A R I P I N
2002 - 21 – 140
TEKNIK INDUSTRI
UNIVERSITAS INDONUSA ESA UNGGUL
2004
MENURUNKAN CACAT NO POWER PADA PRODUKSI
TV
DENGAN METODA SIX SIGMA
DI PT LG ELECTRONICS INDONESIA
MENURUNKAN CACAT NO POWER PADA PRODUKSI
TV
DENGAN METODA SIX SIGMA
DI PT LG ELECTRONICS INDONESIA
MENURUNKAN CACAT NO POWER PADA PRODUKSI
TV
Makin bertambah nilai sigma,
makin berkurang biaya kualitas dan waktu siklus
Sigma adalah ukuran satuan statistik yang menggambarkan
kemampuan suatu proses dan ukuran nilai sigma dinyatakan dalam
DPU (Defect Per Unit) atau PPM
Dapat dikatakan bahwa proses dengan nilai sigma lebih tinggi
dalam proses akan mempunyai cacat yang lebih sedikit
Konsep Six Sigma
Six Sigma : Suatu sistem yang flexibel untuk memperbaiki kinerja
yang mendukung sukses secara terus-menerus.
Six Sigma dibangun berdasarkan banyak ide manajemen yang penting dan
Menggunakan Z sebagai satuan ukuran kemampuan proses
Bila keragaman / variasi turun, maka
kemungkinan cacat juga turun,
maka kemampuan (capability)
meningkat
Kemampuan 6s
1σ
•
Z = 3
2σ 3σ
Kemampuan 3s
USL LSL
USL LSL
•
Z = 6
1σ 2σ 3σ 4σ 5σ 6σ
= s =( Xi- X )
2
i = 1 n
n - 1
Sample’s standard deviation :
=
X=
Xi
i = 1 n
n
Sample’s average :
Z
=
x -
DEFINE
MEASURE
ANALYZE
IMPROVE
CONTROL
•Identify Customer’s CTQ
•Develop a team charter
•Defne and build a process
map
•Validate problem
/ process
•Measure key
problem
•Current
condition
•Screening potential
factor
•Identify vital few root
causes
•Validate hypothesis
•Develop ideas to cut
of root causes
•Optimation solution
•Measure solution
•Standardize
solution
•Establish standard
measure to
maintain
performance
μ
USL USL
T
Tepat namun tidak akurat
Geser
menuju
Target
Turunkan
Variasi
μ
USL USL
T
Shifting/bergeser ke Target & Mereduksi Variasi
Object
dari 6
adalah
Shift(geser) ke target
Menurunkan Variasi
Konsep Six Sigma
USL USL
T
μ
Aplikasi detail Six Sigma
Perbaikan dengan Metoda Six Sigma ( DMAIC )
REDUCE SMPS TRANSFORMER
SHORT ( NO POWER )
REDUCE SMPS TRANSFORMER
SHORT ( NO POWER )
2004 06 14
Incoming Quality Control
Project Registration Sheet
Current
Target
Improvement Ratio (%)0 PPM
Role
Dept
Telp.
Name
February 3 ~ 6, 2004
February 9 ~ 21, 2004
February 24 ~ 28, 2004
March ~ May, 2004
REDUCE SMPS TRANSFORMER
SHORT ( NO POWER )
Short Test as check point at line
production of Samwha and IQC LGEIN.
Good reliability part
WIRE HOLE
WIRING CROSS
CHECKING PROSSES
Aripin
QA
212
• Material Checking method
• Quality System set up
Problem Situation
Management policy said we have reduce field claim.
Data field claim show No Power is cause biggest
than other.
No power is TV Set have no supply voltage. It show by not light ofIndicator power and no display on tube.
No power can caused by parts, like power cord, SMPS Transformer, IC, FBT, Transistor and others.
SMPS Transformer have function as divider power voltage to several sub circuit or part like FBT, IC, and others.
If SMPS not function, it can’t supply voltage to parts or sub circuit
.
