BERITA ACARA PENJELASAN PEKERJAAN
Nomor :
40/Pokja-ULP/Poltekba/X/2015
Kegiatan
:
Pengadaan Sarana dan Prasarana Pendukung Pembelajaran
Paket Pekerjaan :
Peningkatan Infrastruktur TIK dan Peralatan Lab. Telekomunikasi Jurusan
Teknik Elektronika
Lokasi pekerjaan :
Kampus Poltekba Jln. Soekarno Hatta Km.8 Balikpapan
Sumber Dana
:
A P BN
Tahun Anggaran
:
Tahun Anggaran 2015
Pada hari ini,
Senin
tanggal
Lima
bulan
Oktober
tahun
Dua Ribu Lima Belas
, dimulai pukul
09.00 Wite, Pokja ULP Pengadaan Barang/Jasa Paket Pekerjaan
Peningkatan Infrastruktur TIK
dan Peralatan Lab. Telekomunikasi Jurusan Teknik Elektronika
, bertempat di
Kampus Poltekba Jln.
Soekarno Hatta Km.8 Balikpapan telah mengadakan penjelasan pekerjaan/Aanwijzing terhadap
pekerjaan sebagaimana tersebut diatas.
Pokok-pokok pembahasan adalah sebagai berikut :
1.
Penjelasan dilakukan untuk menjelaskan maksud, tujuan, mekanisme/prosedur dan tata
cara pelaksanaan pemilihan penyedia barang yang dilaksanakan sesuai dengan Peraturan
Presiden Nomor 54 Tahun 2010 dan Perubahannya tentang Pengadaan Barang/Jasa
Pemerintah dan syarat-syarat yang ditentukan yang berkaitan dengan pekerjaan ini
2.
Cara penyampaian dokumen penawaran
:
a)
Peserta menyampaikan Dokumen Penawaran kepada Pokja Pengadaan :
1)
Pertama-tama, mengirimkan data kualifikasi melalui melalui aplikasi SPSE ;
2)
Dilanjutkan dengan mengunggah file penawaran dan data isian kualifikasi
terenkripsi melalui aplikasi SPSE sesuai jadwal yang ditetapkan.
b)
Penyampulan dokumen penawaran dengan menggunakan
metode 1 (satu) file
;
c)
Dokumen penawaran yang disampaikan (
di Upload
) oleh peserta pengadaan :
berlaku
ketentuan sebagaimana diatur dalam Dokumen Pengadaan BAB.III IKP Pasal 15 dan
BAB.IV Lembar Data Pemilihan, beserta perubahannya.
d)
File disandikan dengan aplikasi Pengaman Dokumen (APENDO)
e)
Peserta wajib mengetahui dan mengikuti ketentuan penggunaan APENDO yang
tersedia pada aplikasi APENDO.
f)
Peserta hanya dapat menyampaikan Dokumen Penawaran kepada Pokja melalui
aplikasi SPSE.
g)
Peserta dapat mengirim data kualifikasi dan mengunggah file penawaran secara
berulang sebelum batas akhir waktu pemasukan Dokumen Penawaran. Data
kualifikasi dan file penawaran terakhir akan menggantikan data dan file yang telah
terkirim sebelumnya.
h)
File penawaran dan kualifikasi
yang disampaikan kepada Pokja melalui aplikasi SPSE
harus dapat terbaca dengan jelas
, jika file yang disampaikan tidak dapat terbaca
dengan jelas oleh Pokja akan dinyatakan tidak memenuhi syarat dan dianggap gugur.
3.
Pembukaan dokumen penawaran :
2)
Terhadap file penawaran yang tidak dapat dibuka (didekripsi), Pokja menyampaikan
file penawaran tersebut kepada LPSE untuk mendapat keterangan bahwa file yang
bersangkutan tidak dapat dibuka. Selanjutnya Pokja menetapkan penawaran tidak
memenuhi syarat. Apabila dapat dibuka, maka Pokja akan melanjutkan proses atas
penawaran yang bersangkutan.
3)
Penawaran yang memenuhi syarat adalah dokumen penawaran yang berhasil dibuka,
yang terdiri dari data kualifikasi dan penawaran administrasi, teknis dan harga.
4.
Metode evaluasi : dilakukan dengan sistem gugur
.
[Pokja menggunakan evaluasi teknis dengan menggunakan sistem ambang batas]
5.
HAL-HAL YANG MENGGUGURKAN PENAWARAN
: apabila ketentuan yang
disyaratkan sebagaimana dimaksud dalam penjelasan angka 2.c) diatas :
tidak terpenuhi /
tidak lengkap.
6.
Jenis kontrak yang akan digunakan :
Kontrak Harga Satuan
;
Pertanyaan Peserta Lelang dan addendum dokumen pengadaan : terlampir
.
Demikian Berita Acara ini dibuat untuk dipergunakan sebagaimana mestinya.
Samarinda ; 05 Oktober 2015
Ttd
Home Daftar Paket Berita Lelang Non Eproc Log Akses Ganti Password
Petunjuk penggunaan | Aplikasi e-procurement lainnya
Muhammad Ramli, S.Sos. - Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi
Pertanyaan Terhadap Dokumen Lelang
Nama Paket : Pengadaan Peningkatan TI K dan Peralatan Lab. Telekomunikasi Jurusan Teknik Elektronika Poltekba Sisa Waktu : 0 hari / 0 jam / 0 menit
Daftar Paket View Lelang Penjelasan Lelang
Pertanyaan Peserta
Dokumen Bab Uraian Pengirim
Dokumen Lelang TI K BAB I V. LEMBAR DATA PEMI LI HAN (LDP) - Poin S (Lainnya)
1. Mengenai Tenaga Teknis: Pertanyaan: Untuk tenaga Ahli yang terdaftar pada Asosiasi Kontraktor Listrik dan Mekanikal Apakah bisa diganti dengan Tenaga Ahli yang berkualfikasi di Bidang Listrik dan Mekanikal (dilengkapi Sertifikat Keahlian) 2. Mengenai Surat Dukungan: Pertanyaan: Untuk proses pembuatan Surat Dukungan untuk semua perangkat dimana total 111 item membutuhkan waktu yang cukup lama Apakah bisa untuk Surat Dukungan diperuntukkan untuk beberapa I tem perangkat yang wajib saja? 3. Mengenai Surat Jaminan Purna Jual: Pertanyaan: Kami selaku penyedia pasti akan menjamin layanan purna jual dan garansi perangkat selama 1 tahun Untuk Surat Jaminan Purna Jual apakah bisa diganti dengan Surat Pernyataan dari Penyedia diatas materai yang isinya Jaminan Purna Jual untuk semua perangkat selama 1 tahun?
8660169
5 Oct 2015 08: 03
Dokumen Pengadaan I V LDP 1. Mohon konfirmasi nama yang benar untuk nama POKJA ini, karena nama Pokja antara yg tertera pada bab I V dan Bab V berbeda
8662169
5 Oct 2015 08: 07
Dokumen Pengadaan Barang
XI I Kepada Yth. Panitia , Mohon di bantu pertanyaan seputar instalasi teknis pada Bab XI I (Spesifikasi Teknis) , sbb : - Mengenai barang pintu dua daun pintu , termasuk kusen dan kunci (door replacement for access control including door frame , door leaf dan lockset) , berapa ukuran daun pintu nya untuk masingmasing ? Dan bahan apa yang di minta ? -Kabel Tray dan aksesoris pendukung , apakah dapat diberikan lay out kabel tray yang di maksud ? - Untuk UPS 10 KVA , apakah harus menggunakan HSGPower ? - Cable Electrical untuk Pangkalan Data dan Automatic Light Control, mohon di jelaskan lebih lanjut panjang dan type cable, Automatic Light Control seperti apa yang dimaksud ? - Panel Distribusi, apakah bisa di kirim line diagramnya (brp MCB/ MCCB yg dibutuhan) - Arrester dan aksesories pendukung, utk berapa besar yg dibutuhkannya dan diinstall dimana ? Terimakasih sebelum nya
8663169
5 Oct 2015 08: 09
Dokumen Lelang TI K BAB I V. LEMBAR DATA PEMI LI HAN (LDP) - Poin S (Lainnya)
Untuk Surat Dukungan ditujukan ke siapa? 8680169
5 Oct 2015 08: 18
Dokumen Pengadaan Barang
I V LDP Kepada Panitia : sehubungan dengan uraian singkat pekerjaan, Apabila kami akan melakukan survey dalam pengerjaan pekerjaan ini ke Poltek Balikpapan, kami bisa dibantu oleh siapa di Poltek Balikpapan ?
8662169
5 Oct 2015 08: 22
Pengadaan Barang Bab XI I Kepada Yth. Panitia , 1. Apakah kami diberikan butuh design ruangannya ? 2. Mengenai penempatan CCTV dimana saja? 3. Berapa lama untuk penyimpanan rekorder nya? 4. Utk cctv outdoor apakah diperlukan tiang tersendiri? Terimakasih sebelum nya .
