/RYAN N/RYAN R

ENYA 01:00

GW15169885 MY HEART WILL GO ON

HORNER J/JENNINGS W CELINE DION

00:30 GW14869458

I’M KISSING YOU WEEKES D/ATACK T

Des’ree 01:00

GW17404752

BELIEVE HIGGINS B/TORCH S/BARRY P

Cher 00:30

GW36509311

I KISSED A GIRL /HUDSON K/GOTTWALD L/DENNIS C/SANDBERG M

Katy Perry 00:30 GW43363438 DIAMONDS LEVIN B/ERIKSEN M/FURLER S/HERMANSEN T

Rihanna 00:30

GW23927679 I’M COMING OUT RODGERS NILE GREGORY Diana Ross 00:30

GW00360345 I WILL SURVIVE FEKARIS D/PERREN F

GLORIA GAYNOR 00:30 GW26172320 RESPECT COLES/DIGGS/HAWKINS/HUNTER/JONES/WOODS/S

ARETHA FRANKLIN 00:30 GW01061651 YOU DON’T OWN

ME

MADARA J/WHITE D

GRACE 00:30

GW02766131 SISTERS ARE DOIN’ IT FOR THEMSELVES

LENNOX A/STEWART D

EURYTHMICS

00:30

GW01069269 LETS GET IT ON TOWNSEND E/GAYE M MARVIN GAYE 00:45 GW12128864 ^PONY MOSLEY T/LUMPKIN E/GARRETT S

GINUWINE 00:45

GW44740641 ^ROAR PERRY/MCKEE/GOTTWALD/WALTER/SANDBERG

KATY PERRY 00:45

(33)

Operator

A MIDSUMMER NIGHT’S DREAM APRA DURATION Version #1

APRA SONG ID (GW CODE)

SONG (Musical

Work)

COMPOSER(s) (Arranger – if applicable)

PERFORMER(s) DURATION (to be used)

00:00

PUBLISHER (office use

only) GW24012401

ENYA 01:00

GW49902588

RA EHLERS F/THEN Y

SLUMBERJACK 00:30 GW01069269 LETS GET IT

ON

TOWNSEND E/GAYE M

MARVIN GAYE 00:45 GW12128864

PONY MOSLEY T/LUMPKIN E/GARRETT S

GINUWINE 00:45

GW44740641 ROAR PERRY/MCKEE/GOTTWALD/WALTER/SANDBERG KATY PERRY 00:45 GW24012401

ENYA 01:00

(34)

Subject to Change Correct as of 15/10/2018

Ben Mills & Stephanie Yau | Sound & Vision Designer / Set, Costume & Vision Design

A MIDSUMMER NIGHT’S DREAM VISION CUE SYNOPSIS Version #3

CUE Unit Page Cue Name Line/Blocking Notes

SHUT Q 1 Preshow 1 Shutter Close With SND Q 0.5

SHUT Q 2 Preshow 1 Shutter Open VIS Q: As Pre-show song finishes

VIS Q 1 1 1 Dream Sequence With SND Q 1

Athens World

VIS Q 2 7 7

Transition into Forest

With SND Q 4 - Bottom: Hold or cut bow strings!'

VIS Q 3 12 12 TITANIA orgasm With SND Q7 - OBERON: Wake when some vile thing is near

VIS Q 4 14 13 Lysander orgasm With SND Q9 - PUCK: …on thy eyelid

VIS Q5 19 20

Demetrius orgasm

With SND Q14 - Oberon: Beg of her for remedy

VIS Q6 28 31 Return to Athens World VIS Q: As mechanicals exit VIS Q7 29 Athens into Pyramus &

Thisbe With SND Q18

VIS Q 7.5 32 37 Vision fade out (Snap)

PUCK: Shall restore amends.

SHUT Q 3 32 37 Shutter Close

With SND Q35

Sound & Vision Bible

A MIDSUMMER NIGHTS DREAM

Complied by: Ben Mills