840 PPM
Defect Analysis by No Power
5 WORST SYMPTOM IN 2003
No Power
Data field claim 2003
29%
Defect Analysis by Model
Improve TV Quality
Attribute 30% SCR Reducing Improve TV Quality
Attribute
Big Y
Little y2
Bad SystemConnector
AGC Circuit
FrontCabinet Dented PWB Short Bad Wiring Connection
LoosenPart
Opt. Skill, Ability Wire Connection
Handling Handling Opt. Skill, Ability Wrong Connection
Handling AGC Circuit Opt. Skill, Ability
No connection How to Use How to used Plug Connection
Environment
Chassis Reliability
Screen Focus, DYC,PRT ABL Short AGC, No Ruster No Sound Problem
No Power Un Connect
Reliability
1P1P IQC Finished
Theme Selection
Process Mapping
LGEIN LQC
LGEIN LQC
• PatrolPatrol
• PerformancePerformance
Final
Final
Inspect
Inspect
SAMWHA
SAMWHA
Process
Process
•R&DR&D
• PurchasePurchase
•IQCIQC
•ProductionProduction
• LQCLQC
• OQCOQC
LGEIN OQC
LGEIN OQC
• ELTELT
• LTLTLTLT
•Reliability Reliability Product
Product
LGEIN IQC
LGEIN IQC
• AppearanceAppearance
• DimensionDimension
•StructureStructure
•PerformancePerformance
• AssemblingAssembling
• Reliable PartReliable Part
High defect
SMPS no power
At LGEIN production
Selecting Best
Condition
for reliable Part
Find Out what is
the Main Cause of
Problem
• OS&D
SMPS
Component :
• Core
• Bobbin
• Wire
• Insulation
• Tape
• Shield
SMPS
What is SMPS Transformer ?
7
5
1
2 9
8
10
14
12 13
Output of SMPS (Voltage)
• Pin 9 - 8 : 24 ~ 25
• Pin 10 - 11 : 10 ~ 12
• Pin 14 - 13 : 110 ~ 115
• Pin 13 - 12 : 13 ~ 14
• Pin 1 – 2 : 7 ~ 10
Potential Short
Area
Short can be happen if one of wire on potential area
get direct connect.
Clarification Of Y
Indicator
Display
TV Set Power OK TV Set No Power
No Power
SMPS
SMPS
DEFECT
DEFECT
APPEARANCE
APPEARANCE
DIMENSION
DIMENSION
PERFORMANCE
PERFORMANCE
MARKING NG
MARKING NG
RUST
RUST
ISOLATION NG
ISOLATION NG
P/P OVER
P/P OVER
WIRE SHORT
WIRE SHORT
BROKEN
BROKEN
TURNS
TURNS
Kind of defect by SMPS
Master Signal
Test Signal
Master Signal= Test Signal
NG SIGNAL DISPLAY OK SIGNAL DISPLAY
SMPS Transformer Characteristic
Display of Surge Comparison Tester ( ST-215 ) will
show two signal both master and part test.
