PEKERJAAN : VILLA EMILIA 1 SESEH
LOKASI : SESEH
ANGGARAN : 2023
VOL. SAT.
I PANEL
I.1 GROUND FLOOR
1. MCB 10 KA 40 A 1,00 Bh
2. MCB 10 KA 20 A 1,00 Bh
3. MCB 10 KA 25 A 1,00 Bh
4. MCB 6 KA 10 A 7,00 Bh
5. MCB 10 KA 16 A 11,00 Bh
6. MCB 6 KA 6 1,00 Bh
I.2 FIRST FLOOR
1. MCB 6 KA 10 A 3,00 Bh
2. MCB 10 KA 16 A 8,00 Bh
3. ELCB 300 MA 25 A 1,00 Bh
4. MCB 10 KA 16 A 3,00 Bh
I.3 FUSE BOXPUMP ROOM
1. MCB 6 KA 10 A 12,00 Bh
2. MCB 6 KA 6 A 1,00 Bh
I.4 KEBUTUHAN KABEL
1. Kabel NYM 3 x 2,5 mm² 4,00 Roll
2. Kabel NYY 4 x 4 mm² 25,00 m
3. Kabel Bc 6 mm² 30,00 m
4. Kabel NYFGbY 4 x 4 mm² 35,00 m
5. Kabel NYFGbY 4 x 10 mm² 35,00 m
6. Kabel BC 10mm² 30,00 m
7. Kabel BC 50 mm² 30,00 m
KEBUTUHAN MATERIAL ELEKTRIKAL
URAIAN PEKERJAAN
8. Pipa PVC 3/4" 7,50 Btg
II AKSESORIS INSTALASI LISTRIK II.1 PEKERJAAN INSTALASI BASEMEN
1. Ship Lamp 7W 1,00 Bh
2. One Gang Switch 1,00 Bh
3. Waterproof Socket Outlet 2,00 Bh
II.2 PEKERJAAN INSTALASI LT. 1
1. Recessed Downlight Mr16 GU5.3.4.5W/220V 3,00 Bh
2. Hanging Lamp LED Bulb E-27 7W 17,00 Bh
3. Up Light MR16 GU5.3.4.5W/12V 12,00 Bh
4. TL LED Lamp 2 x 18W 3,00 Bh
5. Wall Lamp Decorative LED Bulb E-27 6W 8,00 Bh
6. Spike Monteted Tree Uplighter MR16 GU5.3.4.5W/220V 3,00 Bh 7. Wall Lamp Up & Down Cylinder LED Bulb E-27 (2x4W) 17,00 Bh
8. Recessed Pool lamp 7W 2,00 Bh
9. Ceilling Fan 80W 3,00 Bh
10. CeillingExhaust Fan 25W 2,00 Bh
11. One Gang Switch 6,00 Bh
12. Two Gang Switch 3,00 Bh
13. One gang Two Way Switch 4,00 Bh
14. Door Bell 1,00 Bh
15. Fan Control 3,00 Bh
16. Socket Outlet 23,00 Bh
II.3 PEKERJAAN INSTALASI LT. 2
1. Recessed Downlight Mr16 GU5.3.4.5W/220V 6,00 Bh
2. Hanging Lamp LED Bulb E-27 7W 16,00 Bh
3. Wall Lamp Decorative LED Bulb E-27 6W 13,00 Bh
4. Ceilling Fan 80W 2,00 Bh
5. One Gang Switch 9,00 Bh
6. One gang Two Way Switch 6,00 Bh
7. Socket Outlet 16,00 Bh
8. International Socket Outlet + USB 4,00 Bh
9. Power AC 2,00 Bh
Syafira Chairunisa Franck
Makassar, 11 Agustus 2023
Mengajukan Menyetujui