8663169
5 Oct 2015 08: 47
RAB manakah yang benar, untuk kuantiti FO item # 17, 3000m (spek)? atau 4000 m (RAB)? 8661169
5 Oct 2015 08: 51
Dokumen Lelang TI K BAB I V. LEMBAR DATA PEMI LI HAN (LDP) - A. Lingkup Pekerjaan
Untuk Jangka Waktu Penyelesaian Pekerjaan Apakah ada perpanjangan untuk Jangka Waktu Pelaksanaan Pekerjaan? Mengingat Pekerjaan yang kompleks dan banyaknya item yang akan disediakan
8680169
5 Oct 2015 09: 09
Dokumen Pengadaan Barang
I V Uraian Singkat Pekerjaan dan Penjelasan dari panitia
Dalam penentuan harga penawaran , tentunya kami memerlukan data survey lapangan atau setidaknya lay out pengerjaan intalasi perangkat nantinya, untuk itu mohon lay out dapat diberikan bersamaan addendum aanwijzing ini
8662169
5 Oct 2015 09: 10
LPSE Universitas Mulawarman
http://lpse.unmul.ac.id/eproc/penjelasan/lelang/365169/PENJELASAN
Dokumen Pengadaan Barang
Bab XI I Kepada Yth. Panitia , - I ni penempatannya di bangunan baru atau bangun yang sudah berdiri lama? - Ada keterangan upgrade, apakah artinya semua ini menggantikan device existing ? Systemnya replace atau memang ini benarbenar baru dan tidak menggantikan existing ? -Kalau systemnya upgrade berarti device yang lama itu benar-benar diganti dengan yang barang baru ini ? Mohon penjelasan nya . Terimakasih .
8663169
5 Oct 2015 09: 16
Dokumen Lelang TI K BAB I V. LEMBAR DATA PEMI LI HAN (LDP) - Poin S (Lainnya)
Untuk Training mohon informasi: - Jumlah Peserta - Lokasi - Durasinya (berapa hari) 8680169
5 Oct 2015 09: 19
Lembar Data Pemilihan
Kepada Yth. Panitia ULP, apakah jaminan penawaran masih tetap diperlukan? 8668169
5 Oct 2015 09: 22
Kualifikasi Selamat Pagi, Apakah penyedia diwajibkan memiliki Management Sertifikat Mutu I SO 9001. Jika penyedia tidak memiliki I SO tersebut apakah akan digugurkan ? Terimakasih
8676169
5 Oct 2015 09: 30
Teknis Apakah TKDN dipersyaratkan ? Jika Peserta Lelang tidak membuat TDKN, apakah bisa menggugurkan peserta Lelang ?
8676169
5 Oct 2015 09: 32
Kualifikasi Kepada Yth. Panitia ULP, Apakah jaminan penawaran masih tetap diperlukan? 8676169
5 Oct 2015 09: 37
Teknis Pada spesifikasi teknis yang begitu banyak, apakah panitia dapat memberikan data tersebut dalam bentuk excel ?
8676169
5 Oct 2015 09: 41
Penjelasan Panitia/ Pokja ULP
Dokumen Bab Uraian Pengirim
Kepada Penyedia Jasa yang ingin bertanya kami persilahkan
Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi 5 Oct 2015 08:02
Kepada Penyedia Jasa yang ingin bertanya kami persilahkan
Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi
5 Oct 2015 08:02
8660169 LDP Untuk tenaga Ahli harus yang terdaftar pada Asosiasi Kontraktor Listrik dan Mekanikal
Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi
5 Oct 2015 08:13
8662169 LDP Surat Dukungan diusahakan sebanyak item yang tertera karena akan mempengaruhi poin penilaian
Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi 5 Oct 2015 08:17
8660169 Surat Jaminan Purna Jual Wajib disampaikan dan tidak dapat digantikan dengan Surat Pernyataan dari Penyedia
Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi 5 Oct 2015 08:19
8660169 LDP Nama Pokja adalah : Pokja Pengadaan ULP Politeknik Negeri Balikpapan
Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi
5 Oct 2015 08:23
8663169 Mengenai barang pintu dua daun pintu , termasuk kusen dan kunci (door replacement for access control including door frame , door leaf dan lockset) , ukuran daun pintu nya untuk masing-masing dapat dilihat pada Spec Teknis Nomer 52 Poin 2. Dan bahan yang di minta kayu bengkirai. - lay out kabel tray yang di maksud dapat diberikan setelah tanda tangan kontrak dan kebutuhan kabel sesuai volume di spec teknis.
Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi
5 Oct 2015 08:37
8680169 Untuk Surat Dukungan ditujukan ke : Pokja Pengadaan ULP Politeknik Negeri Balikpapan
Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi 5 Oct 2015 08:52
8662169 sehubungan dengan uraian singkat pekerjaan, tidak perlu dilakukan survey dalam pengerjaan pekerjaan ini ke Poltek Balikpapan, terkecuali sudah tanda tangan kontrak
Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi
5 Oct 2015 08:54
8663169 design ruangannya dapat diberikan setelah tanda tangan kontrak ? 2. penempatan CCTV sesuai design ruangan. 3. lama untuk penyimpanan rekordernya disesuaikan dengan kapasitas hardisk. 4. Utk cctv outdoor tidak diperlukan tiang tersendiri
Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi 5 Oct 2015 09:00
8661169 Untuk kuantiti FO item # 17, yang benar adalah 4000 m sesuai RAB.
Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi
5 Oct 2015 09:03
LPSE Universitas Mulawarman
http://lpse.unmul.ac.id/eproc/penjelasan/lelang/365169/PENJELASAN
07 Oktober 2015 05: 30 © 2006-2015 Lembaga Kebijakan Pengadaan Barang/ Jasa Pemerintah (LKPP) 8680169 Untuk Jangka Waktu Penyelesaian
Pekerjaan TI DAK ADA perpanjangan Waktu Pelaksanaan Pekerjaan.
Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi 5 Oct 2015 09:12
8662169 Dalam penentuan harga penawaran,
Penyedia Jasa hanya menyampaikan penawaran sesuai RAB dan Spec Teknis yang terlampir pada Dokumen Pengadaan dan Addendumnya.
Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi 5 Oct 2015 09:28
8663169 Penempatannya di bangunan baru dan bangunan yang sudah berdiri lama. -Ada keterangan upgrade, artinya tidak semua menggantikan device existing. Systemnya benar-benar baru.
Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi
5 Oct 2015 09:37
8680169 Untuk Training, -jumlah Peserta-Lokasi dan Durasinya sesuai yang ditawarkan oleh penyedia jasa yang penting dapat mendukung terlaksananya kegiatan ini
Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi 5 Oct 2015 09:42
8668169 Jaminan penawaran tidak diperlukan Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi
5 Oct 2015 09:43
8676169 Penyedia diwajibkan memiliki Management Sertifikat Mutu I SO 9001. Jika penyedia tidak memiliki I SO akan digugurkan
Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi 5 Oct 2015 09:47
8676169 Teknis TKDN dipersyaratkan, Jika Peserta Lelang tidak membuat TDKN tidak menggugurkan peserta Lelang
Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi 5 Oct 2015 09:52
8676169 Jaminan penawaran tidak diperlukan Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi
5 Oct 2015 09:52
8676169 Panitia tidak dapat memberikan data Spesifikasi teknis tersebut dalam bentuk excel, Untuk menghindari copy paste
Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi 5 Oct 2015 09:57
8663169 XI I Cable Electrical untuk Pangkalan Data panjangnya kurang lebih 100 Meter dan type serta model cable sesuai jenis peruntukan cable power untuk alat yang ditawarkan. Automatic Light Control ditiadakan dan akan dituangkan dalam Addendum Spec Teknis. - Panel Distribusi sesuai peruntukan alat yang ditawarkan, diinstall di Poltekba.
Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi 5 Oct 2015 10:18
8663169 XI I Untuk UPS 10 KVA , harus memenuhi seluruh spec teknis yang ada pada dokumen pengadaan
Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi
5 Oct 2015 10:25
8663169 BAB XI I Ralat : Lama untuk penyimpanan rekorder CCTV minimal 3 Bulan
Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi
5 Oct 2015 10:29
Penjelasan Tambahan
Penyedia harus mensubmit gambar design arsitektur jaringan I T berikut penjelasan dan fungsi cara kerjanya yang terintegrasi dengan system dan aplikasi : Video Surveillance, Control Access, Absensi, Layanan Pemanggilan dan Alarm
Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi 5 Oct 2015 10:39
Penjelasan Tambahan
Kontrak berdasarkan cara pembayaran: Kontrak Unit Price (Harga Satuan) dan akan dituangkan dalam Addendum Dokumen Pengadaan
Panitia Pengadaan Peningkatan I nfrastruktur TI K dan Peralatan Lab Telekomunikasi
5 Oct 2015 10:58
Peserta (penyedia barang/ jasa) Panitia/ Pokja ULP
Catatan :
Panitia/ Pokja ULP masih bisa memberikan penjelasan selama 3 jam setelah masa Aanwijzing berakhir Untuk menjawab pertanyaan cukup dengan menyebutkan I D Peserta
LPSE Universitas Mulawarman
http://lpse.unmul.ac.id/eproc/penjelasan/lelang/365169/PENJELASAN
LPSE Universitas Mulawarman
http://lpse.unmul.ac.id/eproc/penjelasan/lelang/365169/PENJELASAN
Lampiran Berita Acara Penjelasan (Adendum Dokumen Pengadaan)
Nomor
: 41/Pokja-ULP/Poltekba/X/2015
,
tanggal 05 Oktober 2015 Perubahan atas Dokumen Pengadaan Nomor : 39/Pokja-ULP/Poltekba/IX/2015
tanggal 30 September 2015
Kegiatan
:
Pengadaan Sarana dan Prasarana Pendukung Pembelajaran
Paket Pekerjaan :
Pengadaan Peningkatan Infrastruktur TIK dan Peralatan Lab. Telekomunikasi Jurusan Teknik Elektronika
Lokasi Pekerjaan : Kampus Poltekba Jln. Soekarno Hatta Km.8 Balikpapan
No.