If form signal different that’s part NG
and if same is OK
.Demonstration of Data gathering
Measurement (
Gage R&R)
Date of study : JANUA RY 15. 2004 Reported by : ARIPIN Name of product: SHORT TEST Misc:
Assessment Agreement
Within Appraisers Appraiser vs Standard
Assessment Agreement : 100 %
Operator is good in inspection
Instrument is valid and reliable
Measurement System are
Acceptable
Instrument : Surge Comparison Tester ( ST-215 )
Agreement Analysis
Within Appraisers :
Appraiser agrees with himself across trial
Appraiser # Inspected # Matched Percent 95 % CI OPR-1 25 25 100.00 (86.09, 100.00) OPR-2 25 25 100.00 (86.09, 100.00) OPR-3 25 25 100.00 (86.09, 100.00)
Each Appraiser vs Standard :
Appraiser's assessment across trials agrees with the known standard
Appraiser # Inspected # Matched Percent 95 % CI OPR-1 25 25 100.00 (86.09, 100.00) OPR-2 25 25 100.00 (86.09, 100.00) OPR-3 25 25 100.00 (86.09, 100.00) Between Appraisers :
All appraisers' assessments agree with each other. Assessment Agreement
# Inspected # Matched Percent 95 % CI 25 25 100.00 (86.09, 100.00)
Sample Attribute Try 1 Try 2 Try 1 Try 2 Try 1 Try 2 1 Pass Pass Pass Pass Pass Pass Pass 2 Pass Pass Pass Pass Pass Pass Pass 3 Pass Pass Pass Pass Pass Pass Pass 4 Fail Fail Fail Fail Fail Fail Fail
21 Fail Fail Fail Fail Fail Fail Fail 22 Pass Pass Pass Pass Pass Pass Pass 23 Pass Pass Pass Pass Pass Pass Pass 24 Fail Fail Fail Fail Fail Fail Fail 25 Fail Fail Fail Fail Fail Fail Fail Known Population OPR 1 OPR 2 OPR 3
Capability Process (Current)
Based on data October ~ December ‘03, defect SMPS 124 ea from 147595 ea.
Based on data October ~ December ‘03, defect SMPS 124 ea from 147595 ea.
• Defect Op. = 1 ( Wire Short )
• DPU = 124 : 147595
• DPO = 124 : ( 147595 x 1 ) = 8.4E-04
• DPMO = DPO x 1.000.000 = 840 PPM
From Z Normal table, we get :
DPO = 8.4E-04
Z Value = 3.1 + 0.04
= 3.14
Our Condition now :
Sigma level
= 3.14+ 1.5
=
4.64
8.45E-04
3.1
0.04
Estimate Cause Analysis
By Analyzing all potential problem that could have significant effect for SMPS Performance,
thru
Brainstorming
and screening
, we succeed to collect some root cause for the problem
Material
Method
wire
Hole
Space
Finishing
Core
Turn wiring
Home pin
Varnish
Dielectric Breakdown
Press
Short (No Power)
Potential Factor
Selecting Vital Factor
Test and CI for Two Proportions
Sample X N Sample p 1 0 25 0.000000 2 19 25 0.760000 Difference = p (1) - p (2) Estimate for difference: -0.76
95% CI for difference: (-0.927414, -0.592586) Test for difference = 0 (vs not = 0): Z = -8.90
P-Value = 0.000
-
Since P-Value < 0.05, Reject Ho
Since P-Value < 0.05, Reject Ho
-
It’s mean that
It’s mean that
Dielectric breakdown
Dielectric breakdown
has an effect or SMPS reliability.
has an effect or SMPS reliability.
Dielectric Breakdown is
Dielectric Breakdown is
Vital Few factor
Vital Few factor
X
1 = Dielectric BreakdownHypothesis Testing
Ho : P P 2 ( There are no different Proportion Between D/B below 2250 V and D/B above 2250 V)
Ho :
P
≠P
( There are different Proportion Between D/B below 2250 V and above 2250 V)Sample 2250 Decision Sample 2250 Decision
1 2235 FAIL 14 1850 FAIL 2 1990 FAIL 15 2230 FAIL 3 2010 FAIL 16 1990 FAIL 4 2240 FAIL 17 2010 FAIL 5 2125 FAIL 18 1890 FAIL 6 2150 FAIL 19 2110 FAIL 7 2250 FAIL 20 2225 FAIL 8 1990 FAIL 21 2000 FAIL 9 2000 FAIL 22 2010 FAIL 10 2230 FAIL 23 1995 FAIL 11 2000 FAIL 24 1890 FAIL 12 1985 FAIL 25 1885 FAIL 13 1960 FAIL
D/B : 2250 V
Sample 2250 Decision Sample 2250 Decision
1 5430 PASS 14 4300 PASS 2 4795 PASS 15 5800 PASS 3 4500 FAIL 16 7800 FAIL 4 5350 PASS 17 7900 PASS 5 6000 FAIL 18 4600 FAIL 6 5100 PASS 19 5800 PASS 7 5700 PASS 20 5500 PASS 8 5700 PASS 21 7500 PASS 9 4500 PASS 22 7900 PASS 10 5000 PASS 23 5600 PASS 11 4100 PASS 24 4500 FAIL 12 4250 FAIL 25 6500 PASS 13 5600 PASS
D/B : 2250 V
Selecting Vital Factor
Test and CI for Two Proportions
Sample X N Sample p 1 25 25 1.000000 2 14 25 0.560000 Difference = p (1) - p (2) Estimate for difference: 0.44
95% CI for difference: (0.245420, 0.634580) Test for difference = 0 (vs not = 0):
Z = 3.76
P-Value = 0.000
-
Since P-Value < 0.05, Reject Ho
Since P-Value < 0.05, Reject Ho
-
It’s mean that
It’s mean that
Pin Hole Wire
Pin Hole Wire
has an effect or SMPS reliability.
