DAFTAR BAHAN LOMBA KETERAMPILAN SISWA SMK TINGKAT NASIONAL TAHUN 2017
KEJURUAN : REFRIGERATION & AC Keperluan : Untuk 1 (satu) orang peserta
No Nama Bahan Spesifikasi Merk Jumlah Satuan Harga Satuan JUMLAH (Rp)
REFRIGERATION SYSTEM INSTALLATION AND COMMISSIONING
1 Condensing Unit Optima OP-HJZ019D49N Danfoss 1 Unit 8,000,000 8,000,000
2 Dual Pressure Swich KP-15 Danfoss 1 pcs 600,000 600,000
3 Bracket for Dual Pressure Swich KP-15 Danfoss 1 pcs 30,000 30,000
4 Expansion Valve (internal equalizer) AKV 10-2 Danfoss 1 pcs 450,000 450,000
5 Glycol Pump 30 Watt,2000 l/h Pedrollo 1 pcs 500,000 500,000
6 Filter Dryer 3/8" x 3/8" Danfoss 1 pcs 200,000 200,000
7 Sight glass 3/8" x 3/8" Danfoss 1 pcs 250,000 250,000
8 Refrigerant R134A Dupont 1 Can 1,500,000 1,500,000
9 Glycol 1 Can 150,000 150,000
10 Orifice 0,0 Danfoss 1 pcs 100,000 100,000
11 Soft drawn copper tube 3/4 inch tickness 0,8 mm Kembla 1 Roll 1,200,000 1,200,000
12 Soft drawn copper tube 1/2 inch thicness 0,8 mm Kembla 1 Roll 750,000 750,000
13 Soft drawn copper tube 3/8 inch thicness 0,8 mm Kembla 1 Roll 600,000 600,000
14 Soft drawn copper tube 1/4 inch thicness 0,8 mm Kembla 1 Roll 450,000 450,000
15 Insulation Pipe 1/2" x 2m Armaflex 3 pcs 25,000 75,000
16 Glue for Insulation 250 gr Armaflex 1 Kaleng 70,000 70,000
17 Silver solder 15% silver 15% Harris 3 Batang 5,000 15,000
18 flare nut 3/4" - 4 Pcs 15,000 60,000
19 flare nut 1/2" - 6 Pcs 15,000 90,000
20 flare nut 3/8" - 8 Pcs 15,000 120,000
21 flare nut 1/4" - 8 Pcs 12,000 96,000
22 T-Piece 1/2" - 1 Pcs 30,000 30,000
23 T-Piece 3/8" - 1 Pcs 30,000 30,000
24 Reducer Sleeve 1/2" x 3/8" - 2 Pcs 25,000 50,000
25 Reducer Sleeve 3/4" x 1/2" - 2 Pcs 25,000 50,000
26 Reducer Sleeve 7/8" x 1/2" - 1 Pcs 25,000 25,000
27 Reducer T-Piece 3/8" x 3/8" x 1/4" - 1 Pcs 50,000 50,000
28 Reducer T-Piece 1/2" x 1/2" x 1/4" - 1 Pcs 50,000 50,000
29 Fitted Washer Galvanis 4mm x 10mm - 20 Pcs 1,000 20,000
30 Steel Superb Stead Screw 4mm x 12mm - 20 Pcs 500 10,000
31 Steel Superb Stead Screw 4mm x 25mm - 20 Pcs 500 10,000
32 Self Drilling Screw 4mm x 20mm - 20 Pcs 500 10,000
33 Self Drilling Screw 4mm x 10mm - 20 Pcs 500 10,000
34 Alumunium Rivet 1/8" x 15mm - 50 Pcs 200 10,000
35 Flexible Transparent Hose 3/8' x 1.5 mm - 5 meter 10,000 50,000
36 Hose Clamp 14mm-22mm - 4 Pcs 50,000 200,000
37 Stread Seal 18mm x 2500cm 1 Pcs 12,000 12,000
38 schrader valve 1/4" - 4 Pcs 10,000 40,000
39 Buckets with measurement scale 12 liter - 1 Pcs 25,000 25,000
40 electrical control panel 500x400x300mm - 1 Pcs 400,000 400,000
41 Ice rink tank By Drawing - 1 Pcs 1,200,000 1,200,000
42 Booth By Drawing - 1 Pcs 600,000 600,000
43 Electronic refrigerant controller danfoss ERC 102 C 220 VAC Danfoss 1 Pcs 1,000,000 1,000,000
44 Sensor PTC compatible with danfoss Danfoss 1 Pcs 150,000 150,000
45 selector switch 220 vac 6 A Schneider 1 Pcs 30,000 30,000
46 Indicator lamp 220 vac, red Schneider 1 Pcs 30,000 30,000
47 Indicator lamp 220 vac, green Schneider 1 Pcs 30,000 30,000
48 Indicator lamp 220 vac,yellow Schneider 1 Pcs 30,000 30,000
49 Indicator lamp 220 vac, white Schneider 1 Pcs 30,000 30,000
50 Magnetic contactor schneider, 25 A 220 VAC Schneider 2 Pcs 300,000 600,000
51 Auxiliary contact schneider, 25 A 220 VAC Schneider 1 Pcs 100,000 100,000
