Product Brochure Green Energy Changes The World

(1)

Product Brochure

Green Energy Changes The World

www.srneinverter.com

For Residential

1.1

(2)

(3)

Solar

Storage Inverter

Solar

Storage System Brief

Introduction

Naming Rule 8

Quick Selection Guide 10

01/ HES series 12

02/ HESP series 18

03/ HYP series 20

04/ ASF series 22

05/ ASP series 26

06/ HFP series 28

07/ HF-HV series 30 08/ HF-LV series 32

09/ HTP series 34

About SRNE 4 Naming Rule 38

Quick Selection Guide 39

01/ EOV series 40

02/ EOH series 42

03/ EOT series 44

04/ EOS series 46

05/ EOC series 48

(4)

About SRNE

4 SRNE Global Headquarter / Shenzhen，China

SRNE Solar Co,.Ltd. was established in 2008, headquartered in Shenzhen, China,Which is a high-tech enterprise integrating R&D, production,

sales and service.

At present, We provides customers with three major product lines: Solar storage system，Solar storage

inverter，Solar charge controller

2021-2023

2017-2020

2012-2016

2009

• Investment Dongguan production base and expanded factory area to 20,000 sqm

• Development and production of solar charge inverters

• Awarded Shenzhen Famous Brand Product

• Development and production of photovoltaic

energy storage systems

• Establishment of a foreign sales department to develop international markets

• Development and production of solar charge controllers

• SRNE Solar Co,.Ltd.

established

• Development and production of solar street light controllers

(5)

Product Philosophy

• High-efficiency

• High-quality

• Cost-effective

• Excellent-service

Business Philosophy

• Integrity

• Innovative

• Surpass

• Win-win

Our Vision

• Our vision is to be the world's leading provider of residential solar energy storage products and solutions.

Our Mission

• Our mission is "green energy

changing the world"

(6)

6

SOLAR

STORAGE INVERTER

For Residential

(7)

(8)

Naming Rule

8

HESP 48 60 S 100 -H

Series name

This character represents the name

of the product series Letter “P”

in the end of series name stands for

“parallel connection”

Battery voltage

This character represents the rated voltage of battery. “48” stands for 48V. “24” stands for 24V.

This character represents the power that can be output by the inverter. “100” stands for 10kW,

“60” stands for 6kW, “30” stands for 3kW.

Output voltage

This character represents the output voltage of inverter, “S ” stands for EU standard voltage (200~240Vac). “U” stands for US standard voltage (100~120Vac)

Solar charging current

This character represents the Max.

charging current by solar power,

“200” stands for 200A , “100”

stands for 100A.

Open circuit voltage

This character represents the Max.

open circuit voltage of solar arrays connect with inverter. Remeber do not exceed this limit. “H” stands for 500V, “145” stands for 145V

(9)

Parallel Connection

Up to 6 units in parallel connection

(10)

Quick Selection Guide

10 Series Models

Output Battery Solar Panel Output mode

Rated Power Output Phase Can be parallel Battery

Voltage Max. Charging

Current Max.Open circuit voltage Self-use Without battery On-grid

HES

HES4840S100-H 4kW

Single-phase 48V 100A 500V √ √ √

HES4846S100-H 4.6kW HES4850S100-H

5.5kW HES4855S100-H

HES4860S100-H 6kW HES4880S200-H 8.8kW

Single-phase 48V 200A 500V+500V √ √ √

HES48100S200-H 10kW HES48120S200-H 12kW

HESP

HESP4840S100-H 4kW

Single-phase/

Three-phase（Parallel） √ 1～6 units 48V 100A 500V+500V √ √ √ HESP4846S100-H 4.6kW

HESP4850S100-H

5.5kW HESP4855S100-H

HESP4860S100-H 6kW

HYP HYP4850S100-H 5kW Single-phase/

Three-phase（Parallel） √ 1～6 units 48V 100A 500V √ √

ASF ASF48100S200-H 10kW

Single-phase 48V 200A

500V+500V √ √

ASF4880S180-H 8kW 180A

ASP ASP4880S180-H 8kW Single-phase/

Three-phase（Parallel） √ 1～6 units 48V 180A

500V+500V √ √

ASP48100S200-H 10kW 200A

EU voltage models（Single-phase：200～240Vac）

(11)

