Introduction
• Every day you ask questions with a spatial component.
• Whether you are at work, studying or at leisure you probably ask spatial questions.
• Many of these questions you answer for
yourself without reference to a map or a GIS,
but both of these tools could help. GIS has
particular value when you need to answer
questions about location, patterns, trends and
conditions such as those below:
Spatial Questions :
• Location. Where is the nearest bookshop? Where are stone age settlements located in Europe? Where are areas of
forestry in which Norwegian Spruce trees can be found?
• Patterns. Where do high concentrations of students live in this city? What is the flow of traffic along this motorway?
What is the distribution of crime incidents in London?
• Trends. How are patterns of retailing changing in response to the development of out-of-town superstores? Where have
glaciers retreated in the European Alps? Where have
changes to the population of polar bears occurred?
• Conditions. Where can I find holiday accommodation that is within 1 km of a wind surfing beach and accessible by public transport? Where is there flat land within 500 m of a major highway? Where are there over 100,000 potential customers within a 5 mile radius of a railway station?
• Implications. If I move to a new home in this location, how
far will I be from the office, gym or coffee shop? If we build
a new theme park here, what will be the effect on traffic
flows? What would be the time saving if we delivered our
parcels using this route, rather than an alternative?
Dengan SIG : dapat mengintegrasikan data spasial dan data non spasial untuk menjawab berbagai pertanyaan
• What is there ...? Identification: by pointing at a location on a map, a name, or any other information stored on the object, is returned.
This could also be done without maps, by providing the coordinates, but this would be far less effective and efficient.
• Where is ...? Location: this question results in one or more locations that adhere to the criteria of the question’s conditions.
This could be a set of coordinates or a map that shows the location of a specific object, or all buildings in use by a certain company.
• What has changed since ...? Trends: this question includes geospatial data’s temporal component. A question related to urban growth could result in a map showing those neighbourhoods built between 1950 and 1990.
• What is the best route between ...? Optimal path: based on a network of paths (e.g. roads or a sewage system), answers to such queries for the shortest or cheapest route are provided.
• What relation exists between ...? Patterns: questions like this are more complex and often involve several data sets.
Answers could, for instance, reveal the relationship between the local microclimate and location of factories and the social structure of surrounding neighbourhoods.
• What if ...? Models: these questions are related to planning
and forecasting activities. An example is: what will be the
need to adapt the local public transport network and its
capacity when a new neighbourhood is built north of the
town?
Typical GIS questions answered by maps such as those used to identify, to locate, or to find geospatial patterns
8
Advanced Spatial Analysis
Geographic Information System (GIS) is defined as an information system that is used to input, store, retrieve,manipulate, analyze and output geographically referenced data or geospatial data, in order to support decision making for planning and management of land use, natural resources, environment, transportation, urban facilities, and other administrative records
Output GIS utama : Peta
Geographic Information System (GIS)
KONSEP, PERKEMBANGAN DAN
PERANAN KARTOGRAFI
Materi Pokok:
• Sejarah/ Perkembangan Kartografi
• Konsep dasar Kartografi,
• Konsep dasar Peta,
• Fungsi Peta
INFORMASI GEOSFERA :
- Informasi Lithosfera - Informasi Biosfera - Informasi Pedosfera - Informasi Antroposfera - Informasi Hidrosfera - Informasi Atmosfera
INFORMASI GEOGRAFIS
Analisis
Klasifikasi
Evaluasi
Sintesis
INFORMASI GEOGRAFIS Pendekatan :
Keruangan
Kelingkungan
Kompleks Wilayah
Instrumen :
Kartografi
PJ
Pembuat Kebijakan
Penentu Kebijakan
Perencana (Planner)
Perancang (Designer)
Kedudukan PJ, Kartografi, SIG, Dlm Lingkup
Studi Geografi
History of Cartography
• Ancient Times
• Middle Ages
• Age of Exploration
• Modern Age
Perkembangan Kartografi
1.Jaman Kuno
- Peta Manuskrip (dibuat dengan tangan) - Contoh : peta jaman Yunani, Tiongkok, dll
2. Jaman Pertengahan : (s/d th 800) - Didominasi oleh agama (Gereja)
- Bumi digambar secara simetris
3. Jaman Renaisance
- Perubahan besar dalam perpetaan
- Kesadaran ketertinggalan thd bangsa Timur (Arab) - Kembali ke prinsip kartografi dan geografi
- Peta dpt dicetak dengan cepat, banyak, murah - Penemuan daerah baru semakin banyk
SEJARAH KARTOGRAFI
4. Jaman Modern :
- Penemuan peralatan baru, sehingga pemetaan lebih cepat dan tepat
- Banyak peperangan besar, kebutuhan akan peta meningkat
- Meluasnya hubungan internasional - Penemuan foto udara
- Perkembangan ilmiah semakin maju
Era Digital :
- Penemuan teknologi informasi spasial (komputer,
peralatan survey, remote sensing, GIS)
• Sejarah Kartografi.pdf
Ancient Times
ca 900 BC
Babylonian world map
on clay tablet. Babylon
is at the center. (900
BC)
Timesca. A.D. 335-366 Peutinger Map. Segment of the earliest known road map of the Roman empire.