52 Over load Protector schneider, 25 A 220 VAC Schneider 1 Pcs 300,000 300,000
53 Kabel NYAF 0,75 mm merah Eterna 1 Roll 150,000 150,000
54 Kabel NYAF 0,75 mm biru Eterna 1 Roll 150,000 150,000
55 Kabel NYAF 2,5 mm merah Eterna 1 Roll 225,000 225,000
56 Kabel NYAF 2,5 mm biru Eterna 1 Roll 225,000 225,000
57 Kabel NYAF 2,5 mm kuning hijau Eterna 1 Roll 225,000 225,000
58 Kabel NYY 3x2,5 mm Eterna 1 Roll 350,000 350,000
59 Cable duct 32x32 mm - 1 Batang 25,000 25,000
60 Cable lug Y type 0,75 merah - 1 Pack 25,000 25,000
61 Cable lug Y type 0,75 biru - 1 Pack 25,000 25,000
62 Cable lug Y type 2,5 merah - 1 Pack 25,000 25,000
63 Cable lug Y type 2,5 biru - 1 Pack 25,000 25,000
65 Electrical Tape 19 x 20 meter 3M 1 pcs 15,000 15,000
66 Insulock 10 mm - 1 Pack 15,000 15,000
67 Mount tie 30x30 mm - 1 Pack 40,000 40,000
68 spiral cable protected 10 mm - 1 Roll 60,000 60,000
69 Kabel glen 22 mm - 4 Pcs 15,000 60,000
AIR CONDITIONING SYSTEM FAULTFINDING,REPAIR AND COMMISSIONING
1 Split Air Conditioning - Inverter type CS-S10KKP- Refrigerant : R410a - Capacity : 1 HP
Panasonic 1 Set 5,000,000 5,000,000
2 Bracket outdoor 1 pk - 1 Set 50,000 50,000
3 Soft drawn copper tube 3/8 inch thicness 0,8 mm Kembla 1 Roll 1,000,000 1,000,000
4 Soft drawn copper tube 1/4 inch thicness 0,8 mm Kembla 1 Roll 450,000 450,000
5 Copper tube pipe set size 1/4" and 3/8" including pipe insulator
thickness 0,71mm Kembla 5 meter 60,000 300,000
6 Flare nut Kuningan 1/4" 2 Pcs 15,000 30,000
7 Flare nut Kuningan 3/8" 2 Pcs 15,000 30,000
8 Insulation Pipe 3/8" x 2m Armaflex 3 pcs 30,000 90,000
9 Insulation Pipe 1/2" x 2m Armaflex 3 pcs 25,000 75,000
10 Insulation tape Dengan lem - 3 pcs 25,000 75,000
11 Mur baut 12 mm - 4 pcs 1,000 4,000
12 Steel Superb Stead Screw 6mm x 25mm - 10 Pcs 500 5,000
13 Steel Superb Stead Screw 4mm x 20mm - 10 Pcs 500 5,000
14 Electrical cable NYY 3x2,5 mm Eterna 10 meter 10,000 100,000
15 Electrical cable NYY 4x2,6 mm Eterna 10 meter 10,000 100,000
16 Stop kontak 3 pin,with fuse 13 A Panasonic 1 Set 75,000 75,000
17 Stop kontak 2 pin,with socket Panasonic 1 Set 75,000 75,000
18 Drain hose 5/8" - 5 meter 3,000 15,000
19 Klem kabel 17mm - 1 Pack 15,000 15,000
20 Klem kabel 10mm - 1 Pack 10,000 10,000
21 Booth By Drawing 1 Set 1,000,000 1,000,000
22 Refrigerant r410a Dupont 1 Can 1,500,000 1,500,000
COMPONEN FABRICATION
1 Hard drawn copper tube 7/8 inch thicKness 0,8 mm Kembla 1 Batang 750,000 750,000
2 Soft drawn copper tube 1/4" thickness 0,8 mm Kembla 1 Roll 450,000 450,000
3 Soft drawn copper tube 1/2 inch thicness 0,8 mm Kembla 1 Roll 750,000 750,000
4 End Cap copper 7/8 inch thikness 0,8 mm Kembla 4 pcs 30,000 120,000
5 Reducer copper 1/2" to 1/4" - 2 pcs 25,000 50,000
6 schrader valve 1/4" - 2 pcs 15,000 30,000
7 flare nut 1/4" - 2 pcs 20,000 40,000
8 Silver solder 15% silver 15% Harris 5 pcs 5,000 25,000
9 Brazing flux Gel 100 ml - 1 Botol 100,000 100,000
HEAT EXCHANGER
1 Soft drawn copper tube 3/8 inch thicness 0,8 mm Kembla 1 Roll 600,000 600,000
2 Hard drawn copper tube 5/8 inch thicKness 0,8 mm Kembla 1 Batang 600,000 600,000
3 Reducer Sleeve 5/8" x 3/8" - 20 Pcs 25,000 500,000
4 U-Bend 3/8" - 5 Pcs 50,000 250,000
GAS UNTUK BRAZING
1 Isi gak Oksigen 7 m3 Standard 1 Tabung 120,000 120,000
2 Isi gas Asitilen 6 m3 Standard 1 Tabung 450,000 450,000