URAIAN
KETERANGAN
AWAL
PER U BA HA N
BAB. I. UMUM
A.
Penjelasan dari point huruf A
Cukup Jelas
---
B.
Penjelasan dari point huruf B
Cukup Jelas
---
C.
Penjelasan dari point huruf C
Cukup Jelas
---
D.
Penjelasan dari point huruf D
Cukup Jelas
---
E.
Penjelasan dari point huruf E
Cukup Jelas
---
BAB. II. PENGUMUMAN
DENGAN
PASCAKUALIFIKASI
Cukup Jelas
---
BAB. III. INSTRUKSI KEPADA PESERTA
(IKP)
A.
UMUM
1.
Lingkup pekerjaan
Cukup Jelas
---
2.
Sumber Dana
Cukup Jelas
---
3.
Peserta Pelelangan
Cukup Jelas
---
4.
Larangan Korupsi, Kolusi dan
Nipotisme (KKN),
Persengkongkolan serta Penipuan
Cukup Jelas
---
5.
Larangan
Pertentangan
Kepentingan
Cukup Jelas
---
6.
Pendayagunaan Produksi Dalam
Negeri
Cukup Jelas
---
B.
DOKUMEN PENGADAAN
8.
Isi Dokumen Pengadaan
Cukup Jelas
---
9.
Bahasa Dokumen Pengadaan
Cukup Jelas
---
10.
Pemberian Penjelasan
Cukup Jelas
---
11.
Perubahan Dokumen Pengadaan
Cukup Jelas
Salinan Adendum Dokumen pengadaan bisa didapatkan oleh peserta
dengan mengunduhnya melalui website sebagaimana tercantum
dalam LDP
12.
Tambahan Waktu
Pemasukan Dokumen
Penawaran
Cukup Jelas
---
C.
PENYIAPAN
DOKUMEN
PENAWARAN
13.
Biaya Dalam Penyiapan Penawaran
Cukup Jelas
---
14.
Bahasa Penawaran
Cukup Jelas
---
15.
Dokumen Penawaran
Cukup Jelas
---
16.
Harga Penawaran
Cukup Jelas
---
17.
Mata Uang Penawaran dan Cara
Pembayaran
Cukup Jelas
---
18.
Masa Berlaku Penawaran dan
Jangka Waktu Pelaksanaan
Cukup Jelas
---
19.
Pengisian Data
Kualifikasi
Cukup Jelas
---
20.
Pakta Integritas
Cukup Jelas
---
D.
PEMASUKAN
DOKUMEN
PENAWARAN
21.
Penyampulan
dan
Penandaan
Sampul Penawaran
Cukup Jelas
---
22.
Pemasukan/Penyampaian
Dokumen Penawaran
Cukup Jelas
---
23.
Batas Akhir Waktu Pemasukan
24.
Dokumen Penawaran Terlambat
Cukup Jelas
---
E.
PEMBUKAAN DAN EVALUASI
PENAWARAN
25.
Pembukan Penawaran
Cukup Jelas
---
26.
Evaluasi Dokumen Penawaran
Cukup Jelas
---
27.
[Klarifikasi dan Negosiasi Teknis
dan Harga]
Cukup Jelas
---
28.
Evaluasi Kualifikasi
Cukup Jelas
---
29.
Pembuktian Kualifikasi
Cukup Jelas
---30.
Berita Acara Hasil Pelelangan
Cukup Jelas
---F.
PENETAPAN
PEMENANG
PELELANGAN
31.
Penetapan Pemenang
Cukup Jelas
---
32.
Pengumuman Pemenang
Cukup Jelas
---
33.
Sanggahan
Cukup Jelas
---
G.
PENUNJUKAN PEMENANG
34.
Penunjukan Penyedia/Jasa
Cukup Jelas
---
35.
BAHP, Berita Acara Lainnya dan
Kerahasian Proses
Cukup Jelas
---
H.
PELELANGAN
GAGAL
DAN
TINDAK LANJUT PELELANGAN
GAGAL
36.
Pelelangan Gagal dan Tindak
Lanjut Pelelangan Gagal
Cukup Jelas
---
I.
JAMINAN PELAKSANAAN
37.
Jaminan Pelaksanaan
Cukup Jelas
---
38.
Penandatanganan Kontrak
Cukup Jelas
---
BAB. IV. LEMBAR DATA PEMILIHAN
(LDP)
A.
Lingkup pekerjaan
Pokja :
Pokja Pengadaan Bangan ULP
Politeknik Negeri
Balikpapan
1.
Alamat Pokja ULP : Jln. Soekarno Hatta Km.8 Balikpapan
2.
Website :
www.poltekba.ac.id
3.
Website LPSE : www.lpseunmul.ac.id
4.
Nama paket pekerjaan:
Pengadaan Peningkatan
Infrastruktur
TIK
dan
Peralatan
Lab.
Telekomunikasi Jurusan Teknik Elektronika
5.
Uraian singkat pekerjaan :
(a) Pengadaan, pemasangan, dan integrasi
peralatan
laboratorium
pendidikan
dan
pengembangan infrastruktur teknologi informasi
sampai dengan berfungsi secara optimal
(b) Pelatihan operator/ instruktur untuk dapat
mengoperasikan dan memelihara sistem dan
peralatan secara optimal.
[
diisi
dengan
uraian
secara
singkat
dan
jelas
pekerjaan/kegiatan yang dilaksanakan]
6.
Jangka waktu penyelesaian pekerjaan:
60 (enam
puluh) hari kalender.
1.
Pokja :
Pokja Pengadaan ULP
Politeknik Negeri
Balikpapan
2.
Alamat Pokja ULP :
Jln. Soekarno Hatta Km.8 Balikpapan
3.
Website :
www.poltekba.ac.id
4.
Website LPSE : www.lpseunmul.ac.id
5.
Nama paket pekerjaan:
Pengadaan Peningkatan
Infrastruktur
TIK
dan
Peralatan
Lab.
Telekomunikasi Jurusan Teknik Elektronika
6.
Uraian singkat pekerjaan :
(a) Pengadaan, pemasangan, dan integrasi
peralatan
laboratorium
pendidikan
dan
pengembangan infrastruktur teknologi informasi
sampai dengan berfungsi secara optimal
(b) Pelatihan operator/ instruktur untuk dapat
mengoperasikan dan memelihara sistem dan
peralatan secara optimal.
7.
Jangka waktu penyelesaian pekerjaan:
60 (enam
puluh) hari kalender.
B.
Sumber Dana
Cukup Jelas
---
C.
Jenis Kontrak
1. Kontrak berdasarkan cara pembayaran:
Kontrak
LumpSum
2. Kontrak berdasarkan pembebanan Tahun Anggaran:
Kontrak Tahun Tunggal
3. Kontrak berdasarkan sumber pendanaan: Kontrak
Pengadaan Tunggal
4. Kontrak berdasarkan jenis pekerjaan: Kontrak
Pengadaan Pekerjaan Tunggal
1. Kontrak berdasarkan cara pembayaran:
Kontrak
Harga Satuan (Unit Price)
2. Kontrak berdasarkan pembebanan Tahun Anggaran:
Kontrak Tahun Tunggal
3. Kontrak berdasarkan sumber pendanaan: Kontrak
Pengadaan Tunggal
4. Kontrak berdasarkan jenis pekerjaan: Kontrak
Pengadaan Pekerjaan Tunggal
D.
Jadwal Tahapan Pemilihan
Cukup Jelas
---
---F.
Mata Uang Penawaran dan Cara
Pembayaran
Cukup Jelas
---G.
Masa Berlakunya Penawaran
Masa berlaku penawaran selama
30 (tiga puluh)
hari
kalender sejak batas akhir pemasukan Dokumen
Penawaran, yaitu dari tanggal
12 Oktober 2015
s.d 10
Nopember 2015
Masa berlaku penawaran selama
minimal 30 (Tiga
Puluh)
hari kalender sejak batas akhir pemasukan
Dokumen Penawaran, yaitu dari tanggal
12 Oktober
2015 Sampai Dengan 10 Nopember 2015
H.
Jadwal
Pemasukan
Dokumen
Penawaran
Cukup Jelas
---I.
Batas Akhir Waktu Pemasukan
Penawaran
Cukup Jelas
---J.
Pembukaan Penawaran
Cukup Jelas
---K.
Dokumen Penawaran
Cukup Jelas
---L.
(Ambang Batas Sistem Gugur)
Cukup Jelas
---
M.
Sistem Nilai
Cukup Jelas
---
N.
Umur Ekonomis
Cukup Jelas
---
O.
Sanggahan dan Pengaduan
Cukup Jelas
---
P.
Jaminan Pelaksanaan
Cukup Jelas
---
Q.
Jaminan Uang Muka
Cukup Jelas
---
R.
Sertifikat Garansi
Cukup Jelas
---
S.