has an effect or SMPS reliability.
Pin Hole Wire is
Pin Hole Wire is
Vital Few factor
Vital Few factor
X
2 = Pin Hole WireHypothesis Testing
Ho : P P 2 ( There are no different Proportion Between Pin Hole Below 5 and Above 5)
Ho :
P
≠P
( There are different Proportion Between Pin Hole Below 5 and Above 5)Sample 5 Decision Sample 5 Decision
1 0 PASS 14 1 PASS
Sample 5 Decision Sample 5 Decision
Sample Varnish Decision Sample Varnish Decision
1 V PASS 14 V PASS 2 V PASS 15 V PASS 3 V PASS 16 V PASS 4 V PASS 17 V PASS 5 V PASS 18 V PASS 6 V FAIL 19 V PASS 7 V PASS 20 V PASS 8 V PASS 21 V PASS 9 V PASS 22 V FAIL 10 V PASS 23 V PASS 11 V FAIL 24 V PASS 12 V PASS 25 V PASS 13 V PASS
Sample Non Vr. Decision Sample Non Vr. Decision
1 NV PASS 14 NV PASS 2 NV PASS 15 NV PASS 3 NV FAIL 16 NV PASS 4 NV PASS 17 NV PASS 5 NV PASS 18 NV PASS 6 NV PASS 19 NV PASS 7 NV PASS 20 NV FAIL 8 NV PASS 21 NV PASS 9 NV PASS 22 NV PASS 10 NV FAIL 23 NV FAIL 11 NV PASS 24 NV PASS 12 NV PASS 25 NV PASS 13 NV PASS
X3 = Pressure
Hypothesis Testing
H0 :
P 1 = P
2 (
There are no different Proportion Between varnish and no varnish )
H1 :
P 1 ≠ P 2 (There are different Proportion Between varnish and no varnish )
Varnish
No Varnish
Test and CI for Two Proportions
Sample X N Sample p 1 22 25 0.880000 2 21 25 0.840000 Difference = p (1) - p (2) Estimate for difference: 0.04
95% CI for difference: (-0.152036, 0.232036) Test for difference = 0 (vs not = 0):
Z = 0.41
P-Value = 0.683
P Value > 0.05, Receive H0,
Varnish
not significant as Vital Factor
.
13 - 22
Sample Space Decision Sample Space Decision
Sample No Space Decision Sample No Space Decision
1 NS PASS 14 NS PASS
No Space Space
No Space
Space
P Value > 0.05, Receive H0
,
Space not significant as Vital Factor
.
Test and CI for Two Proportions
Sample X N Sample p 1 22 25 0.880000 2 24 25 0.960000 Difference = p (1) - p (2)
Estimate for difference: - 0.08
95% CI for difference: (-0.152036, 0.232036) Test for difference = 0 (vs not = 0):
Z = 0.41
P-Value = 0.297
14 - 22
Sample Cross Decision Sample Cross Decision
Analyzing Finishing Method by Comparing whether Parallel winding and Cross Winding contribute a significant
effect for wire short.