Ancient Times
1109 AD. Beatus Map, Religious beliefs shown alongside geographic facts.
Ancient Times
Middle Ages
1154AD. Portion of the World map by Muhammed b.Muhammedal- Idrisi.
He was an Arab cartographer at the court of King Roger of Sicily. Arabian peninsula,top center. South is at the top.
CONTOH SEJARAH PERKEMBANGAN PETA
KARTOGRAFI (sesudah th 60-an):
- Kartografi dikelompokkan dalam bidang ilmu pengetahuan komunikasi
- Kartografi didukung perkembangan teknologi komputer yang pesat
KARTOGRAFI : Penyampaian informasi geospasial dalam bentuk peta
--- Bidang kartografi tidak hanya pembuatan
peta, tetapi juga penggunaan peta
KARTOGRAFI :
Adalah Seni, Ilmu pengetahuan dan teknologi
tentang PEMBUATAN PETA, sekaligus mencakup
studinya sebagai dokumen ilmiah dan hasil karya
seni (ICA) --- penekanan : Pembuatan Peta
PETA adalah : Gambaran Permukaan Bumi
Yang diproyeksikan ke bidang datar dengan skala tertentu
KONSEP DASAR
PETA
KONSEP DASAR PETA
Gambaran konvesional & selektif yang diskalakan (diperkecil), biasanya dibuat pada bidang datar yang meliputi perujudan-perujudan (features) bentuk pada muka bumi atau yang ada kaitannya dengan permukaan bumi atau benda-benda angkasa (International Cartographic Association (I.C.A) Sinaga, 1995 : 5).
Secara umum, peta adalah suatu model penyajian, yang
memungkinkan seseorang menangkap kesan struktur
fenomena yang disajikan
sungai jalan permukiman hutan
relief
Apa yang dimaksud dengan permukaan bumi ?
• Peta merupakan penyajian yang SELEKTIF, berarti bahwa obyek yang tergambar pada peta dipilih (diseleksi) sesuai dengan skala dan maksud / tujuan peta.
• Selektif dalam peta umum : berarti bahwa pemilihan obyek yang digambarkan dibatasi oleh skala. Semakin besar skala semakin banyak detail informasi yang digambarkan dan sebaliknya.
• Selektif dalam peta khusus : berarti bahwa
pemilihan obyek yang digambarkan berdasarkan
tema.
Bagaimana Obyek Permukaan Bumi Digambarkan ?
1. Obyek digambarkan dengan simbol
2. Bentuk Permukaan bumi digambarkan dengan Proyeksi Peta
3. Detail informasi obyek ditentukan dengan skala
4. Jenis informasi digambarkan berdasarkan thema
a) Peta Umum
Peta yang berisi keterangan-keterangan umum
yang bersifat fisis ataupun yang bersifat sosial
ekonomis. Contohnya: Peta Topografi, Peta Rupa
Bumi (peta umum berskala besar), Peta Chorografi
(peta umum berskala menengah) dan Peta Dunia
atau Atlas (peta umum berskala kecil).
Contoh Peta Umum
CONTOH PETA DIGITAL 1 : 25.000
b) Peta Tematik
Adalah peta yang berisikan keterangan-keterangan khusus untuk bidang tertentu (berisi tema-tema kertentu, sesuai dengan tujuan pembuatan peta).
Contoh : Peta Iklim, Peta Pariwisata, Peta Geologi,
Peta Tanah, Peta Hidrologi, Peta Kepadatan
Penduduk, Peta Kesesuaian Lahan, dll
INFORMASI DIGAMBARKAN SESUAI TEMA
PETA BATIMETRI
PETA BATAS
PETA ADMINISTRASI
PETA TOPOGRAFI
Obyek di permukaan bumi dapat dipetakan berdasarkan maksud
dan tujuan pengguna
Contoh Peta Tematik
1. Visualisasi data keruangan (geospasial)
Data Geospasial : data yang berkenaan dengan lokasi atau atribut suatu obyek/ fenomena di permukaan bumi
Peta memudahkan pemahaman hubungan geospasial : - posisi / lokasi
- Jarak, arah, Luasan - Bentuk, Ukuran
- Pola, hubungan
2, Penyimpanan, penampilan, dan penayangan hasil akhir data geospasial 3. GDI (Geospatial Data Infrastructure) : infrastruktur untuk mengakses
data geospasial sedang dikembangkan, shg mempermudah akses terhadap data geospasial yang telah dibuat dan dikelola sehingga dapat digunakan untuk pemantauan/ monitoring
4. Pengumpulan seleksi dan Analisis data
5. Media komunikasi (pembuat peta dengan pengguna peta)
FUNGSI PETA : ALAT ANALISIS SPASIAL
FUNGSI PETA
Rumah
RS BNI
Gramedia
Lewat manakah saya ke Toko Gramedia ?
Dari rumah lurus ke utara mengikuti jalan ini melewati perempatan, terus melewati jembatan sungai, sampai di perempatan berikutnya belok ke
kanan
sekitar 200 meter di sebelah timur Bank BNI atau persis di depan RS
Lebih Mudah Manakah ?
Daerah permukiman manakah yang rawan banjir ?
Dimanakah lokasi yang akan tergenang air ?
Lokasi manakah yang masih bisa dikembangkan untuk lokasi permukiman ? Berapa luas hutan yang masih ada ?