Lainnya (apabila ada)
Cukup Jelas
---
BAB. V. LEMBAR DATA KUALIFIKASI
(LDK)
A.
Lingkup Kualifikasi
Cukup Jelas
---
B.
Persyaratan Kualifikasi
Cukup Jelas
---
BAB. VI. BENTUK DOKUMEN PENAWARAN
A.
BENTUK SURAT PENAWARAN PESERTA BADAN
USAHA / KEMITRAAN (KSO) (UNTUK 1 (SATU) FILE)
Cukup Jelas
---B.
BENTUK SURAT PENAWARAN PESERTA
PERORANGAN (UNTUK 1 (SATU) FILE)
Cukup Jelas
---
C.
BENTUK SURAT PENAWARAN
ADMINISTRASI DAN TEKNIS (UNTUK FILE I,
METODE 2 (DUA) FILE)
Cukup Jelas
---
D.
BENTUK SURAT PENAWARAN HARGA
(UNTUK FILE II, METODE 2 (DUA) FILE)
Cukup Jelas
---
E.
BENTUK SURAT PENAWARAN ADMINISTRASI
DAN TEKNIS PESERTA PERORANGAN (UNTUK
FILE I, METODE 2 (DUA) FILE)
Cukup Jelas
---
F.
BENTUK SURAT PENAWARAN HARGA
(UNTUK FILE II, METODE 2 (DUA) FILE)
Cukup Jelas
---
G.
BENTUK PERJANJIAN KEMITRAAN/KERJA
SAMA OPERASI (KSO)
Cukup Jelas
---
H.
BENTUK DOKUMEN PENAWARAN TEKNIS
Cukup Jelas
---
I.
[BENTUK FORMULIR REKAPITULASI
PERHITUNGAN TINGKAT KOMPONEN
DALAM NEGERI (TKDN), apabila memenuhi
syarat untuk diberikan preferensi harga]
Cukup Jelas
---
J.
BENTUK PAKTA INTEGRITAS
Cukup Jelas
---
K.
DATA ISIAN KUALIFIKASI
Cukup Jelas
---
BAB. VII. PETUNJUK PENGISIAN DATA KUALIFIKASI
Cukup Jelas
---
BAB. VIII. TATA CARA EVALUASI KUALIFIKASI
Cukup Jelas
---
BAB. IX. BENTUK DOKUMEN KONTRAK
Cukup Jelas
---
BAB. X. SYARAT-SYARAT UMUM KONTRAK (SSUK)
Cukup Jelas
---
Kontrak Lumpsum
Kontrak Harga Satuan (Unit Price)
BAB. XII. SPESIFIKASI TEKNIS DAN GAMBAR
Ada Perubahan
Terlampir
BAB. XIII. DAFTAR KUANTITAS DAN HARGA
Cukup Jelas
---BAB. XIV. BENTUK DOKUMEN LAIN
Cukup Jelas
---
A.
BENTUK SURAT PENUNJUKAN PENYEDIA/
JASA (SPPBJ)
Cukup Jelas
---
B.
BENTUK SURAT PESANAN
Cukup Jelas
---
C.
BENTUK JAMINAN PELAKSANAAN DARI
BANK
Cukup Jelas
Format Jaminan mengikuti format penerbit Jaminan.
D.
BENTUK JAMINAN PELAKSANAAN DARI
ASURANSI/PERUSAHAAN PENJAMINAN
Cukup Jelas
Format Jaminan mengikuti format penerbit Jaminan.
E.
BENTUK JAMINAN UANG MUKA DARI BANK
Cukup Jelas
Format Jaminan mengikuti format penerbit Jaminan.
F.
BENTUK JAMINAN UANG MUKA DARI
KEMENTERIAN RISET, TEKNOLOGI, DAN PENDIDIKAN TINGGI
POLITEKNIK NEGERI BALIKPAPAN
Jl. Soekarno Hatta Km. 8, Balikpapan 76126, Telp. (0542) 860895, 862305 Fax. 861107 Email: admin@poltekba.ac.id Web: www.poltekba.ac.id
SPESIFIKASI TEKNIS
Kegiatan Pengadaan Sarana dan Prasarana Pendukung Pembelajaran
Pekerjaan
Volume 1 (satu) Paket
NO NAMA BARANG GAMBAR Q'TY SATUAN
I. PENINGKATAN INFRASTRUKTUR TIK
A. Pembangunan Infrastruktur jaringan
1 Access Switch 48-Port POE 1Access Switch 48-Port POE is a fixed-configuration, stackable Gigabit Ethernet switches
that provide enterprise-class access for campus and branch applications. Some features:
7 unit
2- 48 Gigabit Ethernet ports with line-rate forwarding performance 3- Gigabit Small Form-Factor Pluggable (SFP) or 10G SFP+ uplinks 4- Power over Ethernet Plus (PoE+) support
2 Access Switch 24-Port POE 1Access Switch 24-Port POE is fixed-configuration access switches designed for
enterprise, midmarket, and branch office. Some features:
1 unit
2- 24 Ethernet 10/100/1000 PoE+ ports 3- 370W PoE capacity
4- 2 1 Gigabit Ethernet SFP uplink ports
3 Access Switch 8-Port POE 1Access Switch 8-Port POE is compact switch to extend wired switching infrastructure
with a single Ethernet cable from wiring closet. Some features:
1 unit
2- Power over Ethernet (PoE) pass-through 3- 8 FastEthernet
4- 2 x Dual Purpose Uplink
4 Distribution Switch 48-Port 1Distribution Switch 48-Port is an enterprise-class stackable Ethernet access and
aggregation layer switches that provide full convergence between wired and wireless on a single platform. Some features include:
6 unit
2- Support up to 40G of wireless capacity per switch 3- Support up to 50 access points and 2000 wireless clients 4- Dual redundant, modular power supplies and three modular fans
5- Software support for IPv4 and IPv6 routing, Multicast routing, modular quality of service (QoS), Flexible NetFlow (FnF) Version 9, and enhanced security features Pengadaan Peningkatan Infrastruktur TIK dan Peralatan Lab. Telekomunikasi Jurusan Teknik Elektronika Politeknik Negeri Balikpapan Tahun Anggaran 2015
5 Core Switch 1The Core Switch platform consists of fixed-port switches designed for top-of-rack (ToR) and middle-of-row (MoR) deployment in data centers that support enterprise applications, service provider hosting, and cloud computing environments. The switches are Layer 2 and 3 nonblocking 10 and 40 Gigabit Ethernet and Fibre Channel over Ethernet (FCoE)-capable switches with up to 2.56 terabits per second (Tbps) of internal bandwidth.
1 unit
2- 48 ports of 1- and 10-Gbps fiber Enhanced Small Form-Factor Pluggable (SFP+)
3- 12 ports of 40-Gbps fiber Quad SFP (QSFP)
6 WAN & Internet Edge Switch 1Distribution Switch 48-Port is an enterprise-class stackable Ethernet access and
aggregation layer switches that provide full convergence between wired and wireless on a single platform. Some features include:
2 unit
2- Support up to 50 access points and 2000 wireless clients 3- Dual redundant, modular power supplies and three modular fans
4- Software support for IPv4 and IPv6 routing, Multicast routing, modular quality of service (QoS), Flexible NetFlow (FnF) Version 9, and enhanced security features
7 Internet Router 1 Integrated Service Router with embedded hardware encryption acceleration, voice-
and video-capable digital signal processor (DSP) slots, optional firewall, intrusion prevention, call processing, voicemail, and application services.
1 unit
2- 3 onboard GE 3- 4 EHWIC slots 4- 2 DSP slots 5- 1 ISM slot 6- 256MB CF default 7- 512MB DRAM default 8- IP Base
8 Short Range SFP Module 110GBASE SFP module gives 10 Gigabit Ethernet connectivity option for data center,
enterprise and service provider applications. Features including:
12 unit
2- Hot-swappable input/output device 3- Digital optical monitoring capability
4- Supports a link length of 26m on standard Fiber Distributed Data Interface (FDDI)-grade multimode fiber (MMF)
5- Using 2000MHz*km MMF (OM3), up to 300m link lengths are possible. 6- Using 4700MHz*km MMF (OM4), up to 400m link lengths are possible.
9 1000BASE-T 1SFP provides full-duplex Gigabit Ethernet connectivity to high-end workstations and
between wiring closets over existing copper network infrastructure.
10 Long Range SFP Module 110GBASE SFP module gives 10 Gigabit Ethernet connectivity option for data center, enterprise and service provider applications. Features including:
8 unit
2- Hot-swappable input/output device 3- digital optical monitoring capability
4- Supports a link length of 10 kilometers on standard single-mode fiber (SMF, G.652).
11 DMZ Firewall + IPS 1DMZ Firewall is stateful inspection firewall with a comprehensive suite of highly
integrated next-generation firewall services for networks of all sizes-small and midsize businesses with one or a few locations, large enterprises, service providers, and mission-critical data centers. Some features include:
1 unit
2- Firewall Protection: Stateful Packet Filtering, Remote Access Authentication, Deep Inspection Firewall and Intrusion Prevention
3- Granular visibility and control
4- Robust web security onsite or in the cloud
5- Intrusion Prevention System (IPS) to protect against known threats - High availability for High-resiliency Applications
12 Security Management for IPS 1Security Management provides total visibility into everything on your network: physical
and virtual hosts, operating systems, applications, services, protocols, users, geolocation information, content, and network behavior as well as network attacks and malware.