Parallel
Cross
Test and CI for Two Proportions
Sample X N Sample p 1 14 25 0.560000 2 24 25 0.960000 Difference = p (1) - p (2) Estimate for difference: -0.4
95% CI for difference: (0.609193, -0.190807)
Test for difference =0(vs not = 0):
Z =-3.75
P-Value = 0.000
-
Since P-Value < 0.05, Reject Ho
Since P-Value < 0.05, Reject Ho
-
It’s mean that
It’s mean that
Finishing Method
Finishing Method
has an effect or SMPS reliability.
has an effect or SMPS reliability.
Finishing Method is
Finishing Method is
Vital Few factor
Vital Few factor
X
5 = Finishing Method (Winding Method)Hypothesis Testing
Ho : P P 2 ( There are no different Proportion Between Parallel and Cross)
Ho :
P
≠P
( There are different Proportion Between Parallel and Cross)Cross Parallel
Sample Parallel Decision Sample Parallel Decision
1 P PASS 14 P PASS
16 - 22
Vital View
Material
Method
wire
Hole
Space
Cross
Core
Turn wiring
Home pin
Varnish
Dielectric Breakdown
Press
Short (No Power)
Vital View
Vital View
Selecting Vital Factor
Need improved
Not need improved
Selecting Optimum Condition
• Dielectric Breakdown ( ↑ 2250 V and ↓ 2250V)
• Wire Hole (
↑ 5 and ↓5 / on 5 Meters
)
• Method Finishing Home Pin ( Cross and parallel)
Optimum condition :
Dielectric Breakdown :
↑
2250 V
Pin Hole :
↓
5 hole / 5 m
Method Finishing : Parallel
P
C H +
H -DB +
DB -MTD H
DB
50
100 0
0
40
70 0
0
Cube Plot (data means) for PASS ( % )
Opt. Condition
DB PH MTD Pass %
DB - PH + P 0
DB - PH + C 0
DB + PH + P 50
DB + PH + C 40
DB + PH - C 70
DB + PH - P 100
DB - PH - P 0
DB - PH - C 0
In this Step, we try to find the optimum combination of all factors which have a
significant effect on SMPS Transformer Reliability.
Improvement
Improvement on Finishing Method at Samwha Process
Before :
Finishing wire of pin 12 is upper ( entered to home pin )
After :
Finishing wire of pin 10 is upper ( entered to home pin ) Finishing wire of pin 12 is lower then pin 10.
4 M Change Report
8
╚
╝
Cross Method Parallel Method
Change Wire Winding
Improvement
Improvement on Inspection Checking Method
Before
Before
Before
Before
After
After
After
After
Delivery
Sampling
Inspection (Conventional)
Storage Area Incoming
OK
NG IQC
• Appearance
• Size Supplier
Inspection
Check hole & D Breakdown
Storage Area Incoming
OK
NG IQC
• Appearance Size
• 5 m each roll wire ( test hole & D Breakdown ) Supplier
Sampling Delivery
IQC Samwha
IQC Samwha
• Involving new item inspection as an
new inspection check point :
• Check hole wire by Phenolphthalein
( > 5 hole/5m, NG )
• Dielectric Breakdown test
Content
Content
Content
Content
To keep good condition, we do :
Dielectric breakdown and hole wire control at wire vendor ( monthly )
Wire hole test before to production
Item CTQ Control
QC and Process Irregular Audit at Supplier
Total Inspection Part (100% Short Test)
D/B
I Chart of INDUCTANCE
Inductance
I Chart of RESISTANCE
CTQ
Maintain CTQ
Part production on March ~ May ‘04 are 245915 EA, SMPS Transformer defect: 1 ea
DPU = 1 : 184259 = 5.427E-6
▶
DPMO = 4 PPM , Sigma Level = 5.97
Condition part Oct ~ Dec’03
No Power by SMPS
Part No
BOIL BOIK OTHE RS
Condition part Mar ~ May ’04
No Power by SMPS
Part No
22 - 22
