KEMENTERIAN KESEHATAN REPUBLIK INDONESIA

P O L I T E K N I K K E S E H A T A N T A S I K M A L A Y A

Jalan Cilolohan Nomor 35 Kota Tasikmalaya 46115 Telp. 0265-340186

BERITA ACARA ADDENDUM

PEKERJAAN PENGADAAN ALAT PRAKTEK LABORATORIUM UNTUK MAHASISWA

POLITEKNIK KESEHATAN TASIKMALAYA TAHUN ANGGARAN 2012

Nomor : PL.01.01.1.09.12.003

Pada hari ini Jum’at tanggal Dua puluh satu bulan September tahun Dua ribu dua

belas, Kami Panitia Pengadaan Barang Pengadaan Alat Praktek Laboratorium Untuk

Mahasiswa pada Politeknik Kesehatan Tasikmalaya melaksanakan Perubahan Dokumen

dikarenakan adanya beberapa poin yang membingungkan para peserta pengadaan Alat

Praktek Laboratorium Untuk Mahasiswa pada Politeknik Kesehatan Tasikmalaya.

Perubahan tersebut adalah :

1. Untuk Spesifikasi bertambah poinnya dan isian kolom Quantity jumlahnya sama

dengan yang ada pada BoQ, dengan perubahan terlampir dalam Berita Acara

Addendum ini;

2. Untuk Bill of Quantity (BOQ) nama barang disamakan dengan yang ada pada

Spesifikasi Barang, dengan perubahan terlampir dalam Berita Acara Addendum ini;

3. Untuk Surat menyurat yang berhubungan dengan pekerjaan ini ditujukan kepada

Panitia Pengadaan Barang Politeknik Kesehatan Tasikmalaya.

Perubahan dokumen hanya pada poin yang disebutkan di atas.

Demikian Berita Acara Addendum ini dibuat untuk dipergunakan sebagaimana

mestinya.

Tasikmalaya, 21 September 2012

PANITIA PENGADAAN BARANG

POLITEKNIK KESEHATAN TASIKMALAYA

(2)

Vol Sat H.Satuan Jumlah

1 2 3 4 5 6 =3 X 5

A Jurusan Kesehatan Gigi

1 Electric Dental Unit 6 unit 2 Binocular Microscope 7 unit B Jurusan Gizi

1 Analytical Balance 4 unit

2 Lemari Asam 2 unit

3 Photometer 1 unit

4 Microlitre and Haematocrit Centrifuge 3 unit

5 Drying Oven 1 unit

6 Digital Water Bath 4 unit 7 Binocular Microscope 4 unit 8 Digital Hotplate Stirer 5 unit

9 Autoclave 2 unit

10 Fixed Volume Single Pipette 5 set

11 pH Meter 5 unit

C Jurusan Farmasi I Lab Farmaseutik (silid)

1 Drying Oven 1 unit

II Lab Kimia Analitik

1 UV-Visible Spectrophotometer 1 unit 2 High Performance Liquid Chromatography 1 unit III Lab Farmaseutik ( Sterill)

1 Lemari Asam 1 unit

2 Autoclave 1 unit ………..., ………...2012 Penyedia Barang, CV. / PT. ……….. ttd & stempel (NAMA JELAS) (JABATAN)

KOP SURAT

RINCIAN ANGGARAN BIAYA

PENGADAAN ALAT PRAKTEK LABORATORIUM UNTUK MAHASISWA

POLITEKNIK KESEHATAN TASIKMALAYA TAHUN ANGGARAN 2012

No Nama Barang (Merek Barang)

Jumlah PPn 10%

Total Dibulatkan

(3)

No Nama Alat Spesifikasi teknis yang diminta Spesifikasi teknis yang di tawarkan Merk Type Negara Qty

A Jurusan Kesehatan Gigi

1 Electric Dental Unit Produk telah teregristrasi di Kementerian Kesehatan RI/ Depkes 6

Memiliki Sertifikat SNI (Standar Nasional Indonesia) Memiliki Sertifikat ISO/ SMI (Standar Mutu Internasional) TUV Certificate

Specification : Set Includes :

1. Chair with up and down movement, and back forward movement 2. Instrument table is adjustable horizontal and vertical with equipments: - X-Ray film viewer