1 unit
2- Maximum number of devices managed: 10 3- Maximum number of IPS events: 20 million 4- Event storage: 100 GB
5- Maximum network map (hosts/users): 2,000/2,000 6- Maximum flow rate
7(flows per second): 2,000 fps
8- High availability: Lights-out management (LOM)
13 DMZ Switch 1DMZ Switch 48-Ports a fixed-configuration, stackable Gigabit Ethernet switches that
provide enterprise-class access for campus and branch applications. Some features:
1 unit
2- 48 Gigabit Ethernet ports with line-rate forwarding performance 3- Gigabit Small Form-Factor Pluggable (SFP) or 10G SFP+ uplinks
14 Access Point 1Wi-Fi Access Point delivers industry-leading 802.11ac performance for plugging
capacity and coverage gaps in dense indoor environments. Features including:
30 unit
2- Dual-band 2.4GHz and 5GHz access points with 802.11ac 3- 802.11ac with 3x4 MIMO technology
4- Sleek design with internal antennas
5- Classify over 20 different types of interference, including non-Wi-Fi interference
6- Automatic remedial action and less manual intervention 7- Cross-AP Noise Reduction
15 Wireless Controller 1Wireless Controller is a highly scalable and flexible platform that enables systemwide services for mission-critical wireless networking in medium-sized to large enterprises and campus environments.
1 unit
2Some features including:
3- Support for up to 500 access points and 7000 clients 4- 802.11ac and 802.11n optimized
5- Larger mobility domain for more simulataneous client associations
16 Data Center Switch 1Distribution Switch 48-Port is an enterprise-class stackable Ethernet access and
aggregation layer switches that provide full convergence between wired and wireless on a single platform. Some features include:
2 unit
2- Support up to 40G of wireless capacity per switch 3- Support up to 50 access points and 2000 wireless clients 4- Dual redundant, modular power supplies and three modular fans
5- Software support for IPv4 and IPv6 routing, Multicast routing, modular quality of service (QoS), Flexible NetFlow (FnF) Version 9, and enhanced security features
3000 meter
17 Fibre Optic Cable 1Fiber Optic Cable, Corning, Single Mode 24-core outdoor/duct
(Termasuk instalasi) 2Direct buried cable
3The single mode full spectrum optical fibers (ITU-T G.652.D):
4Have additional 3dB SBS threshold for longer distance reach of analog transmission
5Are low water peak type and comply to ITU-T recommendation of G.652 table D
6Have operating wavelengths between 1260nm up to 1625nm
7Have macrobend loss at 1310nm and 1550nm < 0.03 dB with 50mm mandrel diameter and 100 turns
8Have the cabled fiber attenuation at 1310 nm < 0.35 dB/km and 1550 nm < 0.22 dB/km.
9Have the maximum PMD link value of 0.06 ps/ sqrt.km and 0.20 ps/ sqrt.km of individual value
10Are easily splice and the average field splice loss shall not more than 0.08 dB, taken from a bi-direction measurement.
11Are colored with durable, transparent coating to accommodate LID splice method.
12Ha e atte uatio diffe e e at – a ele gth a ge > . dB/k .
13Ha e o e- lad o e t i it e o of ot o e tha . μ . 14Have point of discontinuity not more than 0.05 dB.
15Fiber colours is Blue, Orange, Green, Brown, Grey, White, Red, Black, Yellow, Violet, Pink and Aqua/ Torquiose
18 FOBOT (OTB) 1Wallmounted closure 10 unit
(Termasuk instalasi) 2Support up to 24 Ports, Maximum 36 Ports for LC only
6Suitable for Applications: Data Center, Intra Building and Campus backbone distribution network
7Designed for intra-building, Data Center or campus backbone distribution
19 FO Patch Cord 1FO patch cord FC-LC/LC-LC/FC-FC SM duplex 20 unit
2Outer Sheath LSOH 3Simplex or Duplex Cable 4Differentiated by color coded
5PC or *APC Polish are available (*FC & SC SM only)
6Complies with Telcordia GR-326-CORE, UL, and RoHS standard 7Coating fiber core coloring technology
20 19" 42U Closed Rack 119" Server/Network Cabinet Rack 3 unit
(Termasuk instalasi) 2Size 42U
3Tampered glass front door 4Width 600mm
5Height 2065mm 6Depth 1150mm 7Roof Fan Panel 2 Fan 8Cage Nut
9M6 screw
10Vertical Power Distribution Panel 12 outlets
21 UPS 10kVa 1Uninterruptible Power Supply 10kVa 4 unit
(Termasuk instalasi dan pelatihan) 2High Frequency and Online/Double Conversion Technology
3Digital microprocessor control 4Operating Voltage: Range 170 - 280VAC 5Output Voltage: 220 / 230 / 240 VAC ± 1% 6Harmonic Distortion: < 2% (linear load) 7Support Cold start
8Support Parallel Operation up to 3 units 9Advanced battery management
10Automatic battery charge in UPS off mode backup time
11Lightning and surge protection tidak harus
12Short circuit and overload protection 13Automatic adjustable fan speed 14Operating Temperature: 0 - 40°C 15Humidity: 0 to 95% (non-condensing) 16EMI/RFI noise filter
17Communication Interface: RS232 18Including battery back up time 1 hour
22 Cable Tray dan aksesories pendukung 1Tray tipe C Hotdepped Galvanis Ukuran 150(L)x100(T)x3000(P) 1 paket
(Termasuk instalasi) 2Penyambung kabel tray tipe U + Baut dan Mur
3Penutup Kabel Tray ukuran 150x3000mm 4Penjepit Penutup kabel tray
5Equal Tee ukuran 150mm 6Elbow ukuran 150mm
8Tangkai gantungan kabel tray ukuran 150mm 9Dynabolt ukuran M8
10Gantungan dinding kabel tray ukuran 150mm
23 Patch Panel 24-Port Cat6 1CAT6+ KeyConnect Patch Panel, 24-port, 1U 3 unit
(Termasuk instalasi) 2Suitable Applications: IBDN System 4800, 3600, 2400, TIA Category 6, ISO Class E,
1000BASE-T
3Related Parts: CAT6+ Modular Cords
4Max. Capacity: 24 connectors ( Patch Panel is already loaded ) 5Front Connection: Flush
6Termination Area: Rear 7Material Steel
24 HDPE 20cm PE100 1Density 0.95 testing method ISO 1183 20 unit
(Termasuk instalasi) 2Melt index Mfi 190° 0.35 g/, testing method ISO 1133
3Tensile Strength at yield point 28Mpa, testing method ISO 527 4Dielectric Strength 180 KV/cm, testing method IEC 243 5Thermal conductivity at 20°C 0.4 W/m°C
6Surface resistance >10-16 OHMS
25 Network Cable Cat6 UTP 1Network Cable Cat6 UTP 7 roll
(Termasuk instalasi) 2Conductor Material Bare Annealed Copper
3Insulation Material Thermoplastic Polyolefin 4Outer Jacket Material PVC
5AWG 24
6Suitable for Applications: Horizontal cabling, Gigabit Ethernet, 100BaseTX 7Stranding Solid
26 Patch Panel 48-Port for Cat6 1Cat6 Patch Panel, 48-port 7 unit
(Termasuk instalasi) 2Maximum Capacity: 48 connectors
3Suitable for Applications: TIA Category 6, ISO Class E, 1000BASE-T 4Flush Access Front Connection
5Rear Termination Area 6Material 16 Gauge Steel 7Plug / Jack Compatibility RJ45 8Termination Universal T568A/B
27 Network Point dan aksesories 1Double Port Faceplate 1 paket
(Termasuk instalasi) 2Material Flame Retardant Plastic, UL94V0
3Modular Connectors CAT6
4Suitable for applications: TIA Category 6+, 1000 BASE-T 5Wiring Scheme: T568A/B
6Jack Compatibility: RJ45, RJ11
28 15U Network Cabinet - Wallmount 119" Network Cabinet with depth 490mm, include Horizontal Power Distribution 6
outlet with switch
7 unit
(Termasuk instalasi) 2Minimum 15U
5Dynabolt, Cagenut
29 1U 19" Cable Guide 119" 1U Horizontal Cable Manager 10 unit
(Termasuk instalasi) 216 Gauge CRS Construction
3Six Cable Management Rings
B. Layanan Telefoni berbasis jaringan
30 Voice Gateway Router 1Integrated Service Router delivers highly secure data, voice, video and application
services for small office. Features include:
1 unit
2- 3 Integrated 10/100/1000 Ethernet ports 3- 4 Enhanced High-Speed WAN Interface Card slot 4- 3 onboard digital signal processor slots
5- Embedded hardware-accelerated VPN encryption
6- High-density packet voice DSP module, optimized for voice and video support 7- Standards-certified VoiceXML browser services
31 Call Manager / PBX Server Call Manager PBX Server offers full-featured, enterprise-class communications 1 unit
and collaboration services.