Series Models

Rated Power Output Phase Can be parallel Battery

Voltage Max. Charging

HFP HFP4850S80-H 5kW Single-phase/

Three-phase（Parallel） √ 1～6 units 48V 80A 500V

HFP4850S80-145 5kW 140A 145V √

HF

HF4850S80-H 5kW

Single-phase

48V 80A 500V

√

HF2430S80-H 3kW 24V 80A 500V

HF4850S80-145 5kW 48V 140A 145V

HF4830S60-145 3kW 48V 120A 145V

HF2430S60-100 3kW 24V 140A 100V

HTP HTP4850S80-H 5kW Single-phase/

Three-phase（Parallel） √ 1～6 units 48V 80A 500V √

Quick Selection Guide

Series Models

Rated Power Output Phase Can be parallel Battery Voltage Max. Charging

ASF

ASF4880SH3 8kW

Three-phase 48V

180A

800V+800V √ √

ASF48100SH3 10kW 220A

ASF48120SH3 12kW 260A √ √

HES

HES80SH3 8kW

Three-phase 600V 37.5A 1000V+1000V

√ √ √

HES100SH3 10kW √ √ √

HES120SH3 12kW √ √ √

EU voltage models （ Three-phase ： 380 ～ 415Vac ）

EU voltage models（Single-phase：200～240Vac）

(12)

HES series

• IP65 protection grade for outdoor use

• Time-slot charging & discharging for peak and valley price

• Support self-use/without battery/on-grid output mode

• Support BMS communication

• Up to 1000V PV input voltage, ideal for high power

• The lightweight handle design makes installation more convenient

• Supports both mains and generator power input with intelligent switching

HES80SH3 HES100SH3 HES120SH3 HES4840S100-H HES4846S100-H HES4850S100-H

HES4855S100-H HES4880S200-H HES48100S200-H HES48120S200-H

01

(13)

MODEL HES80SH3 HES100SH3 HES120SH3 Can Be Set INVERTER OUTPUT

Rated Output and UPS Power 8,000W 10,000W 12,000W

Max. Output Power 8,800VA 11,000VA 13,200VA

Peak Power(off grid) 2 times of rated power, 10 S

Rated grid Output Current 11.5A 14.4A 17.3A

Max. grid Output Current 12.7A 12.9A 19.1A

AC voltage range 380～415V（Three-phase）

Rated AC Frequency 50/60Hz

BATTERY

Battery Type Lead-acid / Li-ion / User Defined √

Voltage Range 125～600Vdc

Max. Charging Current 37.5A √

Max. Discharging Current 37.5A √

PV INPUT

Num. of MPPT Trackers 2

No. of Strings Per MPPT Tracker 1+1

Max. DC Input Power 6000W+6000W 7500W+7500W 9000W+9000W

PV Input Current 15A+15A

MPPT Voltage Range 180～850Vdc

Max. PV Input Voltage 1000Vdc+1000Vdc

MAINS/GENERATOR INPUT

Rated apparent power 1,6000W 2,0000W 2,4000W

Max.input Rated apparent power from

grid 1,3200W 1,7600W 2,2000W

Max. grid Intput Current 25.5A 31.9A 38.2A

Rated input Frequency and Voltage 50/60Hz, 3L+N+PE,220/380V;230/400V;240/415V GENERAL

Dimensions 620*550*230mm

Weight 35kg

Protection Degree IP65

Operating Temperature Range -15℃~55℃

Noise ≤30dB

(14)