- Low Speed airmotor - Three way syringe - Foot controller -Waste receptable - Airturbine handpiece (x 2) - Straight handpiece - Contraangle handpiece 3. Hydogroup

4.Adjustable Operating Lamp 5. Doctor's Stool

6. Include Compressor, with Power min. 1 HP, Power : 220 V, 50 Hz SPESIFIKASI BARANG

PENGADAAN ALAT PRAKTEK LABORATORIUM UNTUK MAHASISWA POLITEKNIK KESEHATAN TASIKMALAYA TAHUN ANGGARAN 2012

(4)

2 Binocular Microscope Specification : 7

Optical System : Colour-corrected infinity optics Parfocal distance : +/- 45 mm

Tube length : +/- 180 mm Magnifications : 40x to 1000x Eyepieces Tubes :

- Swiveling Siedentopf tube with upper and lower position - Rotatable tube 360°

- Viewing angle : 30°

Eyepieces : 10x / 18 Br. Foc and All eyepieces anti-fungus treated Nosepiece : 4x

Objective : objectives "Plan-Achromat"4x, 10x, 40x, 100x oil Quick control of light intensity by user

Filter Set : 3 Filter Set

Condenser : Abbe Condenser 0.9 / 1.25

Fixed-Koehler fields of view 18mm B Jurusan Gizi

1 Analytical Balance Specification : 4

• Display : LCD black & white

• Two communication port ; RS-232C and USB

• Fully automatic motorized Leveling system with one touch of a button Weighing Capacity : min 200 g

Readability : 0.1 mg

Response time (Average) : ≤ 3 s Repeatability : ≤± 0.07 mg linearity : ≤± 0.2 mg

Corner Load (100g) : ± 0.2 mg

2 Lemari Asam Specification : 2

Fume hood width : +/- 1.2 m Exhaust outlet diameter : ±305 mm Max sash opening : ±740 mm

Controller : real time digital display of face microprocessor Construction : Tri wall construction

- Work surface : Phenolic Resin Laminate

- Main Body : Fabricated of electro-galvanized steel

- Coating : Epoxy polyester hybrid antimicrobial powder coating Included : Installation, base cabinet, dispenser pipet, Blower, UPS

(5)

3 Photometer Specification : 1

-Optical system : Halogen lamp

- Interferential filters (nm) : 340, 405, 505, 546, 578, 630

- Linearity photometric : - 0,3000 to 2.9999 O.D. with accuracy : +/- 2% at 0.700 O.D.

- Reading volume : min 300 µL - 9 wells for open cuvette incubation - Functionality autodiagnosis - 199 programmable programs

- Power Supply : 230/115 VAC, 50-60 Hz, 83 VA

4 Microlitre and Haematocrit Centrifuge Specification : 3

speed (max.) : Angle Rotor 14.000 rpm / Haematocrit Rotor 12.000 rpm RCF (max.) : Angle Rotor 18.188xg / Haematocrit Rotor 14.811 xg

Capacity (max.) : Angle Rotor 24x2 ml / Haematocrit Rotor 24 x capacity tubes Control system : Microprocessore

Digital displays for speed

Timer : 1 - 99 min. And Hold position Epoxy - polyester painted steel chamber pulse Key

Brushless induction motor Motor Over heating protection Lid Lock and interlock. 230 V, 50/60Hz Accessories :

Angle ( Microlite ) Rotor 24x1.5/2 ml 14.000 rpm, 14.188 xg Haematocrit Rotor 24xcapillary tube 12.000 rpm, 14.811 xg

5 Drying Oven Specification : 1

- Capacity : min. 30 Liter

- Range temperature : Ambient +5°C to 250°C with accuracy ± 1.0 °C -Material Inner Stainless Steel

- Controller Digital PID - Shelves : Adjustable 2 or 3

- Electronic supply : 110 V, 60 Hz or 220 V, 50/60 Hz

6 Digital Water Bath Specification : 4

- Capacity : min. 20 liter

- Range temperature : Ambient +5°C to 99°C with accuracy ± 0.1 °C - Material Bath Seamless Stainless Steel, Case Powder Coated Steel - Electric Supply : 110 V, 60 Hz or 220 V, 50/60 Hz