32 Call Manager Software and License 1Call Manager software is the media-processing engine, and serves to extend telephony
features and capabilities to packet telephony network devices, including:
1 unit
2- IP Phones
3- Media Processing Devices 4- Voice-over-IP (VoIP) gateways 5- Multimedia Applications
33 IP Phone 1IP phone with speakerphone and handset designed for wideband audio. 40 unit
C. Sistem dan Aplikasi Video Surveilance
34 1Manage live video from IP cameras and video encoders to display on any client or
video wall
1 unit
2Manage video streaming from IP cameras and video encoders to NVR / IP SAN
(Termasuk instalasi dan pelatihan) 3Record searching by time, camera number, event, devices or complex conditions
4Archive evidence at local storage / central storage / remote site 5Virtual matrix operation with CCTV IP keyboards or client workstations
6Instant playback historical video record for past 30 seconds from live view window directly Intelligent Video Analytics
7Supports up to 36 intelligent analysis features
8Build the ost o pli ated p epla s a o di g to usto e s’ diffe e t eeds Central Management Server untuk
9Drive workflow and enable operator to confirm critical tasks by automatic checklist display
10Automatically execute corresponding response at different situations e.g. email notification Event Management
11Events classified by types and security levels for easy searching 12Events can be managed according to status to ensure proper handling
13Event notifications at different security levels can be easily identified by different colors
14Allocate event accurately on the map with video verification
15Support GIS, BMP, JPEG, Common Image and Auto CAD format map import 16Support multi-layer E-map navigation and nesting application
17Alarm / event trigger up to 4 live videos for verification 18E-map support with GIS / AutoCAD / Common Image. 19Support BACNET protocol
20Rules Engine Driving for Emergency Processing
21Drive workflow and enable operator to confirm critical tasks by automatic checklist display
35 Network Video Recorder 1Support up to 340Mbps data throughput 1 unit
(Termasuk instalasi) 2Support 128 channels real-time recording video + 20 channels history video playback +
20 channels streaming video forwarding (D1 resolution / full real time / 2 Mbps)
3Built-in standalone server with 16 hard disk bays 4Support RAID 0, 1, 5, 6, 10, 50, 60
5Support Video Compression H.264, MPEG-4, MPEG2 and MJPEG formats 6Support Video Resolution 1080P / 720P / Megapixel / D1 / 4CIF / VGA / CIF 7Complete fail-over solution provided by N+1 redundancy system design 8Power supply and fan module redundancy (2 x PFC)
9Network 2 x 1Gbps Ethernet RJ-45 Ports
10One standard storage unit supports up to 48TB, expansion total storage up to 114TB
11Hot swappable hard disk for easy maintenance and high availability 12Continuous, scheduled, motion and alarm triggered recording support 13Quick video record search by date, time, alarm event, channel number 14Minimum Recording Time : 3 months
36 Intelligent Digital Decoder 1Decode High Definition (1080P / 720P), Megapixel and Standard resolution video
streams
1 unit
(Termasuk instalasi) 2Drive 4 high definition monitors from one unit simultaneously
3Simultaneously decode up to 4 streams at D1 resolution with real time on each port
4Video Output 4 x HDMI ports
5Video Split: Full Screen, 2x2, 3x3, 4x4, 6, 8, 9, 13, 16 split screen 6Display Resolution 1080P / 720P / Megapixel / D1 / 4CIF / VGA / CIF 7Support Video Compression H.264, MPEG4, MPEG2 and MJPEG 8Network 1 Gigabit Ethernet RJ-45 Port
37 Video Wall Display 1ukuran layar minimal : 32 inchi 1 Set
(Termasuk instalasi) 2Bezel width max : 15mm
3Full HD Resolution, 1920 x 1080
4Minimal Brightness : 400 nits surveylance
5Dirancang untuk digunakan selama 24 jam x 7 hari dalam seminggu. 6Viewing Angle (Horizontal and Vertical) : 178
7Maximum pixel frequency 148.5 MHz 8Processor minimum : 1 Ghz, Quadcore 9Memory minimal : 1.5 GB dual 48 bit, DDR3 102D & 3D Graphics Engine, 1920 x 1080
11Display dapat dikontrol dengan menggunakan Tablet atau smarthphone (IOS dan Android) via wifi
38 Keyboard Controller untuk Surveillance 1Touch wheel for DVR/NVR control 1 unit
(Termasuk instalasi) 2Support multiple connectivity options (RS232/422/485 and TCP/IP)
3Web browser for easy upgrading and configuring
4Standard Keys: 0-9, Clr, Ent, Cam, Mon, Mux, Device, Alarm, Seq, Login
5DVR/NVR keys: Rec/Stop, Play Fwd, Play Rev, Review, Search, Touch Pad and Ring for FF, REW, Step FWD, REV
6Camera Function Keys: View, Tour, PTZ Call, Alt, Undo, Set, Iris, (2) Focus, MonA, MonB
7Joystick 3-axis proportional control 8Network RJ45 with POE
39 Perangkat PC Workstation Surveillance 1Processor Intel® Xeon® E3-1200 series or 2nd generation Intel® Core 2 unit
(Termasuk instalasi dan pelatihan) 2Operating System Genuine Windows® 7 Professional (32-Bit or 64-Bit)
3Memory 4GB (2x2GB) Non-ECC DDR3 1333MHz SDRAM
4Security Software: Trusted Platform Module 1.2 (TPM 1.2); Chassis intrusion switch option, Setup/BIOS Password; I/O Interface Security; Intel Anti-Theft Protection option (iATP)
Security Hardware: Kensington® Lock slot; padlock ring 5Hard Drive 250GB 7200RPM 3.5" 6.0GB/s SATA HDD 6Chipset Intel® C206
7Integrated High-Definition Audio with 24-bit analog to digital and 24-bit digital to analog stereo conversion.
8Supports 2 monitors with a total of 16 channels at D1 @ 25fps
40 IP Camera Indoor 11/3" ultra-low illumination CMOS image sensor 27 unit
(Termasuk Instalasi) 21280 (H) x 960 (V) High Definition
3Lens focus :4 mm
4Minimum Illumination: Color: 0.01Lux @ (F1.2,AGC ON) B/W: 0.0Lux (IR On) 5H.264: 100Kbps~6Mbps
6Built-in IR LED 20~30 m 7True Day/Night (with IR-cut)
8Trigger alarm : motion detection (up to 300 zone), Network loss detection, Video loss
9Mobile View APP
(Termasuk Instalasi) 21080P High Resolution 3Lens:  2.8 - 12mm 3M DC-IRIS 4Minimum Illumination: 0 Lux (IR LED ON)
5Main Stream Resolution:  1080P (1920 x 1080), 720P (1280 x 720), Q1080P (960 x 544)
6Second Stream Resolution:  720P (1280 x 720), Q1080P (960 x 544), D1 (720 x 576), VGA (640 x 480), Q720P (640 x 360),
CIF (352 x 288), QVGA (320 x 240), QCIF (176 x 144) 7H.264, and MJPEG simultaneously (Dual-encoders) 8H.264 high profile
9True Day/Night (with IR-cut filter) 10WDR, 3DNR, DC IRIS, and Anti-flicker 11IR Beam Distance up to 40m
12Built in Power over Ethernet (PoE); 100Base-T Ethernet
13E e t t igge i g – a e a ta pe i g, Motio dete tio , Net o k loss, Ala I put, Video loss
14E e t t igge a tio – SNAP, Re o d ideo i SD a d, se d to FTP, se d to E ail, External output activation, voice alert, notify to CMS
15Supported Protocols: IPv4, IPv6, TCP, UDP, HTTP, HTTPS, SMTP, FTP, NTP, DNS, DDNS, DHCP, ARP, Bonjour, UPnP, RTSP, RTP, RTCP, IGMP, PPPoE, ICMP, SNMP
16Edge sto age – up to G 17Audio Encoder: RTSP: G.711 64kbps 18Audio Streaming: One-way or two-way 19Audio Input: External audio in 20Audio Output: Speaker Out 21IP66 weather-proof 22ONVIF Profile S compliant
42 Smart Tv 65" 1Ukuran Layar:65 Inch 1 unit
2Resolusi Layar:3840 x 2160 (Ultra HD)
3Input / Output:HDMI, USB, Component In (Y/Pb/Pr), Composite In (AV), Ethernet (LAN), Audio Out (Mini Jack / LR), Digital Audio Out (Optical), RF In
4Audio, Dolby Digital, Multiroom Link, HD Audio, Virtual Surround 5Koneksi, Wireless LAN Built-in
6Voltase, 100 - 240V AC, 50/60Hz 7Apps, Multi-Screen II, Web Browser App
8Convergence, TV to Mobile - Mirroring, Mobile to TV - Mirroring, WiFi Direct 9Interaction, Face Recognition, Motion control
10Connectivity, MHL, Dongle Ready (3G/LTE), HDMI Quick Switch, Anynet+ (HDMI-CEC)
11Feature, Processor Quad-Core, Digital Clean View, Analog Clean View, Auto Channel Search, Auto Power Off, BD Wise Plus, Caption (Subtitle), USB HID Support ,Eco Sensor, Triple Protector
43 Smart TV 32" 1Tipe Layar:LED TV 1 unit
2Ukuran Layar:32 Inch 3Audio:Dolby Digital
6Smart TV Type:Apps 7Social TV 2.0 or similar 8Web Browser App
9Koneksi Nirkabel: Wifi Direct, Wireless LAN Built In 10Convergence: Mobile to TV - Mirroring, DLNA 11:Wireless TV On - WOL
12:WiFi Direct
13Connectivity:HDMI, USB, Component in, Ethernet, MHL, HDMI, Digital audio out
14Feature:Processor Quad Core, Digital Clean View, Auro channel search, subtittle, auto power off
D.