14

MODEL HES4880S200-H HES48100S200-H HES48120S200-H Can Be Set

INVERTER OUTPUT

Rated Output Power 8,800W 10,000W 12,000W

Max.Peak Power 17,600VA 20,000VA 24,000VA

Rated Output Voltage 230Vac (Single-phase) √

Load Capacity of Motors 5HP 6HP

BATTERY

Rated Battery Voltage 48V

Max.MPPT Charging Current 200A √

Max.Mains/Generator Charging Current 120A √

Max.Hybrid Charging Current 200A √

PV INPUT

Max.PV Array Power 5,500W+5,500W 6,500W+6,500W

Max.Input Current 22A+22A

Max.Voltage of Open Circuit 500Vdc+500Vdc

MAINS/GENERATOR INPUT

Input Voltage Range 90～275Vac √

Frequency Range 50/60Hz

GENERAL

Weight 37kg

Operating Temperature Range -25~55℃,>45℃ derated

Cooling Method Internal Fan

(15)

MODEL HES4840S100-H HES4846S100-H Can Be Set INVERTER OUTPUT

Rated Output Power 4,000W 4,600W

Max.Peak Power 8,000VA 9,200VA

Load Capacity of Motors 4HP

BATTERY

PV INPUT

Max.PV Array Power 4,500W 5,100W

Max.Input Current 22A

Max.Voltage of Open Circuit 500Vdc

MAINS/GENERATOR INPUT

Bypass Overload Current 40A

GENERAL

Weight 19.2kg

(16)

16

MODEL HES4850S100-H HES4855S100-H HES4860S100-H Can Be Set

INVERTER OUTPUT

BATTERY

Max.Mains/Generator Charging

Current 60A √

PV INPUT

MAINS/GENERATOR INPUT

GENERAL

Weight 19.2kg

(17)

Three-phase 8～12kW

Single-phase 4～6kW Single-phase

8～12kW

(18)

HESP series

• IP65 protection grade for outdoor use

• Up to 6 units in parallel for 36kW

• Support self-use/without battery/on-grid output mode

• Adopt dual MPPT technology

HESP4840S100-H HESP4846S100-H HESP4850S100-H

HESP4855S100-H HESP4860S100-H

02

(19)

MODEL HESP4840S100-H HESP4846S100-H HESP4850S100-H

HESP4855S100-H HESP4860S100-H Can Be Set INVERTER OUTPUT

Rated Output Power 4,000W 4,600W 5,500W 6,000W

Max.Peak Power 8,000VA 9,200VA 11,000VA 12,000VA

Rated Output Voltage 230Vac，Single-phase /Three-phase (Parallel) √

Rated AC Frequency 50/60Hz √

Parallel Capacity 1～6 units

BATTERY

Max.MPPT Charging

Current 100A √

Max.Mains/Generator

Charging Current 60A √

PV INPUT

Max.PV Array Power 3,000W+3,000W 3,500W+3,500W 4,000W+4,000W 4,500W+4,500W

Max.Input Current 16A+16A

Max.Voltage of Open

Circuit 500Vdc+500Vdc

MAINS/GENERATOR INPUT

GENERAL

Weight 20kg

Operating Temperature

Range -25~55℃,>45℃ derated

(20)

HYP series

• Support self-use/without battery output mode

• Single phase/ three phase outputs available

HYP4850S100-H

03

(21)

MODEL HYP4850S100-H Can Be Set INVERTER OUTPUT

Rated Output Power 5,000W

Max.Peak Power 10,000VA

Rated AC Frequency 50Hz/60Hz

BATTERY

Battery Type Li-ion/Lead-Acid/User Defined √

Rated Battery Voltage 48Vdc

PV INPUT

Max.PV Array Power 5,500W

MAINS/GENERATOR INPUT

Frequency Range 50Hz/60Hz

GENERAL

Dimensions 446.9*350*133mm

Weight 13kg

Protection Degree IP20, Indor OnIy

Noise <60dB

Cooling Method InternaI Fan

(22)

ASF series

• Rated output power up to 8-12kW

• 2 MPPT strings input

• The 400V three-phase system is efficient, reliable and ideal for large equipment, providing energy and cost saving

ASF4880SH3 ASF48100SH3 ASF48120SH3

ASF4880S180-H ASF48100S200-H

04

(23)