(6)

7 Binocular Microscope Specification : 4

Optical System : Colour-corrected infinity optics Parfocal distance : +/- 45 mm

Tube length : +/- 180 mm Magnifications : 40x to 1000x Eyepieces Tubes :

- Swiveling Siedentopf tube with upper and lower position - Rotatable tube 360°

- Viewing angle : 30°

Eyepieces : 10x / 18 Br. Foc and All eyepieces anti-fungus treated Nosepiece : 4x

Objective : objectives "Plan-Achromat"4x, 10x, 40x, 100x oil Quick control of light intensity by user

Filter Set : 3 Filter Set

Condenser : Abbe Condenser 0.9 / 1.25

Fixed-Koehler fields of view 18mm

8 Digital Hotplate Stirer Specification : 5

- Speed Range : 60 to 1500 rpm

- Range temperature : Ambient +5°C to 400°C - Microprocessor Digital Feedback Control - Power consumption : ± 500 watt

- Electric supply : 90 V, 60 Hz or 240 V, 50/60 Hz

9 Autoclave Specification : 2

Chamber Capacity : min. 30 liters Automatic Operation

Sterilization temperature :up to minimal 125o C Main Controller : precise pressure switch Equipped with Safety device and eletric safety

Automatic Exhaust systems of the remained air by heat expansions bellow valve. Automatic Cut-off systems by a sensitive thermostate

(7)

10 Fixed Volume Single Pipette - Fixed Volume single pipette (1 x) : 10 µl, 50 µl,100 µl, 200 µl, 500 µl, 1000 µl 5

- Ergonomic design - fully autoclavable - color code

- Super blow out piston

11 pH Meter Specification : 5

Display : Graphic and soft keys.

pH : -2,000 … +20,000 with accuracy ± 0.005

Voltage : -2,000 mV… +2,000 mV with accuracy ± 0.2 < |1,000|, ± 1>|1,000|(mV)

Memory data storage : minimal 400 C Jurusan Farmasi

I Lab Farmaseutik (silid)

1 Drying Oven Specification : 1

- Capacity : min. 30 Liter

- Range temperature : Ambient +5°C to 250°C with accuracy ± 1.0 °C -Material Inner Stainless Steel

- Controller Digital PID - Shelves : Adjustable 2 or 3

- Electronic supply : 110 V, 60 Hz or 220 V, 50/60 Hz II Lab Kimia Analitik

1 UV-Visible Spectrophotometer Specification : 1

* Xenon flash lamp , full-spectrum * 2 silicon diode detectors

* Wavelength Range : 190–1100 nm

* Wavelength accuracy (nm) : + 0.5 - 541.94 * Wavelength reproducibility (nm) : + 0.05 - 0.20 * Photometric range (Abs) : + 2.5 - 4.0

* Photometric accuracy (Abs) : Abs : 0.003 - 0.007 Abs * Spectral bandwidth (nm) : 1.5 nm or better

* Scan rate : minimum 23500 nm/min

(8)

No Nama Alat Spesifikasi teknis yang diminta Spesifikasi teknis yang di tawarkan Merk Type Negara Qty 2 High Performance Liquid

Chromatography

Specification : 1

Consist of HPLC Pump (1 x) Binary Gradient Pump

- Flow range : 0.0 – 10.0 ml/min - Flow Precision : < 0.1% RSD or less - Flow Accuracy : +/- 1.0 % or less - Gradient Profile: > 9 Curves Manual Injector (1 x) Syringe 100 ul (1 x) UV/Vis Detector (1 x) - Dual wavelength

- Wavelength range : 190 – 600 nm or higher - wavelength accuracy : +/- 1 nm or less - Light Source : D2 lamp for UV and Viscible

- Flow Cell is designed in such way to reduce reflection of the light and maximize the light reach the detector to optimize sensitivity

- Lamp optimization to give consistent performance Data System

- LC Software (1 x)

- Computer system with Windows XP Pro, Monitor, Printer (1 x) Solvent Filtration Kit (1 kit)

Sample/Standard Filtration Kit (1 pkg)

C18 4.6 x 150mm + Guard Column and Guard Holder (1 x) III Lab Farmaseutik ( Sterill)

1 Lemari Asam Specification : 1