44 1Supports Windows Server 2008/2012/2012 R2, SQL Server 2008/2012, Windows
7/8/8.1 (32-bt and 64-bit)
1 paket
2Installer program streamlines Windows and SQL account setup for Access control management logins in non-domain environments
3Single user interface for multiple security and business functions
(Termasuk instalasi dan pelatihan) 4Integrates video, access, and intrusion. can be integrated with other building systems
such as secondary fire, lighting and heating, ventilation, and air conditioning.
5Elevator control 6Tracks assigned assets 7Custom triggers and procedures
8Associates events to actions including sending emails, running a stored procedure, or triggering a panel I/O point.
9Basic Reports
10Virtualization support for VMWare and Microsoft Hyper-V 11Compliance Reports that offers
– Data a d statisti al epo ti g
– Auto ge e ated epo ts upo s hedules
12Easy system setup and maintenance with user definable hardware templates 13Database partitioning and definable operator permissions
14IP, serial and modem communications 15CASI Micro/5 Replacement Program
16Professional, Corporate and Enterprise editions: – Sta da d Badgi g a d Ad a ed Badgi g lie t – -D PDF a ode add-o li e se fo adgi g – Optio fo T a spo tatio Se u it Clea i ghouse TSC – We ased lie ts
– E e t P o edu es t igge s o o se uti e dupli ate e e ts – Muste i g, a ti-pass a k a d gua d tou
– Mi i u a d a i u o upa e fo e e t
– Detailed histo i e o ds fo t a ki g o figu atio ha ges, se u it ope atio s a d device events to comply with audit requirements for regulatory compliance
– I te o s li ked to eade s a d lo atio s o aps p o ide ui k a ess to spe ifi units
– Suppo ts R a d late AutoCAD files DWF o XPS ith add-o li e se Sistem dan Aplikasi Kontrol Akses dan Absensi
– Optio s fo i teg ati g io et i s, thi dpa t ha d a e, ada - ideo solutio s a d IT o e ge e – High a aila ilit a d edu da t se e solutio s Co po ate Editio
– Suppo t fo Wi eless Lo ksets f o Allegio , Assa A lo , a d Salto
45 Intelligent Controller 1Up to 12 intervals per time zone where each interval is a start time, stop time and day
map. The day map indicates the day of the week or holiday
3 unit
(Termasuk instalasi) 2255 possible holidays are defined by a starting date and duration
3Automatic calculation of leap year and Daylight Saving Time 419-digit (64-bit) user ID
5Support for FIPS long card numbers 6Activation and deactivation dates by card
7Up to 12 access levels per card or individual time zones per readers 8Up to 8-digit Personal Identification
9Operating modes include locked, unlocked, facility code, card only, card and PIN, card or PIN, and PIN only
10Strike modes include fail-safe and fail-secure 11Up to eight card formats per reader
12Entire card bit-stream reported with invalid facility code or invalid card format 13A ti-pass a k suppo t – f ee pass a d e e pt flags, last a ea a essed, last eade
accessed and time/date of last access
14Configurable as standard, entry delay latching, entry delay non-latching and exit delay
15Configurable as standard (energize to activate) or fail-safe (de-energize to activate)
16Pulse control: single pulse (up to 24 hours) or repeating pulses (on/off in 0.1 second increments, up to 255 times)
17Support up to 32 I/O or reader modules may be connected to the RS485 ports. 18Standard CE Certified, UL294/UL1076 and CUL Listed
19AES FIPS 197 Encryption
20Web server for hardware configuration
21Primary communication support: RS232, RS485, Dial up modem, Ethernet (TCP/IP)
22Operational modes: Credential only, PIN only, Credential or PIN, Credential and PIN, Facility code only
46 Reader Module 12 reader ports - 12 VDC at 50 mA, clock/data or data0/data1 26 unit
(Termasuk instalasi) 22 dedicated alarm inputs for tamper detection and power loss
32 general purpose output relay, form-C, 5 A 28 VDC 4Standard UL294/UL1076 and CUL Listed
5Up to 8 supervised, general purpose alarm inputs with programmable circuit type
6Up to 6 relay outputs 7RS-485 connection
48 High Density Panel 1High Density Panel for Access Control 4 unit
(Termasuk instalasi) 2Tamper Switch
3Including Backup Battery 12V 7Ah
49 Power Supply untuk Akses Panel 1Auto switching Power Supply for Access Control Panel 4 unit
(Termasuk instalasi) 2Operating Power: 110/220 VAC
3Output Power: 12 VDC 4A
50 PC Workstation dengan 23" Monitor 1Intel® Xeon® E3-1200 v3 processors 1 unit
(Termasuk instalasi) 2Operating System Genuine Windows® 7 Professional 64 bit (Includes Windows 8 Pro
license and media)
3Memory up to 32GB 1600MHz ECC or up to 16GB 1600MHz non-ECC DDR3 memory
4Hard Drive Minumum 500GB SATA 5Optical Drive DVD+/-RW Drive 6Chipset Intel® C226
7Network Controller Integrated Intel 82579 Gigabit Ethernet controller 8Sound Card Integrated Realtek ALC269Q High Definition Audio 9LED Monitor 23"
10Access Control Client software
51 Akses Reader 113.56MHz, Contactless Smart Card Reader 50 unit
(Termasuk instalasi) 2ISO 14443A (MIFARE®) Compatible
3Read Range up to 2.5in.(6.4cm) 4Wiegand Output Interface 5with Mounting
52 Kusen dengan dua daun pintu 1Pintu dan kusen pintu terbuat dari bahan kayu 30 unit
(Termasuk instalasi) 2Ukuran Pintu : 72-82 cm X 2 dengan tinggi 200-235 cm
3Ukuran Kusen pintu : disesuaikan dengan pintu
53 1Electro-Magnetic Lock 30 unit
2Surface mounted
(Termasuk instalasi) 3Holding Force 600lbs
4Electro-Magnetic Lock 5Dual Voltage 12V / 24V 6Built-in Voltage Spike Supressor 7Standard: CE Approved, UL Listed
54 Kartu Akses 1Contactless Smart Card, size ± 85 × 54 × 0.8mm 1000 unit
2Memory EEPROM, for read/write 3Card working Frequency 13.56MHz 4Operating Distance up to 10cm 5Reading Time maximum : 170 ms 6Minimal Write endurance 100000 cycles 7Data Retention minimum 10 Years
55 1Single-sided or dual-sided printing module 1 unit
EM Door Lock lengkap dengan accessories
2Edge-to-edge printing
(Termasuk instalasi dan pelatihan) 3Color dye sublimation, monochrome thermal transfer
4300 dpi print head (11.8 dots/mm) 516MB memory (RAM)
6Feeder capacity: 100 cards
7Support card thickness: 0.25 to 1.25 mm
8Card types: PVC cards, Composite PVC cards, PET cards, ABS cards, Special varnished cards
9Card format: ISO CR80 - ISO 7810
56 USB Card Reader 1Dual frequency proximity and contactless card reader 1 unit
2Operating System Compatibility: Windows 2000®, XP®, Vista®, 7®, Macintosh® and Linux
3T pi al a i u ead a ge: . – . depe de t upo p o i it a d t pe a d environmental conditions
4Power Supply option: USB self-powered, PoE 5Transmit Frequency: 125 kHz & 13.56 MHz 6Operating Temperature: Range -30° to 65°C
7Operating Humidity: Range 5% to 95% relative humidity (non-condensing) 8Interface: USB, Ethernet
9Certifications: FCC, United States; CE Mark, RoHS, UL
57 Kabel RS485 (Kabel komunikasi data) 1Cable RS485 24 AWG stranded (7x32) TC conductors 13 roll
(Termasuk instalasi) 2Conductors 4 Pairs
3Insulation Material Polyethylene 4Outer Jacket Material PVC 51 roll = 1000ft
58 Cable Tray dan aksesories pendukung 1Staight Tray Ukuran 150(L)x100(T)x3000(P) ,, 1 lot
(Termasuk instalasi) 2Penyambung kabel tray tipe U + Baut dan Mur
3Penutup Kabel Tray ukuran 150x3000mm 4Penjepit Penutup kabel tray
5Equal Tee size 150mm 6Elbow size 150mm
7Gantungan Kabel Tray satu set ukuran 150mm 8Tangkai gantungan kabel tray ukuran 150mm 9Dynabolt ukuran M8
10Gantungan dinding kabel tray ukuran 150mm
E.