MODEL ASF4880SH3 ASF48100SH3 ASF48120SH3 Can Be Set INVERTER OUTPUT

Max.Peak Power 16,000W 20,000W 24,000W

Rated Output Voltage 230/400Vac（Three-phase ） √

BATTERY

Battery Type Li-ion / Lead-Acid / User Defined √

Max. Charging Current 180A 220A 260A √

PV INPUT

No. of Strings Per MPPT Tracker 2+2

Max. PV Array Power 6,000W+6,000W 7,500W+7,500W 9,000W+9,000W

Max. Input Current 22A+22A

Max. Voltage of Open Circuit 800Vdc+800Vdc

MAINS / GENERATOR INPUT

Rated Input Voltage phase voltage 170~280V, line voltage 305~485V

Rated Input Frequency 50/60Hz

GENERAL

Weight 27kg

Protection Degree IP20，Indoor Only

Noise <60dB

(24)

24

MODEL ASF4880S180-H ASF48100S200-H Can Be Set

INVERTER OUTPUT

Rated Output Voltage 230Vac（Single-phase ） √

Rated AC Frequency 50/60Hz √

BATTERY

Max.MPPT Charging Current 180A 200A √

Max.Mains/Generator Charging Current 100A 120A √

Max.Hybrid Charging Current 180A 200A √

PV INPUT

Max.PV array power 5,500W+5,500W

Max.input current 22A+22A

MAINS / GENERATOR INPUT

GENERAL

Weight 27kg

Noise <60dB

(25)

Three-phase 8～12kW

Single-phase

8～10kW

(26)

ASP series

• Single unit power up to 8-10kW

• Dual MPPT, with an efficiency of up to 99.9%.

• Time-of-use charging and discharging function suitable for peak and valley electricity price applications.

• The energy-saving mode function of a single machine reduces no-load energy loss.

• Supports Lithium battery BMS communication.

ASP4880S180-H ASP48100S200-H

05

(27)

MODEL ASP4880S180-H ASP48100S200-H Can Be Set INVERTER OUTPUT

Parallel Capacity 1～6 units √

BATTERY

PV INPUT

Max.PV array power 5,500W+5,500W

Max.input current 22A+22A

MAINS / GENERATOR INPUT

GENERAL

Weight 27kg

Noise <60dB

(28)

HFP series

• Suitable for off-grid applications

• Single phase / three phase outputs available

• Multiple charge and discharge modes are available

HFP4850S80-H HFP4850S80-145

06

(29)

MODEL HFP4850S80-H HFP4850S80-145 Can Be Set INVERTER OUTPUT

BATTERY

PV INPUT

Max.Input Current 22A 50A

Max.Voltage of Open Circuit 500Vdc 145Vdc

MAINS/GENERATOR INPUT

GENERAL

Weight 10.8kg

Operating Temperature Range -10℃~55℃ -15℃~55℃

Noise <60dB

(30)

HF -High PV Voltage

series

• Stable output of pure sine waves

HF4850S80-H HF2430S80-H

07

(31)

MODEL HF4850S80-H HF2430S80-H Can Be Set INVERTER OUTPUT

Rated Output Voltage 230Vac（single phase） √

BATTERY

Rated Battery Voltage 48Vdc 24Vdc

PV INPUT

MAINS/GENERATOR INPUT

Bypass Overload Current 40A 30A

GENERAL

Dimensions 426*322*126mm 378*280*103mm

Weight 10.9kg 6.9kg

Operating Temperature Range -15℃~55℃ -10℃~55℃

Noise <60dB

(32)

HF -Low PV Voltage

series

• Stable output of pure sine waves

HF4850S80-145 HF4830S60-145 HF2430S60-100

08

(33)

MODEL HF4850S80-145 HF4830S60-145 HF2430S60-100 Can Be Set INVERTER OUTPUT

Max.Peak Power 10,000VA 6,000VA 6,000VA

Rated Output Voltage 230Vac（single phase） √

Load Capacity of Motors 4HP 2HP 2HP

BATTERY

Rated Battery Voltage 48Vdc 24Vdc

Max.Hybrid Charging Current 140A 120A 140A √

PV INPUT

Max.PV Array Power 4,400W 3,400W 1,600W

Max.Voltage of Open Circuit 145Vdc 100Vdc

MAINS/GENERATOR INPUT

GENERAL

Dimensions 426*322*124mm 378*280*103mm

Weight 10.8kg 6.2kg

Noise <60dB

(34)

HTP series

• Single phase / three phase outputs available

• Rackmount design for easy integration

HTP4850S80-H

09

(35)

MODEL HTP4850S80-H Can Be Set INVERTER OUTPUT

Rated Output Voltage 230Vac，single phase(Parallel)/three phase (Parallel) √

BATTERY

PV INPUT

Max.PV Array Power 5,500W

MAINS/GENERATOR INPUT

GENERAL

Weight 14kg

Noise <60dB

(36)

36

SOLAR

STORAGE SYSTEM

For Residential

(37)

(38)

Naming Rule

38

EOS 05 B 220

Series name

This character represents the name of the product series

Product installation method

Output voltage

Represents the output voltage of the inverter

"220 "stands for EU standard voltage (200~240Vac)

"110 "stands for US standard voltage (100~120Vac)

Battery storage capacity

05: Battery capacity is 5kWh 10: The battery capacity is 10kWh

B: Energy storage battery C: Power conversion module S: Energy storage system

(39)

Quick Selection Guide

Model Rated Output Voltage 1 inv + 1 bat 1 inv + 2 bat 1 inv + 3 bat 1 inv + 4 bat 1 inv + 5 bat 1 inv +6 bat 1 inv + 7 bat 1 inv + 8 bat 1 inv + 9 bat

EOV

series 220Vac single-phase 5kW+5.12kWh 5kW+10.24kWh 5kW+15.36kWh 5kW+20.48kWh / ^/ ^/ ^/ ^/

EOH

series

230Vac single-phase / 10kW+10.24kWh 10kW+15.36kWh 10kW+20.48kWh 10kW+25.6kWh 10kW+30.72kWh 10kW+35.84kWh 10kW+40.96kWh 10kW+46.08kWh 220Vac single-phase 5kW+5.12kWh 5kW+10.24kWh 5kW+15.36kWh 5kW+20.48kWh 5kW+25.6kWh 5kW+30.72kWh 5kW+35.84kWh 5kW+40.96kWh 5kW+46.08kWh

Solar Storage System

（solar inv&bat integrated）

Model Rated Battery Power 1 unit 2 units 3 units 4 units 5 units 6 units 7 units 8 units 9 units EOS05B ^5.12kWh ^5.12kWh ^10.24kWh ^15.36kWh ^20.48kWh ^25.6kWh ^30.72kWh ^35.84kWh ^40.96kWh ^46.08kWh EOS10B ^10.24kWh ^10.24kWh ^20.48kWh ^30.72kWh ^40.96kWh ^51.2kWh ^61.44kWh ^71.68kWh ^81.92kWh ^92.16kWh EOC05B ^5.12kWh ^5.12kWh ^10.24kWh ^15.36kWh ^20.48kWh ^25.6kWh ^30.72kWh ^35.84kWh ^40.96kWh ^46.08kWh

Solar Storage Battery

Series Models

Output Battery Solar Panel AC Bypass Output

Rated Power Output Phase Battery Capacity Rated Voltage Max. Charge

Current Max.Open circuit

voltage Max. Charge

Current Auto Bypass Rated Output Power

Manual Bypass Rated Output

Power EOT ^EOT01S-220 ^1.5kW Single-phase

50AH

25.6V

50A

108V

40A 2kW

5kW

EOT02S-220 2.5kW 100AH 100A 60A 3kW

Aii-In-One Solar Storage System

(40)

EOV series

• Up to 4 batteries in parallel expand to 20.48kWh

• High quality lithium iron phosphate cells

• No matching and commissioning required, ready to install

• Up to 2 systems in parallel with double storage & output

• Large LCD screen with real-time data

• Multiple charge and discharge modes available

SR-EOV05S-220 SR-EOV10S-220 SR-EOV15S-220 SR-EOV20S-220

01

(41)