59 Network Resource Interface 1Universal Interface equipment for external control access and audio extension. 1 unit
(Termasuk instalasi) 2Digitalization input : 4 AUX balanced audio input source channel
3Audio Storage built-in minimum 512MB Flash memory, and 4G SD card 4Network 4 Ethernet interfaces for multiple communication
5Trigger input 32 dry contact with supervision. Input faults can be monitored. 6Communication terminals 2 x RS-485 for integration with Fire System Panel 7Main Power Supply -100 - 240 V, 50/60 Hz
8Backup Power Supply VDC 21.5 - 28.5 10Rated power 15 W
accessories
11Auxiliary input: Input channels 4 Input signal nnbhc
Frequency response 60 Hz - 16 kHz S/N > 85 dB
12Balanced Input: Input channels 4
Input signal 14 mV (-37 dBV) / 1 V(odBV) I put i peda e kΩ
Phantom power supply DC 24 V Frequency response 60 Hz -16 kHz S/N > 65 dB
13Control Terminal: Trigger inputs 32 inputs (can be monitored)
Trigger outputs (reserved) 8 outputs (NO, NC and COM)
Trigger outputs (reserved)
Max working voltage AC 250 V / DC 30 V Max working current 2.5 A
Others
Network interface 2.5 A Number of ports 4
Audio Storage : 4 GB SD card 500 MB Flash
1 unit
60 Digital Multi Audio Player 1Multi Audio Player integrated with DVD player
(Termasuk instalasi) 2Interface USB and SD.
3Support MP3 file, FM/AM tuner
4Play music and applications at 2 zones at the same time 5Two line outputs with independent volume control 6Support FM antenna input
7Stereo RCA FM/AM tuner output, 8Mixed sound RCA output 9Support CD, DVD videos and JPEG. 10Power Voltage: 230V, 50/60Hz 11Support USB 2.0 high speed, SD Card 12RS-458 remote control interface
61 Network Paging Console 1Paging console to performs paging, monitoring, and communication 2 unit
(Termasuk instalasi dan pelatihan) 2Network RJ45 standard port
3Interface Audio Output/Input 4Power Supply Voltage: 12/24 VDC 5Rated Power: 5W
6MIC Frequency Response: 80Hz - 16KHz 7SNR >85dB
8THD <0.05%
11LCD touch screen
12Sampling Rate: 44.1 KHz, 16 Bit 13Operating Temperature -10°C - +55°C 14Relative Humidity: <95% (non-condensing) 15Provides Indicator: Fault, Run, Emergency
62 1PAVA System Software Management includes server-side system resource platform 1 unit
2PAVA Client-side Management System for management of devices through ethernet network
(Termasuk instalasi dan pelatihan) 3Make announcement
4Play audio 5Manage logs
6Monitor system status of devices
7Flexible management of operation permissions 8Supports displaying the network as a visual map
9Fault detection Displays the Device ID, Type, and IP address 10Monitors the status of all devices in the system
11Supports multiple broadcast modes of operation 12Records event logs and fault logs
13System backup
63 Digital Integrated System Manager 1Main Power Supply: 100 - 240 V, 50/60 Hz 3 unit
(Termasuk instalasi dan pelatihan) 2Backup Power Supply: 21.5 - 28.5 VDC
3Single click emergency mode switchover 4DC power output DC24V/1A
5Max. input power 120 W 6Rated power 50 W 7Auxiliary input 1V(0dBV) 8I put i peda e kΩ
9Frequency response 60 Hz - 16 kHz 10Audio Input SNR > 85 dB 11Audio Output
12Audio output channels 4 13Output signal 1.2V(1.6dBV) 14Record output 1V(0dBV) 15Channels 4
16Input signal
1714mV(-37dBV) or 330mV (-9.6dBV) 18I put i peda e kΩ
19Phantom power DC 24V, 20configured by switch
21Frequency response 60 Hz - 16 kHz 22SNR > 65 dB
23Output channels 8, with circuit fault detection function Max. output load 500 W (If the line supervision is used, the load shall be less than250W.)
24Trigger input ports 8
25Trigger output ports 8 (NO, NC and COM) 26Standard CE Complied, EN 54 (Part 16) Certified PAVA System Management Software
64 High Efficient Amplifier 1Class-D Amplifier 3 unit
(Termasuk instalasi) 24 Channels
3Audio Inputs: balanced or unbalanced audio input 4Audio Outputs: 100V or 70V
5RJ-45 network port 6Rated Power: 4 ×125 W
7Main Power Supply Voltage: 100 - 240 V, 50/60 Hz 8DC Backup Power Voltage: Range 21.5 - 28.5 VDC 9Power Consumption: < 700 W
10Frequency Response: 70 Hz -18 kHz +1 dB - 3 dB 11Input Sensitivity: 1.414 VRMS
12I peda e: kΩ 13SNR > 100 dB
14Non-linear distortion <0.05% (at 1/3 Rated Power, 1 kHz) 15Material Fire-proof ABS
16Fault Protection
17Standard CE Complied, CB Certified
65 Ceiling Speaker 1Modular Ceiling Loudspeaker 70 unit
(Termasuk instalasi) 2Mounting: Direct ceiling
3Rated Power 6 W, Max Power 9 W 4Power taps (at 100V): 6 W/3 W/1.5 W 5Power taps (at 70V): 3 W/1.5 W/0.75 W 6SPL at 6W/1W (120 Hz-18 KHz, 1 m): 99 dB/91dB 7Frequency Range (at -10 dB): 80 Hz - 20 KHz 8Dispersion Angle (at 1 Khz/-6 dB): 184°/90° 9Rated Input Voltage: 100 V/70 V
10Rated I peda e . KΩ/ . KΩ/ . KΩ 11Connection: 4-pole screw plastic block 12Material Frame-proof ABS
13Standard CE and RoHS compliant
66 Projection Speaker 1Bidirectional Projection Speaker that provides a broad frequency response range, low
distortion, and high sound pressure level
21 unit
(Termasuk instalasi) 2Mounting option: Ceiling or Wall mount
3Intelligible voice and superior sound reproduction 4Suitable for indoor and outdoor environment 5Rated Power 20 W (10Wx2), Max Power 30 W 6Power taps (at 100V): 20 W/10 W/5 W/2.5 W 7SPL at 20W/1W (200Hz-15kHz, 1m): 107 dB/98 dB 8Frequency Response (at -10 dB): 150 Hz - 20k Hz 9Dispersion Angle (at 1k Hz/-6 dB): 180° 10Rated Input Voltage: 100 V/70 V 11Rated I peda e: Ω/ kΩ/ kΩ/ kΩ 12Connector: Fire-resistant cable 13Standard IP 65
67 Horn Speaker 1Horn Loudspeaker is attached with strong and adjustable mounting bracket to direct the sound beam
4 unit
(Termasuk instalasi) 2Rated Power 30 W, Max Power 45 W
3Power taps (at 100V): 30 W/15 W 4Power taps (at 70V): 15 W/7.5 W 5SPL at 30W/1W (4k Hz, 1m): 117 dB/105 dB 6Frequency Response (at -10 dB): 250 Hz - 10k Hz 7Dispersion Angle ( at 1k Hz/-6 dB ): 140° 8Rated Input Voltage: 100 V/70 V
9Rated I peda e: Ω/ Ω
10Connector: Flexible wire
11Outdoor IP 66, Water & Dust protected 12Material ABS
13Standard CE and RoHS compliant
68 Panel Intrusion Alarm berbasis jaringan 1Commercial alarm panel listed for residential burglary, residential fire and commercial
burglary applications
3 unit
(Termasuk instalasi dan pelatihan) 2Support 9 style-B hardwired zones and up to 119 additional zones using built-in polling
loop interface
3Support up to 127 wireless zones
4Support up to 150 user codes with 7 authority levels 5Support up to 96 programmable outputs
6Keeps event logs up to 512 events
7Support IP communicators over the panel keypad bus 8Telco line cut detection
9Support features Quick Exit, Group Bypass, Arm Faulted and Event Arming 10Alarm Sounder Output: Range 10VDC-13.8VDC, Maximum 1.7 amps 11Auxiliary Power Output: Range 9.6VDC- 13.8VDC, Maximum 750mA 12Backup Battery: 12VDC, 4AH or 7AH sealed-lead acid.
13Standby Time: Minimum 4 hours with 750mA aux. load using 7AH battery
14Standards: UL609 Grade A; UL1610 Grades A, AA; UL365 Grades A, AA; UL985; UL1023; UL1635
69 Dual Tec Motion Sensor 1Sensor Range: 12 m x 17 m 9 unit
(Termasuk instalasi) 2Operating Power:
- Voltage: Range 9.0 - 15 VDC;
- Current: Typical 11 mA, Maximum 13 mA
3Alarm Relay: Energized Form A; 30 mA, 25 VDC, Maximum 22 Ohms resistance 4Alarm Relay Duration: 3 seconds
5Tampers: Cover and Wall 6Microwave Frequency 10.525 GHz
7RFI Immunity: 20V/m 10-1000 MHz, 15V/m 1000-2700 MHz 8PIR White Light Immunity: Typical 6,500 Lux
9Fluorescent Light Filter: 50/60 Hz 10Operating Temperature: -10°C to 55°C 11Relative Humidity: 5 to 93% (non-condensing)
70 Strobe Light 1High intensity flashes strobe light 12 unit
(Termasuk instalasi) 2Mounting option: Surface mounted or mounted on alarm bell housing
3Voltage: Range 5 to 15 VDC 4Flash Rate: 60/minutes @ 6VDC 5Weather resistant for outdoor
71 Panic Button 1Microswitch rated at 10AMP at 250VAC 2 unit
(Termasuk instalasi) 2Metal Case
3Output: Normally Closed (NC), Normally Open (NO)
72 Temperature Sensor 1Dual Temperature Sensor 1 unit
(Termasuk inst