Inverter Module SR-EOV05C-220 Can Be Set Output

Max. Peak Power 10,000VA

Load Capacity of Motor 4HP

Wave Form Pure Sine Wave

Rated Output Voltage 220Vac （single phase） ✓

Max. Parallel Capacity 2 units （up to 10kW ） ✓

Output Mode Off-grid/Hybrid ✓

Solar Input

Solar Charge Type MPPT

Max. Solar Array Power 5,500W

Max. Solar Open Circuit Voltage 500Vdc

Grid / Generator Input

Input Voltage Range 90~280Vac

Battery Charging

Max. Solar Charging Current 100A ✓

Max. Grid/Generator Charging Current 60A ✓

General

Dimension 500*555*130mm（1.64*1.82*0.42ft）

Battery Module SR-EOV05B Can Be Set

Battery Power 5.12kWh

Rated Voltage 51.2V

Rated Capacity 100Ah

Battery Type LFP

Crycling Lifespan 6000 (80%DOD,0.5C,25°C)

Max. Parallel Capacity 4 units （up to 20.48kWh） ✓

Dimension 600*555*130mm（1.96*1.82*0.42ft）

Standard UN38.3,MSDS,UL1973，IEC62619,IEC61000 RoHS

(42)

EOH series

• Integrated inverter design, easy to use and quick to install

• Users can set the charging and discharging time of the battery and mains to save on electricity bills

• The system offers various charging methods, including solar power, commercial power, or a combination of both

• The system allows for parallel connection of up to 9 batteries, providing a maximum capacity of 45kWh.

SR-EOH05S-220 SR-EOH10S-220 SR-EOH15S-220 SR-EOH20S-220 SR-EOH25S-220 SR-EOH30S-220

SR-EOH35S-220 SR-EOH40S-220 SR-EOH45S-220

02

(43)

Inverter Module SR-EOH05C-220 SR-EOH10C-220 Can Be Set Output

Max. Peak Power 10,000VA 20,000VA

Load Capacity of Motor 4HP 6HP

Wave Form Pure Sine Wave

Rated Output Voltage 220Vac （Single-phase） 230Vac （Single-phase） ✓

Output Mode Off-grid/Hybrid ✓

Solar Input

Solar Charge Type MPPT

Max. Solar Array Power 5,500W 5,500W + 5,500W

Max. Solar Open Circuit Voltage 500Vdc

Grid / Generator Input

Input Voltage Range 90~280Vac

Battery Charging

Max. Solar Charging Current 100A 200A ✓

Max. Grid/Generator Charging Current 60A 120A ✓

General

Dimension 655*353*210 (2.14*1.15*0.69ft） 655*353*328mm（2.14*1.15*1.07ft）

Battery Module SR-EOH05B Can Be Set

Rated Voltage 51.2V

Battery Type LFP

Max. Parallel Capacity 9 units （up to 46.08kWh） ✓

Dimension 655*353*205mm（2.14*1.15*0.67ft）

Standard UN38.3,MSDS,IEC62619,UL1973,IEC61000-6:2019,RoHS

(44)

EOT series

• Low noise design provides users with a quieter user experience.

• Automatic and manual bypass function Equipped with automatic and manual power switching function, manual switching can provide a maximum power of 5000W.

• Pure sine wave output Stronger carrying capacity, can connect more household loads.

• Fast charging PV and AC hybrid charging，fast charging speed, can fully charge the battery in up to 1 hour

SR-EOT01S-220 SR-EOT02S-220

03

(45)

MODEL SR-EOT01S-220 SR-EOT02S-220 INVERTER OUTPUT

Rated Output Voltage 230Vac（Single-phase）

BATTERY

Battery Type LiFePO4

Battery Energy 1.28kWh 2.56kWh

Battery Capacity 50AH 100AH

Battery Rated Voltage 25.6V

Battery Working Voltage Range 22.4～28.8V

Standard Charge current 25A 50A

Max. Charge Current 50A 100A

PV CHARGE

Max. Output Power 1,000W 1,500W

Max. MPPT Charging Current 40A 60A

Max. Voltage of Open Circuit 108V

MPPT Voltage Range 30~95Vdc

AC CHARGE

Max. AC Charge Power 1,000W 1,500W

Max. AC Charging Current 40A 60A

Rated Input Voltage 220/230Vac

Input Voltage Range 90～280Vac

AC Bypass Output

Auto Bypass Rated Output Power 2,000W 3,000W

Manual Bypass Rated Output Power 5,000W

Frequency 50Hz

AC Input Breaker 30A

GENERAL

Noise ≤40dB

(46)

EOS series

• Supports wall or floor mounting

• Up to 9 in parallel connection, expand to 92.16kWh

• Min. width of just 19.1cm, saving space in the home

• Compatible with many brands of inverter protocols

• Support Wifi and BT view real-time data through APP

SR-EOS05B SR-EOS10B

04

(47)

MODEL SR-EOS05B SR-EOS10B Can Be Set MAIN INFO

Rated Voltage 51.2V

Rated Capacity 100Ah 200Ah

Battery Power 5.12kWh 10.24kWh

Battery Type LFP

Lifetime 20 years

Max. Parallel Capacity 9 units ✓

CHARGE&DISCHRAGE

Max. Charging Voltage 57.6V ✓

Over Discharging Voltage 44.8V ✓

Max. Charging Current 100A 150A ✓

Peak Charging Current 110A (3s) 200A (3s) ✓

Max. Discharging Current 100A 200A ✓

Peak Discharging Current 110A (3s) 220A (3s) ✓

GENERAL

Weight 47kg （103.6lb） 88kg，（194lb）

Dimension（L*W*H） 460*100*725mm （1.5*0.32*2.37ft） 620*205*1014mm（2*0.67*3ft）

Communication CAN / RS485 / USB / WiFi / Bluetooth ✓

Storage Condition 6 months@25°C/77°F，3 months@35°C/95°F，1 month@45°C/113°F

Charging Temp. Range 0～45℃（32~113℉）

Discharging Temp. Range -10～45℃（14~113℉）

Cooling Method Natural Cooling

Protection Grade IP30 IP65

STANDARD

Transportation UN38.3,MSDS

Standard EN IEC 61000,EN IEC 62619,IEC 62321 EN IEC 61000,EN IEC 62619,IEC 62321,EN 60529

(48)

EOC series

• Supports USB interface for direct computer communication.

• Supports wall, floor,stack or rack mounting

• Up to 9 in parallel connection, expand to 45kWh

• Minimum width of 12cm, saving space at home

• Low internal resistance design mode is adopted

SR-EOC05B

05

(49)

MODEL SR-EOC05B Can Be Set MAIN INFO

Rated Voltage 51.2V

Battery Type LFP

Lifetime 20 years

Max. Parallel Capacity 9 units ✓

CHARGE&DISCHRAGE

Max. Charging Voltage 57.6V ✓

Over Discharging Voltage 44.8V ✓

Standard charge current 50A

Max. Charging Current 100A (1C) ✓

Peak Charging Current 110A (1.1C,3s) ✓

Standard discharge current 50A

Max. Discharging Current 100A (1C) ✓

Peak Discharging Current 110A (1.1C,3s) ✓

GENERAL

Weight 45kg （99.2lb）

Dimension（L*W*H） 580*446*120mm （1.9*1.46*0.39ft）

Communication CAN / RS485 / USB / ✓

Storage Condition 6 months@25°C/77°F，3 months@35°C/95°F，1 month@45°C/113°F

Charging Temp. Range 0～45℃

Discharging Temp. Range -10～45℃

Cooling Method Natural Cooling

Protection Grade IP30

STANDARD

Transportation UN38.3,MSDS

Safety IEC 62619: 2017,EN IEC 61000-6,UL1973

(50)

Applications

50

HT series

HES series

HES series

(51)

HYP+EOS series

Applications

ASF+EOS series

HC series-Solar sewage treatment ASF+EOS series

(52)

SRNE Solar Co,.Ltd

Mail [email protected] Web www.srneinverter.com www.srnesolar.com

Add

4-5F,Building13A,Taihua Wutong Industrial Park ,Gushu

Development Zone , Hangcheng Street,Baoan, Shenzhen, China PR

@SRNE solar

(53)

Product Brochure Green Energy Changes The World
